Tuwunel

High Performance Matrix Homeserver in Rust!

Tuwunel is a featureful Matrix homeserver you can use instead of Synapse with your favorite client, bridge or bot. It is written entirely in Rust to be a scalable, low-cost, enterprise-ready, community-driven alternative, fully implementing the Matrix Specification for all but the most niche uses.

This project is the official successor to conduwuit after it reached stability. Tuwunel is now used by many companies with a vested interest in its continued development by full-time staff. It is primarily sponsored by the government of Switzerland 🇨🇭 where it is currently deployed for citizens.

Getting Started

• GitHub Releases
• Sourcecode git clone https://github.com/matrix-construct/tuwunel.git
• DockerHub or docker pull jevolk/tuwunel:latest
• GHCR or docker pull ghcr.io/matrix-construct/tuwunel:latest
• Static binaries available as releases or build artifacts.
• Deb and RPM packages available as releases or build artifacts.
• Arch package available as tuwunel.
• Nix package available as matrix-tuwunel and NixOS module available as services.matrix-tuwunel.
• Alpine package available as tuwunel.
• Gentoo ebuild available in Guru as net-im/tuwunel.
• Ansible playbook available as matrix-docker-ansible-deploy.

1. Configure by copying and editing the tuwunel-example.toml. The server_name and database_path must be configured. Most users deploy via docker or a distribution package and should follow the appropriate guide instead. This is just a summary for the impatient. See the full documentation.

Tip

Avoid using a sub-domain for your server_name. You can always delegate later with a .well-known file, but you can never change your server_name.

2. Setup TLS certificates. Most users enjoy the Caddy reverse-proxy which automates their certificate renewal. Advanced users can load their own TLS certificates using the configuration and Tuwunel can be deployed without a reverse proxy. Example /etc/caddy/Caddyfile configuration with Element unzipped to /var/www/element:

tuwunel.me, tuwunel.me:8448 {
    reverse_proxy localhost:8008
}
web.tuwunel.me {
    root * /var/www/element/
    file_server
}

caddy reload --config /etc/caddy/Caddyfile

3. Start the server, connect your client and register your username. The first registration is granted server admin.

Tip

Configure a secret registration_token and set allow_registration = true

🤗 Did you find this and other documentation helpful? We would love to hear feedback about setting up Tuwunel.

Migrating to Tuwunel

Caution

Never switch between different forks of Conduit or you will corrupt your database. All derivatives of Conduit share the same linear database version without any awareness of other forks. The database will permanently corrupt and we will not be able to help you.

Migrating from conduwuit

Migrating from conduwuit to Tuwunel just works. In technical parlance it is a “binary swap.” All you have to do is update to the latest Tuwunel and change the path to the executable from conduwuit to tuwunel.

Anything else named “conduwuit” is still recognized, this includes environment variables with prefixes such as CONDUWUIT_. In fact, CONDUIT_ is still recognized for our legacy users. You may have noticed that various configs, yamls, services, users, and other items were renamed, but if you were a conduwuit user we recommend against changing anything at all. This will keep things simple. If you are not sure please ask. If you found out that something did in fact need to be changed please open an issue immediately.

Upgrading & Downgrading Tuwunel

We strive to make moving between versions of Tuwunel safe and easy. Downgrading Tuwunel is always safe but often prevented by a guard. An error will indicate the downgrade is not possible and a newer version which does not error must be sought.

Branches

The main branch is always reasonably safe to run. We understand the propensity for users to simply clone the main branch to get up and running, and we’re obliged to ensure it’s always viable. Nevertheless, only tagged releases are true releases.

Container Tracking

Important

We strongly advise tracking the :latest tag when automatically updating.

Tracking :latest gives us the necessary discretion to keep you on the appropriate stable release version. Tracking the :preview tag provides select updates of higher confidence between releases. Tracking the :main branch provides the most frequent updates which have been reviewed and tested with confidence for release, the only remaining risk being the unknown. The publication frequency for these tags are on average monthly, weekly and daily, respectively.

Getting Help & Support

If you are opposed to using github, or if private discussion is required such as for security disclosures, or for any other reason, I would be happy to receive your DM at @jason:tuwunel.me. This will not be bothering me as it would be my pleasure to help you when possible. As an emergency contact you can send an email to jasonzemos@gmail.com.

Tuwunel Fanclub

We have an unofficial community-run chat which is publicly accessible at #tuwunel:matrix.org. The members, content, or moderation decisions of this room are not in any way related or endorsed by this project or its sponsors, and not all project staff will be present there. There will be at least some presence by staff to offer assistance so long as the room remains in minimally good standing.

Tuwunel^💕

Tuwunel’s theme is empathy in communication defined by the works of Edith Stein. Empathy is the basis for how we approach every message and our responsibility to the other in every conversation.

How can I deploy my own?

• Deployment options

If you want to connect an appservice to Tuwunel, take a look at the appservices documentation.

How can I contribute?

See the contributor’s guide

Deploying into service

Read the Generic guide first regardless of which platform you ultimately use. It explains the universal requirements — binary selection, database configuration, the system user, and the systemd unit — that every other guide builds on.

Choosing a reverse proxy

Tuwunel listens on plain HTTP and requires a reverse proxy to terminate TLS. All guides assume HTTPS is already handled externally.

Caddy is the recommended choice. It handles TLS automatically via Let’s Encrypt, and the full Tuwunel configuration fits in two lines. It also proxies port 8448 (Matrix federation) in the same block with no extra work.

Nginx is a solid choice if you are already running it. The configuration is more verbose but well-documented. Set client_max_body_size to match or exceed Tuwunel’s max_request_size (default 20 MiB), and never use $request_uri in the proxy pass — it causes subtle breakage.

Warning

Apache and Lighttpd are not supported for Matrix federation. Both alter the X-Matrix authorization header that federation depends on. Nginx and Caddy handle it correctly.

Traefik works well in Docker environments. Note that Traefik cannot serve .well-known files by itself — you need a companion nginx container for federation discovery, or expose port 8448 directly as a Traefik entrypoint. Also check whether you are running a version between 3.6.4–3.6.6 or 2.11.32–2.11.34, which contain a bug that requires an extra workaround flag.

Root-domain delegation

By default, Tuwunel’s server name is the domain that appears in Matrix user IDs (@alice:example.com), which must exactly match the host Tuwunel presents when federating. If you want to host Matrix under a subdomain (matrix.example.com) while users have addresses on the root domain (example.com), configure root-domain delegation. This serves .well-known/matrix/client and .well-known/matrix/server from the root domain pointing to the subdomain, and requires no changes to DNS beyond what is already needed for your web server.

Things to know before getting started

Pick the right binary. Prebuilt binaries for x86_64 come in -v1-, -v2-, and -v3- CPU-optimized variants. Running the wrong one produces an Illegal Instruction crash. The generic guide includes a command to check which variant your CPU supports; -v2- or better is recommended for RocksDB’s CRC32 performance.

RocksDB is the only supported database. SQLite support has been removed. If you are migrating from Conduit, you will need a migration tool before deploying Tuwunel.

Port 8448 matters for federation. Clients connect on port 443, but other Matrix homeservers connect on port 8448. Both must be reachable for a fully functional server. NAT hairpinning or split-horizon DNS may be needed for internal clients that need to reach the same domain.

Container images are minimal. Docker and Podman images contain only the binary, a minimal init (tini), and CA certificates — no shell. If you need to inspect a running container you will need to exec into it using the binary directly.

Rootless Podman requires linger. Without loginctl enable-linger, rootless containers stop when the user logs out. The Podman guide uses quadlet files and user-level systemd to handle this correctly.

NixOS has platform-specific workarounds. The community services.matrix-conduit NixOS module defaults to SQLite, requires a manual workaround for UNIX socket support, and conflicts with jemalloc when a hardened profile is enabled. The NixOS guide covers all three.

Configuration

This chapter describes various ways to configure Tuwunel.

Basics

Tuwunel uses a config file for the majority of the settings, but also supports setting individual config options via commandline.

Please refer to the example config file for all of those settings.

The config file to use can be specified on the commandline when running Tuwunel by specifying the -c, --config flag. It is also possible to specify more than one config file.

Alternatively, you can use the environment variable TUWUNEL_CONFIG to specify the config file to used. Conduit’s environment variables are supported for backwards compatibility.

Important

It is bad practice to uncomment default options without changing them. Many defaults are updated by developers as features evolve and can be essential to expected server function.

Option commandline flag

Tuwunel supports setting individual config options in TOML format from the -O / --option flag. For example, you can set your server name via -O server_name=\"example.com\".

Note that the config is parsed as TOML, and shells like bash will remove quotes. So unfortunately it is required to escape quotes if the config option takes a string. This does not apply to options that take booleans or numbers:

• --option allow_registration=true works ✅
• -O max_request_size=99999999 works ✅
• -O server_name=example.com does not work ❌
• --option log=\"debug\" works ✅
• --option server_name='"example.com"' works ✅

Relevance of configuration settings

There is a specific sequence for reading and overwriting the settings. The latest setting takes precedence and defines the configuration.

1. Set in CONDUIT_CONFIG.
2. Set in CONDUWUIT_CONFIG.
3. Set in TUWUNEL_CONFIG.
4. Set in the first config file on the command line (e.g. -c config_file_1.toml).
5. Set in the second config file on the command line (e.g. -c config_file_2.toml).
6. Set in any additional config file on the command line (e.g. -c config_file_n.toml).
7. Set within the options (again, the latest option in the list overrides).

Environment variables

All of the settings that are found in the config file can be specified by using environment variables. The environment variable names should be all caps and prefixed with TUWUNEL_.

For example, if the setting you are changing is max_request_size, then the environment variable to set is TUWUNEL_MAX_REQUEST_SIZE.

To modify config options not in the [global] context such as [global.well_known], use the __ suffix split: TUWUNEL_WELL_KNOWN__SERVER

Conduit and conduwuit’s environment variables are supported for backwards compatibility (e.g. CONDUIT_SERVER_NAME or CONDUWUIT_SERVER_NAME).

Execute commandline flag

Tuwunel supports running admin commands on startup using the commandline argument --execute. The most notable use for this is to create an admin user on first startup.

The syntax of this is a standard admin command without the prefix such as ./tuwunel --execute "users create_user june"

An example output of a success is:

INFO tuwunel_service::admin::startup: Startup command #0 completed:
Created user with user_id: @june:girlboss.ceo and password: `<redacted>`

This commandline argument can be paired with the --option flag.

Examples

Example configuration

### Tuwunel Configuration
###
### THIS FILE IS GENERATED. CHANGES/CONTRIBUTIONS IN THE REPO WILL BE
### OVERWRITTEN!
###
### You should rename this file before configuring your server. Changes to
### documentation and defaults can be contributed in source code at
### src/core/config/mod.rs. This file is generated when building.
###
### Any values pre-populated are the default values for said config option.
###
### At the minimum, you MUST edit all the config options to your environment
### that say "YOU NEED TO EDIT THIS".
###
### For more information, see:
### https://tuwunel.chat/configuration.html


[global]

# The server_name is the pretty name of this server. It is used as a
# suffix for user and room IDs/aliases.
#
# See the docs for reverse proxying and delegation:
# https://tuwunel.chat/deploying/generic.html#setting-up-the-reverse-proxy
#
# Also see the `[global.well_known]` config section at the very bottom.
#
# Examples of delegation:
# - https://matrix.org/.well-known/matrix/server
# - https://matrix.org/.well-known/matrix/client
#
# YOU NEED TO EDIT THIS. THIS CANNOT BE CHANGED AFTER WITHOUT A DATABASE
# WIPE.
#
# example: "girlboss.ceo"
#
#server_name =

# This is the only directory where tuwunel will save its data, including
# media. Note: this was previously "/var/lib/matrix-conduit".
#
#database_path = "/var/lib/tuwunel"

# Text which will be added to the end of the user's displayname upon
# registration with a space before the text. In Conduit, this was the
# lightning bolt emoji.
#
# To disable, set this to "" (an empty string).
#
# reloadable: yes
#
#new_user_displayname_suffix = "💕"

# The default address (IPv4 or IPv6) tuwunel will listen on.
#
# If you are using Docker or a container NAT networking setup, this must
# be "0.0.0.0".
#
# To listen on multiple addresses, specify a vector e.g. ["127.0.0.1",
# "::1"]
#
#address = ["127.0.0.1", "::1"]

# The port(s) tuwunel will listen on.
#
# For reverse proxying, see:
# https://tuwunel.chat/deploying/generic.html#setting-up-the-reverse-proxy
#
# If you are using Docker, don't change this, you'll need to map an
# external port to this.
#
# To listen on multiple ports, specify a vector e.g. [8080, 8448]
#
#port = 8008

# The UNIX socket tuwunel will listen on.
#
# Remember to make sure that your reverse proxy has access to this socket
# file, either by adding your reverse proxy to the 'tuwunel' group or
# granting world R/W permissions with `unix_socket_perms` (666 minimum).
#
# example: "/run/tuwunel/tuwunel.sock"
#
#unix_socket_path =

# The default permissions (in octal) to create the UNIX socket with.
#
#unix_socket_perms = 660

# Error on startup if any config option specified is unknown to Tuwunel.
#
# This is false by default to allow easier deprecation or removal of
# config options in the future without breaking existing deployments. The
# default behaviour is to simply warn on startup.
# reloadable: yes
#
#error_on_unknown_config_opts = false

# tuwunel supports online database backups using RocksDB's Backup engine
# API. To use this, set a database backup path that tuwunel can write
# to.
#
# For more information, see:
# https://tuwunel.chat/maintenance.html#backups
#
# reloadable: yes
# example: "/opt/tuwunel-db-backups"
#
#database_backup_path =

# The amount of online RocksDB database backups to keep/retain, if using
# "database_backup_path", before deleting the oldest one.
#
# reloadable: yes
#
#database_backups_to_keep = 1

# Set this to any float value to multiply tuwunel's in-memory LRU caches
# with such as "auth_chain_cache_capacity".
#
# May be useful if you have significant memory to spare to increase
# performance.
#
# If you have low memory, reducing this may be viable.
#
# By default, the individual caches such as "auth_chain_cache_capacity"
# are scaled by your CPU core count.
#
#cache_capacity_modifier = 1.0

# Set this to any float value in megabytes for tuwunel to tell the
# database engine that this much memory is available for database read
# caches.
#
# May be useful if you have significant memory to spare to increase
# performance.
#
# Similar to the individual LRU caches, this is scaled up with your CPU
# core count.
#
# This defaults to 128.0 + (64.0 * CPU core count).
#
#db_cache_capacity_mb = varies by system

# Set this to any float value in megabytes for tuwunel to tell the
# database engine that this much memory is available for database write
# caches.
#
# May be useful if you have significant memory to spare to increase
# performance.
#
# Similar to the individual LRU caches, this is scaled up with your CPU
# core count.
#
# This defaults to 48.0 + (4.0 * CPU core count).
#
#db_write_buffer_capacity_mb = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#pdu_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#auth_chain_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#shorteventid_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#eventidshort_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#eventid_pdu_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#shortstatekey_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#statekeyshort_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#servernameevent_data_cache_capacity = varies by system

# This item is undocumented. Please contribute documentation for it.
#
#stateinfo_cache_capacity = varies by system

# Minimum time-to-live in seconds for room summary entries in the spaces
# cache.
#
# reloadable: yes
#
#spacehierarchy_cache_ttl_min = 21600

# Maximum time-to-live in seconds for room summary entries in the spaces
# cache.
#
# reloadable: yes
#
#spacehierarchy_cache_ttl_max = 129600

# Minimum timeout a client can request for long-polling sync. Requests
# will be clamped up to this value if smaller.
#
# reloadable: yes
#
#client_sync_timeout_min = 5000

# Default timeout for long-polling sync if a client does not request
# another in their query-string.
#
# reloadable: yes
#
#client_sync_timeout_default = 30000

# Maximum timeout a client can request for long-polling sync. Requests
# will be clamped down to this value if larger.
#
# reloadable: yes
#
#client_sync_timeout_max = 90000

# Maximum entries stored in DNS memory-cache. The size of an entry may
# vary so please take care if raising this value excessively. Only
# decrease this when using an external DNS cache. Please note that
# systemd-resolved does *not* count as an external cache, even when
# configured to do so.
#
#dns_cache_entries = 32768

# Minimum time-to-live in seconds for entries in the DNS cache. The
# default may appear high to most administrators; this is by design as the
# exotic loads of federating to many other servers require a higher TTL
# than many domains have set. Even when using an external DNS cache the
# problem is shifted to that cache which is ignorant of its role for
# this application and can adhere to many low TTL's increasing its load.
#
#dns_min_ttl = 10800

# Minimum time-to-live in seconds for NXDOMAIN entries in the DNS cache.
# This value is critical for the server to federate efficiently.
# NXDOMAIN's are assumed to not be returning to the federation and
# aggressively cached rather than constantly rechecked.
#
# Defaults to 3 days as these are *very rarely* false negatives.
#
#dns_min_ttl_nxdomain = 259200

# Number of DNS nameserver retries after a timeout or error.
#
#dns_attempts = 10

# The number of seconds to wait for a reply to a DNS query. Please note
# that recursive queries can take up to several seconds for some domains,
# so this value should not be too low, especially on slower hardware or
# resolvers.
#
#dns_timeout = 10

# Fallback to TCP on DNS errors. Set this to false if unsupported by
# nameserver.
#
#dns_tcp_fallback = true

# Enable to query all nameservers until the domain is found. Referred to
# as "trust_negative_responses" in hickory_resolver. This can avoid
# useless DNS queries if the first nameserver responds with NXDOMAIN or
# an empty NOERROR response.
#
#query_all_nameservers = true

# Enable using *only* TCP for querying your specified nameservers instead
# of UDP.
#
# If you are running tuwunel in a container environment, this config
# option may need to be enabled. For more details, see:
# https://tuwunel.chat/troubleshooting.html#potential-dns-issues-when-using-docker
#
#query_over_tcp_only = false

# DNS A/AAAA record lookup strategy
#
# Takes a number of one of the following options:
# 1 - Ipv4Only (Only query for A records, no AAAA/IPv6)
#
# 2 - Ipv6Only (Only query for AAAA records, no A/IPv4)
#
# 3 - Ipv4AndIpv6 (Query for A and AAAA records in parallel, uses whatever
# returns a successful response first)
#
# 4 - Ipv6thenIpv4 (Query for AAAA record, if that fails then query the A
# record)
#
# 5 - Ipv4thenIpv6 (Query for A record, if that fails then query the AAAA
# record)
#
# If you don't have IPv6 networking, then for better DNS performance it
# may be suitable to set this to Ipv4Only (1) as you will never ever use
# the AAAA record contents even if the AAAA record is successful instead
# of the A record.
#
#ip_lookup_strategy = 5

# List of domain patterns resolved via the alternative path without any
# persistent cache, very small memory cache, and no enforced TTL. This
# is intended for internal network and application services which require
# these specific properties. This path does not support federation or
# general purposes.
#
# reloadable: yes
# example: ["*\.dns\.podman$"]
#
#dns_passthru_domains = []

# Whether to resolve appservices via the alternative path; setting this is
# superior to providing domains in `dns_passthru_domains` if all
# appservices intend to be matched anyway. The overhead of matching regex
# and maintaining the list of domains can be avoided.
#
#dns_passthru_appservices = false

# Enable or disable case randomization for DNS queries. This is a security
# mitigation where answer spoofing is prevented by having to exactly match
# the question. Occasional errors seen in logs which may have lead you
# here tend to be from overloading DNS. Nevertheless for servers which
# are truly incapable this can be set to false.
#
# This currently defaults to false due to user reports regarding some
# popular DNS caches which may or may not be patched soon. It may again
# default to true in an upcoming release.
#
#dns_case_randomization = false

# Max request size for file uploads. Accepts an integer byte count or a
# string with SI/IEC suffix such as "24 MiB".
#
#max_request_size = 24 MiB

# Maximum number of concurrently pending (asynchronous) media uploads a
# user can have.
#
# reloadable: yes
#
#max_pending_media_uploads = 5

# The time in seconds before an unused pending MXC URI expires and is
# removed.
#
# reloadable: yes
#
#media_create_unused_expiration_time = 86400 (24 hours)

# The maximum number of media create requests per second allowed from a
# single user.
#
# reloadable: yes
#
#media_rc_create_per_second = 10

# The maximum burst count for media create requests from a single user.
#
# reloadable: yes
#
#media_rc_create_burst_count = 50

# This item is undocumented. Please contribute documentation for it.
# reloadable: yes
#
#max_fetch_prev_events = 192

# Default/base connection timeout (seconds). This is used only by URL
# previews and update/news endpoint checks.
#
#request_conn_timeout = 10

# Default/base request timeout (seconds). The time waiting to receive more
# data from another server. This is used only by URL previews,
# update/news, and misc endpoint checks.
#
#request_timeout = 35

# Default/base request total timeout (seconds). The time limit for a whole
# request. This is set very high to not cancel healthy requests while
# serving as a backstop. This is used only by URL previews and update/news
# endpoint checks.
#
#request_total_timeout = 320

# Default/base idle connection pool timeout (seconds). This is used only
# by URL previews and update/news endpoint checks.
#
#request_idle_timeout = 5

# Default/base max idle connections per host. This is used only by URL
# previews and update/news endpoint checks. Defaults to 1 as generally the
# same open connection can be re-used.
#
#request_idle_per_host = 1

# Federation well-known resolution connection timeout (seconds).
#
#well_known_conn_timeout = 6

# Federation HTTP well-known resolution request timeout (seconds).
#
#well_known_timeout = 10

# Federation client request timeout (seconds). You most definitely want
# this to be high to account for extremely large room joins, slow
# homeservers, your own resources etc.
#
#federation_timeout = 300

# Federation client idle connection pool timeout (seconds).
#
#federation_idle_timeout = 25

# Federation client max idle connections per host. Defaults to 1 as
# generally the same open connection can be re-used.
#
#federation_idle_per_host = 1

# Federation sender request timeout (seconds). The time it takes for the
# remote server to process sent transactions can take a while.
#
#sender_timeout = 180

# Federation sender idle connection pool timeout (seconds).
#
#sender_idle_timeout = 180

# Federation sender transaction retry backoff limit (seconds).
#
# reloadable: yes
#
#sender_retry_backoff_limit = 86400

# Appservice URL request connection timeout. Defaults to 35 seconds as
# generally appservices are hosted within the same network.
#
#appservice_timeout = 35

# Appservice URL idle connection pool timeout (seconds).
#
#appservice_idle_timeout = 300

# Notification gateway pusher idle connection pool timeout.
#
#pusher_idle_timeout = 15

# Maximum time to receive a request from a client (seconds).
#
#client_receive_timeout = 75

# Maximum time to process a request received from a client (seconds).
#
#client_request_timeout = 240

# Maximum time to transmit a response to a client (seconds)
#
#client_response_timeout = 120

# Grace period for clean shutdown of client requests (seconds).
#
# reloadable: yes
#
#client_shutdown_timeout = 10

# Source of the client IP address for rate limiting, logging, and
# security tooling.
#
# When unset (the default), the `ClientIp` extractor falls back to
# `axum-client-ip`'s `InsecureClientIp` for backward compatibility;
# clients can spoof their address via request headers in that mode.
#
# When set, tuwunel installs `SecureClientIpSource` with the selected
# variant and `ClientIp` resolves exclusively from that source. The
# rightmost value is used for multi-valued headers; only the proxy can
# append to the right, so this is resistant to client spoofing.
#
# Supported values:
# - "connect_info" - TCP peer address only (direct connections)
# - "rightmost_x_forwarded_for" - nginx, Caddy
# - "rightmost_forwarded" - RFC 7239 proxies
# - "x_real_ip" - nginx `X-Real-IP`
# - "cf_connecting_ip" - Cloudflare / cloudflared
# - "true_client_ip" - Akamai, Cloudflare Enterprise
# - "fly_client_ip" - Fly.io
# - "cloudfront_viewer_address" - AWS CloudFront
#
# On Unix-socket deployments, leave this unset rather than setting
# "connect_info"; that source requires a TCP peer address.
#
# WARNING: a header-based value without a trusted reverse proxy in
# front of tuwunel allows clients to forge their IP. Changing this
# value requires a server restart.
#
#ip_source = "connect_info"

# Grace period for clean shutdown of federation requests (seconds).
#
# reloadable: yes
#
#sender_shutdown_timeout = 5

# Enables registration. If set to false, no users can register on this
# server.
#
# If set to true without a token configured, users can register with no
# form of 2nd-step only if you set the following option to true:
# `yes_i_am_very_very_sure_i_want_an_open_registration_server_prone_to_abuse`
#
# If you would like registration only via token reg, please configure
# `registration_token` or `registration_token_file`.
# reloadable: yes
#
#allow_registration = false

# Enabling this setting opens registration to anyone without restrictions.
# This makes your server vulnerable to abuse
# reloadable: yes
#
#yes_i_am_very_very_sure_i_want_an_open_registration_server_prone_to_abuse = false

# A static registration token that new users will have to provide when
# creating an account. If unset and `allow_registration` is true,
# you must set
# `yes_i_am_very_very_sure_i_want_an_open_registration_server_prone_to_abuse`
# to true to allow open registration without any conditions.
#
# YOU NEED TO EDIT THIS OR USE registration_token_file.
#
# reloadable: yes
# example: "o&^uCtes4HPf0Vu@F20jQeeWE7"
#
#registration_token =

# Path to a file on the system that gets read for additional registration
# tokens. Multiple tokens can be added if you separate them with
# whitespace
#
# tuwunel must be able to access the file, and it must not be empty
#
# reloadable: yes
# example: "/etc/tuwunel/.reg_token"
#
#registration_token_file =

# Controls whether encrypted rooms and events are allowed.
# reloadable: yes
#
#allow_encryption = true

# Controls whether locally-created rooms should be end-to-end encrypted by
# default. This option is equivalent to the one found in Synapse.
#
# Options:
# - "all": All created rooms are encrypted.
# - "invite": Any room created with `private_chat` or
#   `trusted_private_chat` presets.
# - "none": Explicit value for no effect.
# - Other values default to no effect.
#
# reloadable: yes
#
#encryption_enabled_by_default_for_room_type = "none"

# Controls whether federation is allowed or not. It is not recommended to
# disable this after installation due to potential federation breakage but
# this is technically not a permanent setting.
#
#allow_federation = true

# Sets the default `m.federate` property for newly created rooms when the
# client does not request one. If `allow_federation` is set to false at
# the same this value is set to false it then always overrides the client
# requested `m.federate` value to false.
#
# Rooms are fixed to the setting at the time of their creation and can
# never be changed; changing this value only affects new rooms.
# reloadable: yes
#
#federate_created_rooms = true

# Allows federation requests to be made to itself
#
# This isn't intended and is very likely a bug if federation requests are
# being sent to yourself. This currently mainly exists for development
# purposes.
# reloadable: yes
#
#federation_loopback = false

# Always calls /forget on behalf of the user if leaving a room. This is a
# part of MSC4267 "Automatically forgetting rooms on leave"
# reloadable: yes
#
#forget_forced_upon_leave = false

# Set this to true to require authentication on the normally
# unauthenticated profile retrieval endpoints (GET)
# "/_matrix/client/v3/profile/{userId}".
#
# This can prevent profile scraping.
# reloadable: yes
#
#require_auth_for_profile_requests = false

# Preserve per-room profile overrides during a global profile update.
#
# When `true` (default), a profile change (displayname or avatar_url)
# arriving via the profile endpoints skips rooms whose current
# `m.room.member` already differs from the user's prior global
# profile. This is the natural behavior users expect after setting a
# per-room nickname or avatar with a client's `/myroomnick`-style
# command: a subsequent global change does not clobber the override.
#
# Set to `false` to always rewrite every joined room's member event
# to match the new global profile. That matches the literal spec
# reading.
#
# MSC4466 lets clients pick this per request via the
# `org.matrix.msc4466.propagate_to` query parameter
# (`all` / `unchanged` / `none`); an explicit value overrides this
# default in either direction.
#
# reloadable: yes
#
#preserve_room_profile_overrides = true

# Set this to true to allow your server's public room directory to be
# federated. Set this to false to protect against /publicRooms spiders,
# but will forbid external users from viewing your server's public room
# directory. If federation is disabled entirely (`allow_federation`), this
# is inherently false.
# reloadable: yes
#
#allow_public_room_directory_over_federation = false

# Set this to true to allow your server's public room directory to be
# queried without client authentication (access token) through the Client
# APIs. Set this to false to protect against /publicRooms spiders.
# reloadable: yes
#
#allow_public_room_directory_without_auth = false

# Allows room directory searches to match on partial room_id's when the
# search term starts with '!'.
#
# reloadable: yes
#
#allow_public_room_search_by_id = true

# Set this to false to limit results of rooms when searching by ID to
# those that would be found by an alias or other query; specifically
# those listed in the public rooms directory. By default this is set to
# true allowing any joinable room to match. This satisfies the Principle
# of Least Expectation when pasting a room_id into a search box with
# intent to join; many rooms simply opt-out of public listings. Therefor
# to prevent this feature from abuse, knowledge of several characters of
# the room_id is required before any results are returned.
#
# reloadable: yes
#
#allow_unlisted_room_search_by_id = true

# Show all local users in user directory. With this set to false, only
# users in public rooms or those that share a room with the user making
# the search will be shown.
#
# reloadable: yes
#
#show_all_local_users_in_user_directory = false

# Allow guests/unauthenticated users to access TURN credentials.
#
# This is the equivalent of Synapse's `turn_allow_guests` config option.
# This allows any unauthenticated user to call the endpoint
# `/_matrix/client/v3/voip/turnServer`.
#
# It is unlikely you need to enable this as all major clients support
# authentication for this endpoint and prevents misuse of your TURN server
# from potential bots.
# reloadable: yes
#
#turn_allow_guests = false

# Set this to true to lock down your server's public room directory and
# only allow admins to publish rooms to the room directory. Unpublishing
# is still allowed by all users with this enabled.
# reloadable: yes
#
#lockdown_public_room_directory = false

# Set this to true to allow federating device display names / allow
# external users to see your device display name. If federation is
# disabled entirely (`allow_federation`), this is inherently false. For
# privacy reasons, this is best left disabled.
# reloadable: yes
#
#allow_device_name_federation = false

# Config option to allow or disallow incoming federation requests that
# obtain the profiles of our local users from
# `/_matrix/federation/v1/query/profile`
#
# Increases privacy of your local user's such as display names, but some
# remote users may get a false "this user does not exist" error when they
# try to invite you to a DM or room. Also can protect against profile
# spiders.
#
# This is inherently false if `allow_federation` is disabled
# reloadable: yes
#
#allow_inbound_profile_lookup_federation_requests = true

# Allow standard users to create rooms. Appservices and admins are always
# allowed to create rooms
# reloadable: yes
#
#allow_room_creation = true

# Set to false to disable users from joining or creating room versions
# that aren't officially supported by tuwunel. Unstable room versions may
# have flawed specifications or our implementation may be non-conforming.
# Correct operation may not be guaranteed, but incorrect operation may be
# tolerable and unnoticed.
#
# tuwunel officially supports room versions 6+. tuwunel has slightly
# experimental (though works fine in practice) support for versions 3 - 5.
#
# reloadable: yes
#
#allow_unstable_room_versions = true

# Set to true to enable experimental room versions.
#
# Unlike unstable room versions these versions are either under
# development, protype spec-changes, or somehow present a serious risk to
# the server's operation or database corruption. This is for developer use
# only.
# reloadable: yes
#
#allow_experimental_room_versions = false

# MSC4284: ask the room's policy server to sign outgoing events. When a
# room has a valid `m.room.policy` state event, the homeserver requests a
# signature from that policy server's federation `/sign` endpoint before
# federating each event. Refusal aborts the local request; network or
# timeout failures fail open with a warn log so a transient policy-server
# outage does not silently take the room offline.
#
# reloadable: yes
#
#enable_policy_servers = false

# MSC4284: timeout (seconds) for requests to a room's policy server.
# Applies to both outbound `/sign` calls and inbound signature-fetches.
#
# reloadable: yes
#
#policy_server_request_timeout = 5

# Default room version tuwunel will create rooms with.
#
# The default is prescribed by the spec, but may be selected by developer
# recommendation. To prevent stale documentation we no longer list it
# here. It is only advised to override this if you know what you are
# doing, and by doing so, updates with new versions are precluded.
# reloadable: yes
#
#default_room_version =

# This item is undocumented. Please contribute documentation for it.
#
#allow_jaeger = false

# This item is undocumented. Please contribute documentation for it.
#
#jaeger_filter = "info"

# If the 'perf_measurements' compile-time feature is enabled, enables
# collecting folded stack trace profile of tracing spans using
# tracing_flame. The resulting profile can be visualized with inferno[1],
# speedscope[2], or a number of other tools.
#
# [1]: https://github.com/jonhoo/inferno
# [2]: www.speedscope.app
#
#tracing_flame = false

# This item is undocumented. Please contribute documentation for it.
#
#tracing_flame_filter = "info"

# This item is undocumented. Please contribute documentation for it.
#
#tracing_flame_output_path = "./tracing.folded"

# Examples:
#
# - No proxy (default):
#
#       proxy = "none"
#
# - For global proxy, create the section at the bottom of this file:
#
#       [global.proxy]
#       global = { url = "socks5h://localhost:9050" }
#
# - To proxy some domains:
#
#       [global.proxy]
#       [[global.proxy.by_domain]]
#       url = "socks5h://localhost:9050"
#       include = ["*.onion", "matrix.myspecial.onion"]
#       exclude = ["*.myspecial.onion"]
#
# Include vs. Exclude:
#
# - If include is an empty list, it is assumed to be `["*"]`.
#
# - If a domain matches both the exclude and include list, the proxy will
#   only be used if it was included because of a more specific rule than
#   it was excluded. In the above example, the proxy would be used for
#   `ordinary.onion`, `matrix.myspecial.onion`, but not
#   `hello.myspecial.onion`.
#
#proxy = "none"

# Servers listed here will be used to gather public keys of other servers
# (notary trusted key servers).
#
# Currently, tuwunel doesn't support inbound batched key requests, so
# this list should only contain other Synapse servers.
#
# reloadable: yes
# example: ["matrix.org", "tchncs.de"]
#
#trusted_servers = ["matrix.org"]

# Whether to query the servers listed in trusted_servers first or query
# the origin server first. For best security, querying the origin server
# first is advised to minimize the exposure to a compromised trusted
# server. For maximum federation/join performance this can be set to true,
# however other options exist to query trusted servers first under
# specific high-load circumstances and should be evaluated before setting
# this to true.
# reloadable: yes
#
#query_trusted_key_servers_first = false

# Whether to query the servers listed in trusted_servers first
# specifically on room joins. This option limits the exposure to a
# compromised trusted server to room joins only. The join operation
# requires gathering keys from many origin servers which can cause
# significant delays. Therefor this defaults to true to mitigate
# unexpected delays out-of-the-box. The security-paranoid or those willing
# to tolerate delays are advised to set this to false. Note that setting
# query_trusted_key_servers_first to true causes this option to be
# ignored.
# reloadable: yes
#
#query_trusted_key_servers_first_on_join = true

# Only query trusted servers for keys and never the origin server. This is
# intended for clusters or custom deployments using their trusted_servers
# as forwarding-agents to cache and deduplicate requests. Notary servers
# do not act as forwarding-agents by default, therefor do not enable this
# unless you know exactly what you are doing.
# reloadable: yes
#
#only_query_trusted_key_servers = false

# Maximum number of keys to request in each trusted server batch query.
#
# reloadable: yes
#
#trusted_server_batch_size = 192

# Maximum number of request batches in flight simultaneously when querying
# a trusted server.
#
# reloadable: yes
#
#trusted_server_batch_concurrency = 2

# Max log level for tuwunel. Allows debug, info, warn, or error.
#
# See also:
# https://docs.rs/tracing-subscriber/latest/tracing_subscriber/filter/struct.EnvFilter.html#directives
#
# **Caveat**:
# For release builds, the tracing crate is configured to only implement
# levels higher than error to avoid unnecessary overhead in the compiled
# binary from trace macros. For debug builds, this restriction is not
# applied.
#
#log = "info"

# Output logs with ANSI colours.
#
#log_colors = true

# Sets the log format to compact mode.
#
#log_compact = false

# Configures the span events which will be outputted with the log.
#
#log_span_events = "none"

# Configures whether TUWUNEL_LOG EnvFilter matches values using regular
# expressions. See the tracing_subscriber documentation on Directives.
#
#log_filter_regex = true

# Toggles the display of ThreadId in tracing log output.
#
#log_thread_ids = false

# Redirects logging to standard error (stderr). The default is false for
# stdout. For those using our systemd features the redirection to stderr
# occurs as necessary and setting this option should not be required. We
# offer this option for all other users who desire such redirection.
#
#log_to_stderr = false

# Setting to false disables the logging/tracing system at a lower level.
# In contrast to configuring an empty `log` string where the system is
# still operating but muted, when this option is false the system was not
# initialized and is not operating. Changing this option has no effect
# after startup. This option is intended for developers and expert use
# only: configuring an empty log string is preferred over using this.
#
#log_enable = true

# Setting to false disables the logging/tracing system at a lower level
# similar to `log_enable`. In this case the system is configured normally,
# but not registered as the global handler in the final steps. This option
# is for developers and expert use only.
#
#log_global_default = true

# OpenID token expiration/TTL in seconds.
#
# These are the OpenID tokens that are primarily used for Matrix account
# integrations (e.g. Vector Integrations in Element), *not* OIDC/OpenID
# Connect/etc.
#
# reloadable: yes
#
#openid_token_ttl = 3600

# Allow an existing session to mint a login token for another client.
# This requires interactive authentication, but has security ramifications
# as a malicious client could use the mechanism to spawn more than one
# session. Enabled by default.
#
# reloadable: yes
#
#login_via_existing_session = true

# Whether to enable the login token route to accept login tokens at all.
# Login tokens may be generated by the server for authorization flows such
# as SSO; disabling tokens may break such features.
#
# This option is distinct from `login_via_existing_session` and does not
# carry the same security implications; the intent is to leave this
# enabled while disabling the former to prevent clients from commanding
# login token creation but without preventing the server from doing so.
#
# reloadable: yes
#
#login_via_token = true

# Whether to enable login using traditional user/password authorization
# flow.
#
# Set this option to false if you intend to allow logging in only using
# other mechanisms, such as SSO.
#
# reloadable: yes
#
#login_with_password = true

# Login token expiration/TTL in milliseconds.
#
# These are short-lived tokens for the m.login.token endpoint.
# This is used to allow existing sessions to create new sessions.
# see login_via_existing_session.
#
# reloadable: yes
#
#login_token_ttl = 120000

# Access token TTL in seconds.
#
# For clients that support refresh-tokens, the access-token provided on
# login will be invalidated after this amount of time and the client will
# be soft-logged-out until refreshing it.
#
# reloadable: yes
#
#access_token_ttl = 604800

# Refresh token TTL in seconds.
#
# Refresh tokens are rejected once this lifetime elapses. Whether the
# deadline slides forward on each use or stays fixed at issuance is
# controlled by `refresh_token_idle_only`. The default of `0` disables
# refresh-token expiry entirely; a typical enabled value is `259200`
# (three days).
#
# reloadable: yes
#
#refresh_token_ttl = 0

# Whether `refresh_token_ttl` acts as an idle timeout or an absolute
# session lifetime.
#
# When `true` (default), each successful refresh resets the deadline to
# `now + refresh_token_ttl`. A session in continuous use never expires.
# When `false`, the deadline is fixed at first issuance and rotation
# carries it forward, forcing re-auth after `refresh_token_ttl`
# regardless of activity.
#
# reloadable: yes
#
#refresh_token_idle_only = true

# Whether refresh-token expiry triggers a hard logout instead of a soft
# one.
#
# When `false` (default), an expired refresh token is rejected with
# `M_UNKNOWN_TOKEN` carrying `soft_logout: true`. The client can preserve
# E2EE keys and local state, then re-authenticate to resume the same
# device.
#
# When `true`, the device is removed entirely on expiry: the access
# token is invalidated, the device record is deleted, and the client is
# signalled with `soft_logout: false`. The next session is a brand-new
# device, so the client cannot recover E2EE history from local state
# alone; this is the CWE-613 stance and trades usability for that
# guarantee.
#
# reloadable: yes
#
#refresh_token_hard_logout = false

# Static TURN username to provide the client if not using a shared secret
# ("turn_secret"), It is recommended to use a shared secret over static
# credentials.
# reloadable: yes
#
#turn_username = false

# Static TURN password to provide the client if not using a shared secret
# ("turn_secret"). It is recommended to use a shared secret over static
# credentials.
#
# reloadable: yes
#
#turn_password = false

# Vector list of TURN URIs/servers to use.
#
# Replace "example.turn.uri" with your TURN domain, such as the coturn
# "realm" config option. If using TURN over TLS, replace the URI prefix
# "turn:" with "turns:".
#
# reloadable: yes
# example: ["turn:example.turn.uri?transport=udp",
# "turn:example.turn.uri?transport=tcp"]
#
#turn_uris = []

# TURN secret to use for generating the HMAC-SHA1 hash apart of username
# and password generation.
#
# This is more secure, but if needed you can use traditional static
# username/password credentials.
#
#turn_secret = false

# TURN secret to use that's read from the file path specified.
#
# This takes priority over "turn_secret" first, and falls back to
# "turn_secret" if invalid or failed to open.
#
# example: "/etc/tuwunel/.turn_secret"
#
#turn_secret_file =

# TURN TTL, in seconds.
#
# reloadable: yes
#
#turn_ttl = 86400

# List/vector of room IDs or room aliases that tuwunel will make newly
# registered users join. The rooms specified must be rooms that you have
# joined at least once on the server, and must be public.
#
# reloadable: yes
# example: ["#tuwunel:grin.hu",
# "!l2xV0sd51lraysuRcsWVECge4NULaH3g-ou95vgDgiM"]
#
#auto_join_rooms = []

# Config option to automatically deactivate the account of any user who
# attempts to join a:
# - banned room
# - forbidden room alias
# - room alias or ID with a forbidden server name
#
# This may be useful if all your banned lists consist of toxic rooms or
# servers that no good faith user would ever attempt to join, and
# to automatically remediate the problem without any admin user
# intervention.
#
# This will also make the user leave all rooms. Federation (e.g. remote
# room invites) are ignored here.
#
# Defaults to false as rooms can be banned for non-moderation-related
# reasons and this performs a full user deactivation.
# reloadable: yes
#
#auto_deactivate_banned_room_attempts = false

# RocksDB log level. This is not the same as tuwunel's log level. This
# is the log level for the RocksDB engine/library which show up in your
# database folder/path as `LOG` files. tuwunel will log RocksDB errors
# as normal through tracing or panics if severe for safety.
#
#rocksdb_log_level = "error"

# This item is undocumented. Please contribute documentation for it.
#
#rocksdb_log_stderr = false

# Max RocksDB `LOG` file size before rotating. Accepts an integer byte
# count or a string with SI/IEC suffix such as "4 MiB".
#
#rocksdb_max_log_file_size = 4194304

# Time in seconds before RocksDB will forcibly rotate logs.
#
#rocksdb_log_time_to_roll = 0

# Use RocksDB tunings tailored to spinning disks (HDDs). On NVMe or SSD
# storage, leave this disabled.
#
# When enabled, RocksDB skips compaction readahead and parallel file-open
# threads at startup. This option does not affect Direct IO; for that, see
# `rocksdb_direct_io`.
#
#rocksdb_optimize_for_spinning_disks = false

# Enables direct-io to increase database performance via unbuffered I/O.
#
# For more details about direct I/O and RockDB, see:
# https://github.com/facebook/rocksdb/wiki/Direct-IO
#
# Set this option to false if the database resides on a filesystem which
# does not support direct-io like FUSE, or any form of complex filesystem
# setup such as possibly ZFS.
#
#rocksdb_direct_io = true

# Amount of threads that RocksDB will use for parallelism on database
# operations such as cleanup, sync, flush, compaction, etc. Set to 0 to
# use all your logical threads. Defaults to your CPU logical thread count.
#
#rocksdb_parallelism_threads = varies by system

# Maximum number of LOG files RocksDB will keep. This must *not* be set to
# 0. It must be at least 1. Defaults to 3 as these are not very useful
# unless troubleshooting/debugging a RocksDB bug.
#
#rocksdb_max_log_files = 3

# Type of RocksDB database compression to use.
#
# Available options are "zstd", "bz2", "lz4", or "none".
#
# It is best to use ZSTD as an overall good balance between
# speed/performance, storage, IO amplification, and CPU usage. For more
# performance but less compression (more storage used) and less CPU usage,
# use LZ4.
#
# For more details, see:
# https://github.com/facebook/rocksdb/wiki/Compression
#
# "none" will disable compression.
#
#rocksdb_compression_algo = "zstd"

# Level of compression the specified compression algorithm for RocksDB to
# use.
#
# Default is 32767, which is internally read by RocksDB as the default
# magic number and translated to the library's default compression level
# as they all differ. See their `kDefaultCompressionLevel`.
#
# Note when using the default value we may override it with a setting
# tailored specifically tuwunel.
#
#rocksdb_compression_level = 32767

# Level of compression the specified compression algorithm for the
# bottommost level/data for RocksDB to use. Default is 32767, which is
# internally read by RocksDB as the default magic number and translated to
# the library's default compression level as they all differ. See their
# `kDefaultCompressionLevel`.
#
# Since this is the bottommost level (generally old and least used data),
# it may be desirable to have a very high compression level here as it's
# less likely for this data to be used. Research your chosen compression
# algorithm.
#
# Note when using the default value we may override it with a setting
# tailored specifically tuwunel.
#
#rocksdb_bottommost_compression_level = 32767

# Whether to enable RocksDB's "bottommost_compression".
#
# At the expense of more CPU usage, this will further compress the
# database to reduce more storage. It is recommended to use ZSTD
# compression with this for best compression results. This may be useful
# if you're trying to reduce storage usage from the database.
#
# See https://github.com/facebook/rocksdb/wiki/Compression for more details.
#
#rocksdb_bottommost_compression = true

# Database recovery mode (for RocksDB WAL corruption).
#
# Use this option when the server reports corruption and refuses to start.
# Set mode 2 (PointInTime) to cleanly recover from this corruption. The
# server will continue from the last good state, several seconds or
# minutes prior to the crash. Clients may have to run "clear-cache &
# reload" to account for the rollback. Upon success, you may reset the
# mode back to default and restart again. Please note in some cases the
# corruption error may not be cleared for at least 30 minutes of operation
# in PointInTime mode.
#
# As a very last ditch effort, if PointInTime does not fix or resolve
# anything, you can try mode 3 (SkipAnyCorruptedRecord) but this will
# leave the server in a potentially inconsistent state.
#
# The default mode 1 (TolerateCorruptedTailRecords) will automatically
# drop the last entry in the database if corrupted during shutdown, but
# nothing more. It is extraordinarily unlikely this will desynchronize
# clients. To disable any form of silent rollback set mode 0
# (AbsoluteConsistency).
#
# The options are:
# 0 = AbsoluteConsistency
# 1 = TolerateCorruptedTailRecords (default)
# 2 = PointInTime (use me if trying to recover)
# 3 = SkipAnyCorruptedRecord (you now voided your tuwunel warranty)
#
# For more information on these modes, see:
# https://github.com/facebook/rocksdb/wiki/WAL-Recovery-Modes
#
# For more details on recovering a corrupt database, see:
# https://tuwunel.chat/troubleshooting.html#database-corruption
#
#rocksdb_recovery_mode = 1

# Enables or disables paranoid SST file checks. This can improve RocksDB
# database consistency at a potential performance impact due to further
# safety checks ran.
#
# For more information, see:
# https://github.com/facebook/rocksdb/wiki/Online-Verification#columnfamilyoptionsparanoid_file_checks
#
#rocksdb_paranoid_file_checks = false

# Enables or disables checksum verification in rocksdb at runtime.
# Checksums are usually hardware accelerated with low overhead; they are
# enabled in rocksdb by default. Older or slower platforms may see gains
# from disabling.
#
#rocksdb_checksums = true

# Enables the "atomic flush" mode in rocksdb. This option is not intended
# for users. It may be removed or ignored in future versions. Atomic flush
# may be enabled by the paranoid to possibly improve database integrity at
# the cost of performance.
#
#rocksdb_atomic_flush = false

# Database repair mode (for RocksDB SST corruption).
#
# Use this option when the server reports corruption while running or
# panics. If the server refuses to start use the recovery mode options
# first. Corruption errors containing the acronym 'SST' which occur after
# startup will likely require this option.
#
# - Backing up your database directory is recommended prior to running the
#   repair.
#
# - Disabling repair mode and restarting the server is recommended after
#   running the repair.
#
# See https://tuwunel.chat/troubleshooting.html#database-corruption for more details on recovering a corrupt database.
#
#rocksdb_repair = false

# This item is undocumented. Please contribute documentation for it.
#
#rocksdb_read_only = false

# This item is undocumented. Please contribute documentation for it.
#
#rocksdb_secondary = false

# Enables idle CPU priority for compaction thread. This is not enabled by
# default to prevent compaction from falling too far behind on busy
# systems.
#
#rocksdb_compaction_prio_idle = false

# Enables idle IO priority for compaction thread. This prevents any
# unexpected lag in the server's operation and is usually a good idea.
# Enabled by default.
#
#rocksdb_compaction_ioprio_idle = true

# Enables RocksDB compaction. You should never ever have to set this
# option to false. If you for some reason find yourself needing to use
# this option as part of troubleshooting or a bug, please reach out to us
# in the tuwunel Matrix room with information and details.
#
# Disabling compaction will lead to a significantly bloated and
# explosively large database, gradually poor performance, unnecessarily
# excessive disk read/writes, and slower shutdowns and startups.
#
#rocksdb_compaction = true

# Level of statistics collection. Some admin commands to display database
# statistics may require this option to be set. Database performance may
# be impacted by higher settings.
#
# Option is a number ranging from 0 to 6:
# 0 = No statistics.
# 1 = No statistics in release mode (default).
# 2 to 3 = Statistics with no performance impact.
# 3 to 5 = Statistics with possible performance impact.
# 6 = All statistics.
#
#rocksdb_stats_level = 1

# Ignores the list of dropped columns set by developers.
#
# This should be set to true when knowingly moving between versions in
# ways which are not recommended or otherwise forbidden, or for
# diagnostic and development purposes; requiring preservation across such
# movements.
#
# The developer's list of dropped columns is meant to safely reduce space
# by erasing data no longer in use. If this is set to true that storage
# will not be reclaimed as intended.
#
#rocksdb_never_drop_columns = false

# Configures RocksDB to not preallocate WAL logs.
#
# Normally, RocksDB allocates certain types of files by calling
# fallocate, writing the file contents, then truncating the logs to the
# proper size. This causes pathological disk space usage on btrfs due to
# how it interacts with its Copy-on-Write implementation. On ZFS,
# fallocate(2) for preallocation is unsupported and returns EOPNOTSUPP;
# only `FALLOC_FL_PUNCH_HOLE` and `FALLOC_FL_ZERO_RANGE` are implemented.
#
# Set this to false if you run the server on btrfs or ZFS, and do not
# touch it otherwise.
#
#rocksdb_allow_fallocate = true

# This is a password that can be configured that will let you login to the
# server bot account (currently `@conduit`) for emergency troubleshooting
# purposes such as recovering/recreating your admin room, or inviting
# yourself back.
#
# See https://tuwunel.chat/troubleshooting.html#lost-access-to-admin-room
# for other ways to get back into your admin room.
#
# Once this password is unset, all sessions will be logged out for
# security purposes.
#
# example: "F670$2CP@Hw8mG7RY1$%!#Ic7YA"
#
#emergency_password =

# This item is undocumented. Please contribute documentation for it.
# reloadable: yes
#
#notification_push_path = "/_matrix/push/v1/notify"

# For compatibility and special purpose use only. Setting this option to
# true will not filter messages sent to pushers based on rules or actions.
# Everything will be sent to the pusher. This option is offered for
# several reasons, but should not be necessary:
# - Bypass to workaround bugs or outdated server-side ruleset support.
# - Allow clients to evaluate pushrules themselves (due to the above).
# - Hosting or companies which have custom pushers and internal needs.
#
# Note that setting this option to true will not affect the record of
# notifications found in the notifications pane.
# reloadable: yes
#
#push_everything = false

# Setting to false disables the heroes calculation made by sliding and
# legacy client sync. The heroes calculation is mandated by the Matrix
# specification and your client may not operate properly unless this
# option is set to true.
#
# This option is intended for custom software deployments seeking purely
# to minimize unused resources; the overall savings are otherwise
# negligible.
# reloadable: yes
#
#calculate_heroes = true

# Allow local (your server only) presence updates/requests.
#
# Note that presence on tuwunel is very fast unlike Synapse's. If using
# outgoing presence, this MUST be enabled.
# reloadable: yes
#
#allow_local_presence = true

# Allow incoming federated presence updates/requests.
#
# This option receives presence updates from other servers, but does not
# send any unless `allow_outgoing_presence` is true. Note that presence on
# tuwunel is very fast unlike Synapse's.
# reloadable: yes
#
#allow_incoming_presence = true

# Allow outgoing presence updates/requests.
#
# This option sends presence updates to other servers, but does not
# receive any unless `allow_incoming_presence` is true. Note that presence
# on tuwunel is very fast unlike Synapse's. If using outgoing presence,
# you MUST enable `allow_local_presence` as well.
# reloadable: yes
#
#allow_outgoing_presence = true

# How many seconds without presence updates before you become idle.
# Defaults to 5 minutes.
#
#presence_idle_timeout_s = 300

# How many seconds without presence updates before you become offline.
# Defaults to 30 minutes.
#
#presence_offline_timeout_s = 1800

# Enable the presence idle timer for remote users.
#
# Disabling is offered as an optimization for servers participating in
# many large rooms or when resources are limited. Disabling it may cause
# incorrect presence states (i.e. stuck online) to be seen for some remote
# users.
#
#presence_timeout_remote_users = true

# Suppresses push notifications for users marked as active. (Experimental)
#
# When enabled, users with `Online` presence and recent activity
# (based on presence state and sync activity) won’t receive push
# notifications, reducing duplicate alerts while they're active
# on another client.
#
# Disabled by default to preserve legacy behavior.
# reloadable: yes
#
#suppress_push_when_active = false

# Allow receiving incoming read receipts from remote servers.
# reloadable: yes
#
#allow_incoming_read_receipts = true

# Allow sending read receipts to remote servers.
# reloadable: yes
#
#allow_outgoing_read_receipts = true

# Allow outgoing typing updates to federation.
# reloadable: yes
#
#allow_outgoing_typing = true

# Allow incoming typing updates from federation.
# reloadable: yes
#
#allow_incoming_typing = true

# Maximum time federation user can indicate typing.
#
# reloadable: yes
#
#typing_federation_timeout_s = 30

# Minimum time local client can indicate typing. This does not override a
# client's request to stop typing. It only enforces a minimum value in
# case of no stop request.
#
# reloadable: yes
#
#typing_client_timeout_min_s = 15

# Maximum time local client can indicate typing.
#
# reloadable: yes
#
#typing_client_timeout_max_s = 45

# Set this to true for tuwunel to compress HTTP response bodies using
# zstd. This option does nothing if tuwunel was not built with
# `zstd_compression` feature. Please be aware that enabling HTTP
# compression may weaken TLS. Most users should not need to enable this.
# See https://breachattack.com/ and https://wikipedia.org/wiki/BREACH
# before deciding to enable this.
#
#zstd_compression = false

# Set this to true for tuwunel to compress HTTP response bodies using
# gzip. This option does nothing if tuwunel was not built with
# `gzip_compression` feature. Please be aware that enabling HTTP
# compression may weaken TLS. Most users should not need to enable this.
# See https://breachattack.com/ and https://wikipedia.org/wiki/BREACH before
# deciding to enable this.
#
# If you are in a large amount of rooms, you may find that enabling this
# is necessary to reduce the significantly large response bodies.
#
#gzip_compression = false

# Set this to true for tuwunel to compress HTTP response bodies using
# brotli. This option does nothing if tuwunel was not built with
# `brotli_compression` feature. Please be aware that enabling HTTP
# compression may weaken TLS. Most users should not need to enable this.
# See https://breachattack.com/ and https://wikipedia.org/wiki/BREACH
# before deciding to enable this.
#
#brotli_compression = false

# Set to true to allow user type "guest" registrations. Some clients like
# Element attempt to register guest users automatically.
# reloadable: yes
#
#allow_guest_registration = false

# Set to true to log guest registrations in the admin room. Note that
# these may be noisy or unnecessary if you're a public homeserver.
# reloadable: yes
#
#log_guest_registrations = false

# Set to true to allow guest registrations/users to auto join any rooms
# specified in `auto_join_rooms`.
# reloadable: yes
#
#allow_guests_auto_join_rooms = false

# Enable the legacy unauthenticated Matrix media repository endpoints.
# These endpoints consist of:
# - /_matrix/media/*/config
# - /_matrix/media/*/upload
# - /_matrix/media/*/preview_url
# - /_matrix/media/*/download/*
# - /_matrix/media/*/thumbnail/*
#
# The authenticated equivalent endpoints are always enabled.
#
# Defaults to false.
#
#allow_legacy_media = false

# Fallback to requesting legacy unauthenticated media from remote servers.
# Unauthenticated media was removed in ~2024Q3; enabling this adds
# considerable federation requests which are unlikely to succeed.
# reloadable: yes
#
#request_legacy_media = false

# This item is undocumented. Please contribute documentation for it.
# reloadable: yes
#
#freeze_legacy_media = true

# Check consistency of the media directory at startup:
# 1. When `media_compat_file_link` is enabled, this check will upgrade
#    media when switching back and forth between Conduit and tuwunel. Both
#    options must be enabled to handle this.
# 2. When media is deleted from the directory, this check will also delete
#    its database entry.
#
# If none of these checks apply to your use cases, and your media
# directory is significantly large setting this to false may reduce
# startup time.
#
#media_startup_check = true

# Enable backward-compatibility with Conduit's media directory by creating
# symlinks of media.
#
# This option is only necessary if you plan on using Conduit again.
# Otherwise setting this to false reduces filesystem clutter and overhead
# for managing these symlinks in the directory. This is now disabled by
# default. You may still return to upstream Conduit but you have to run
# tuwunel at least once with this set to true and allow the
# media_startup_check to take place before shutting down to return to
# Conduit.
#
#media_compat_file_link = false

# Prune missing media from the database as part of the media startup
# checks.
#
# This means if you delete files from the media directory the
# corresponding entries will be removed from the database. This is
# disabled by default because if the media directory is accidentally moved
# or inaccessible, the metadata entries in the database will be lost with
# sadness.
#
#prune_missing_media = false

# List of storage providers to use for media. Providers can be configured
# below in respective sections designated by
# `global.storage_provider.<NAME>.<brand>` where `NAME` can be listed
# here.
#
# For advanced features and future extensions involving multiple providers
# the list may contain multiple entries. You MUST take note of other
# configuration options when listing multiple providers or resource
# duplication costs and poor performance can result.
#
# The list defaults to `["media"]` which is an implicit storage provider
# representing the media directory on the local filesystem. It can be
# altered by configuring `global.storage_provider.media.local` explicitly
# or disabled by omitting it from this list entirely. Users with existing
# deployments are advised to continue listing "media" as a fallback along
# with their new provider.
#
# reloadable: yes
#
#media_storage_providers = ["media"]

# List of configured storage providers where new media will be sent. When
# this list is not explicitly configured all entries in
# `media_storage_providers` are used as default.
#
# This list is important for users passively migrating to a new media
# storage provider by only writing to one while querying the other as a
# fallback.
#
# For example:
#
# `media_storage_providers = ["media", "media_on_s3"]`
# `store_media_on_providers = ["media_on_s3"]`
#
# Entries in this list must also be listed in `media_storage_providers`.
#
# reloadable: yes
#
#store_media_on_providers = []

# Vector list of regex patterns of server names that tuwunel will refuse
# to download remote media from.
#
# reloadable: yes
# example: ["badserver\.tld$", "badphrase", "19dollarfortnitecards"]
#
#prevent_media_downloads_from = []

# List of forbidden server names via regex patterns that we will block
# incoming AND outgoing federation with, and block client room joins /
# remote user invites.
#
# This check is applied on the room ID, room alias, sender server name,
# sender user's server name, inbound federation X-Matrix origin, and
# outbound federation handler.
#
# Basically "global" ACLs.
#
# reloadable: yes
# example: ["badserver\.tld$", "badphrase", "19dollarfortnitecards"]
#
#forbidden_remote_server_names = []

# (EXPERIMENTAL) The behavior of this option will change; the
# _experimental suffix will be removed for that change in an upcoming
# release.
#
# List of allowed server names via regex patterns. This is an allow-list
# rather than a deny-list with all the same details as its counterpart in
# `forbidden_remote_server_names`.
#
# This feature becomes active when this list has one or more entries;
# everything not matching is denied. By default it is empty and inactive.
#
# Entries in `forbidden_remote_server_names` are still applied after
# this is applied. This allows you to match e.g. "*\.example\.com" here
# while still singling out "bad\.example\.com" for exclusion.
#
# reloadable: yes
# example: ["badserver\.tld$", "badphrase", "19dollarfortnitecards"]
#
#allowed_remote_server_names_experimental = []

# List of forbidden server names via regex patterns that we will block all
# outgoing federated room directory requests for. Useful for preventing
# our users from wandering into bad servers or spaces.
#
# reloadable: yes
# example: ["badserver\.tld$", "badphrase", "19dollarfortnitecards"]
#
#forbidden_remote_room_directory_server_names = []

# Vector list of IPv4 and IPv6 CIDR ranges / subnets *in quotes* that you
# do not want tuwunel to send outbound requests to. Defaults to
# RFC1918, unroutable, loopback, multicast, and testnet addresses for
# security.
#
# Please be aware that this is *not* a guarantee. You should be using a
# firewall with zones as doing this on the application layer may have
# bypasses.
#
# Currently this does not account for proxies in use like Synapse does.
#
# To disable, set this to be an empty vector (`[]`).
#
# Defaults to:
# ["127.0.0.0/8", "10.0.0.0/8", "172.16.0.0/12",
# "192.168.0.0/16", "100.64.0.0/10", "192.0.0.0/24", "169.254.0.0/16",
# "192.88.99.0/24", "198.18.0.0/15", "192.0.2.0/24", "198.51.100.0/24",
# "203.0.113.0/24", "224.0.0.0/4", "::1/128", "fe80::/10", "fc00::/7",
# "2001:db8::/32", "ff00::/8", "fec0::/10"]
#
#ip_range_denylist =

# Optional IP address or network interface-name to bind as the source of
# URL preview requests. If not set, it will not bind to a specific
# address or interface.
#
# Interface names only supported on Linux, Android, and Fuchsia platforms;
# all other platforms can specify the IP address. To list the interfaces
# on your system, use the command `ip link show`.
#
# example: `"eth0"` or `"1.2.3.4"`
#
#url_preview_bound_interface =

# Vector list of domains allowed to send requests to for URL previews.
#
# This is a *contains* match, not an explicit match. Putting "google.com"
# will match "https://google.com" and
# "http://mymaliciousdomainexamplegoogle.com" Setting this to "*" will
# allow all URL previews. Please note that this opens up significant
# attack surface to your server, you are expected to be aware of the risks
# by doing so.
#
# reloadable: yes
#
#url_preview_domain_contains_allowlist = []

# Vector list of explicit domains allowed to send requests to for URL
# previews.
#
# This is an *explicit* match, not a contains match. Putting "google.com"
# will match "https://google.com", "http://google.com", but not
# "https://mymaliciousdomainexamplegoogle.com". Setting this to "*" will
# allow all URL previews. Please note that this opens up significant
# attack surface to your server, you are expected to be aware of the risks
# by doing so.
#
# reloadable: yes
#
#url_preview_domain_explicit_allowlist = []

# Vector list of explicit domains not allowed to send requests to for URL
# previews.
#
# This is an *explicit* match, not a contains match. Putting "google.com"
# will match "https://google.com", "http://google.com", but not
# "https://mymaliciousdomainexamplegoogle.com". The denylist is checked
# first before allowlist. Setting this to "*" will not do anything.
#
# reloadable: yes
#
#url_preview_domain_explicit_denylist = []

# Vector list of URLs allowed to send requests to for URL previews.
#
# Note that this is a *contains* match, not an explicit match. Putting
# "google.com" will match "https://google.com/",
# "https://google.com/url?q=https://mymaliciousdomainexample.com", and
# "https://mymaliciousdomainexample.com/hi/google.com" Setting this to "*"
# will allow all URL previews. Please note that this opens up significant
# attack surface to your server, you are expected to be aware of the risks
# by doing so.
#
# reloadable: yes
#
#url_preview_url_contains_allowlist = []

# Maximum body size allowed when spidering a URL for previews. Accepts an
# integer byte count or a string with SI/IEC suffix such as "256 KB".
#
# reloadable: yes
#
#url_preview_max_spider_size = 256000

# Option to decide whether you would like to run the domain allowlist
# checks (contains and explicit) on the root domain or not. Does not apply
# to URL contains allowlist. Defaults to false.
#
# Example usecase: If this is enabled and you have "wikipedia.org" allowed
# in the explicit and/or contains domain allowlist, it will allow all
# subdomains under "wikipedia.org" such as "en.m.wikipedia.org" as the
# root domain is checked and matched. Useful if the domain contains
# allowlist is still too broad for you but you still want to allow all the
# subdomains under a root domain.
# reloadable: yes
#
#url_preview_check_root_domain = false

# List of forbidden room aliases and room IDs as strings of regex
# patterns.
#
# Regex can be used or explicit contains matches can be done by just
# specifying the words (see example).
#
# This is checked upon room alias creation, custom room ID creation if
# used, and startup as warnings if any room aliases in your database have
# a forbidden room alias/ID.
#
# reloadable: yes
# example: ["19dollarfortnitecards", "b[4a]droom", "badphrase"]
#
#forbidden_alias_names = []

# List of forbidden username patterns/strings.
#
# Regex can be used or explicit contains matches can be done by just
# specifying the words (see example).
#
# This is checked upon username availability check, registration, and
# startup as warnings if any local users in your database have a forbidden
# username.
#
# reloadable: yes
# example: ["administrator", "b[a4]dusernam[3e]", "badphrase"]
#
#forbidden_usernames = []

# List of server names to deprioritize joining through.
#
# If a client requests a join through one of these servers,
# they will be tried last.
#
# Useful for preventing failed joins due to timeouts
# from a certain homeserver.
#
# reloadable: yes
#
#deprioritize_joins_through_servers = ["matrix\.org"]

# Maximum make_join requests to attempt within each join attempt. Each
# attempt tries a different server, as each server is only tried once;
# though retries can occur when the join request as a whole is retried.
#
# reloadable: yes
#
#max_make_join_attempts_per_join_attempt = 48

# Maximum join attempts to conduct per client join request. Each join
# attempt consists of one or more make_join requests limited above, and a
# single send_join request. This value allows for additional servers to
# act as the join-server prior to reporting the last error back to the
# client, which can be frustrating for users. Therefor the default value
# is greater than one, but less than excessively exceeding the client's
# request timeout, though that may not be avoidable in some cases.
#
# reloadable: yes
#
#max_join_attempts_per_join_request = 3

# Retry failed and incomplete messages to remote servers immediately upon
# startup. This is called bursting. If this is disabled, said messages may
# not be delivered until more messages are queued for that server. Do not
# change this option unless server resources are extremely limited or the
# scale of the server's deployment is huge. Do not disable this unless you
# know what you are doing.
#
#startup_netburst = true

# Messages are dropped and not reattempted. The `startup_netburst` option
# must be enabled for this value to have any effect. Do not change this
# value unless you know what you are doing. Set this value to -1 to
# reattempt every message without trimming the queues; this may consume
# significant disk. Set this value to 0 to drop all messages without any
# attempt at redelivery.
#
#startup_netburst_keep = 50

# Block non-admin local users from sending room invites (local and
# remote), and block non-admin users from receiving remote room invites.
#
# Admins are always allowed to send and receive all room invites.
# reloadable: yes
#
#block_non_admin_invites = false

# Allow admins to enter commands in rooms other than "#admins" (admin
# room) by prefixing your message with "\!admin" or "\\!admin" followed up
# a normal tuwunel admin command. The reply will be publicly visible to
# the room, originating from the sender.
#
# reloadable: yes
# example: \\!admin debug ping puppygock.gay
#
#admin_escape_commands = true

# Automatically activate the tuwunel admin room console / CLI on
# startup. This option can also be enabled with `--console` tuwunel
# argument.
#
#admin_console_automatic = false

# List of admin commands to execute on startup.
#
# This option can also be configured with the `--execute` tuwunel
# argument and can take standard shell commands and environment variables
#
# For example: `./tuwunel --execute "server admin-notice tuwunel has
# started up at $(date)"`
#
# example: admin_execute = ["debug ping puppygock.gay", "debug echo hi"]`
#
#admin_execute = []

# Ignore errors in startup commands.
#
# If false, tuwunel will error and fail to start if an admin execute
# command (`--execute` / `admin_execute`) fails.
# reloadable: yes
#
#admin_execute_errors_ignore = false

# List of admin commands to execute on SIGUSR2.
#
# Similar to admin_execute, but these commands are executed when the
# server receives SIGUSR2 on supporting platforms.
#
# reloadable: yes
#
#admin_signal_execute = []

# Controls the max log level for admin command log captures (logs
# generated from running admin commands). Defaults to "info" on release
# builds, else "debug" on debug builds.
#
# reloadable: yes
#
#admin_log_capture = "info"

# The default room tag to apply on the admin room.
#
# On some clients like Element, the room tag "m.server_notice" is a
# special pinned room at the very bottom of your room list. The tuwunel
# admin room can be pinned here so you always have an easy-to-access
# shortcut dedicated to your admin room.
#
# reloadable: yes
#
#admin_room_tag = "m.server_notice"

# Whether to grant the first user to register admin privileges by joining
# them to the admin room. Note that technically the next user to register
# when the admin room is empty (or only contains the server-user) is
# granted, and only when the admin room is enabled.
#
# reloadable: yes
#
#grant_admin_to_first_user = true

# Whether the admin room is created on first startup. Users should not set
# this to false. Developers can set this to false during integration tests
# to reduce activity and output.
#
#create_admin_room = true

# Whether to enable federation on the admin room. This cannot be changed
# after the admin room is created.
#
#federate_admin_room = true

# Sentry.io crash/panic reporting, performance monitoring/metrics, etc.
# This is NOT enabled by default. tuwunel's default Sentry reporting
# endpoint domain is `o4509498990067712.ingest.us.sentry.io`.
#
#sentry = false

# Sentry reporting URL, if a custom one is desired.
#
#sentry_endpoint = ""

# Report your tuwunel server_name in Sentry.io crash reports and
# metrics.
#
#sentry_send_server_name = false

# Performance monitoring/tracing sample rate for Sentry.io.
#
# Note that too high values may impact performance, and can be disabled by
# setting it to 0.0 (0%) This value is read as a percentage to Sentry,
# represented as a decimal. Defaults to 15% of traces (0.15)
#
#sentry_traces_sample_rate = 0.15

# Whether to attach a stacktrace to Sentry reports.
#
#sentry_attach_stacktrace = false

# Send panics to Sentry. This is true by default, but Sentry has to be
# enabled. The global `sentry` config option must be enabled to send any
# data.
#
#sentry_send_panic = true

# Send errors to sentry. This is true by default, but sentry has to be
# enabled. This option is only effective in release-mode; forced to false
# in debug-mode.
#
#sentry_send_error = true

# Controls the tracing log level for Sentry to send things like
# breadcrumbs and transactions
#
#sentry_filter = "info"

# Enable the tokio-console. This option is only relevant to developers.
#
#	For more information, see:
# https://tuwunel.chat/development.html#debugging-with-tokio-console
#
#tokio_console = false

# Arbitrary argument vector for integration testing. Functionality in the
# server is altered or informed for the requirements of integration tests.
# - "smoke" performs a shutdown after startup admin commands rather than
#   hanging on client handling.
#
#test = false

# Indicates the server has started in maintenance mode. Historically
# maintenance mode has been enabled by the command line argument
# `--maintenance` which then sets various configuration items such as
# `listening=false` among others. That is still the case. This option was
# only added as a single source of truth that `--maintenance` mode is
# active.
#
# This option must never be set manually.
#
#maintenance = false

# Controls whether admin room notices like account registrations, password
# changes, account deactivations, room directory publications, etc will be
# sent to the admin room. Update notices and normal admin command
# responses will still be sent.
# reloadable: yes
#
#admin_room_notices = true

# Save original events before applying redaction to them.
#
# They can be retrieved with `admin debug get-retained-pdu` or MSC2815.
#
# reloadable: yes
#
#save_unredacted_events = true

# Redaction retention period in seconds.
#
# By default the unredacted events are stored for 60 days.
#
# reloadable: yes
#
#redaction_retention_seconds = 5184000

# Allows users with `redact` power level to request unredacted events with
# MSC2815.
#
# Server admins can request unredacted events regardless of the value of
# this option.
#
# reloadable: yes
#
#allow_room_admins_to_request_unredacted_events = true

# Prevents local users from sending redactions.
#
# This check does not apply to server admins.
# reloadable: yes
#
#disable_local_redactions = false

# Enable database pool affinity support. On supporting systems, block
# device queue topologies are detected and the request pool is optimized
# for the hardware; db_pool_workers is determined automatically.
#
#db_pool_affinity = true

# Sets the number of worker threads in the frontend-pool of the database.
# This number should reflect the I/O capabilities of the system,
# such as the queue-depth or the number of simultaneous requests in
# flight. Defaults to 32 times the number of CPU cores.
#
# Note: This value is only used if db_pool_affinity is disabled or not
# detected on the system, otherwise it is determined automatically.
#
#db_pool_workers = 32

# When db_pool_affinity is enabled and detected, the size of any worker
# group will not exceed the determined value. This is necessary when
# thread-pooling approach does not scale to the full capabilities of
# high-end hardware; using detected values without limitation could
# degrade performance.
#
# The value is multiplied by the number of cores which share a device
# queue, since group workers can be scheduled on any of those cores.
#
#db_pool_workers_limit = 64

# Limits the total number of workers across all worker groups. When the
# sum of all groups exceeds this value the worker counts are reduced until
# this constraint is satisfied.
#
# By default this value is only effective on larger systems (e.g. 16+
# cores) where it will tamper the overall thread-count. The thread-pool
# model will never achieve hardware capacity but this value can be raised
# on huge systems if the scheduling overhead is determined to not
# bottleneck and the worker groups are divided too small.
#
#db_pool_max_workers = 2048

# Determines the size of the queues feeding the database's frontend-pool.
# The size of the queue is determined by multiplying this value with the
# number of pool workers. When this queue is full, tokio tasks conducting
# requests will yield until space is available; this is good for
# flow-control by avoiding buffer-bloat, but can inhibit throughput if
# too low.
#
#db_pool_queue_mult = 4

# Sets the initial value for the concurrency of streams. This value simply
# allows overriding the default in the code. The default is 32, which is
# the same as the default in the code. Note this value is itself
# overridden by the computed stream_width_scale, unless that is disabled;
# this value can serve as a fixed-width instead.
#
#stream_width_default = 32

# Scales the stream width starting from a base value detected for the
# specific system. The base value is the database pool worker count
# determined from the hardware queue size (e.g. 32 for SSD or 64 or 128+
# for NVMe). This float allows scaling the width up or down by multiplying
# it (e.g. 1.5, 2.0, etc). The maximum result can be the size of the pool
# queue (see: db_pool_queue_mult) as any larger value will stall the tokio
# task. The value can also be scaled down (e.g. 0.5)  to improve
# responsiveness for many users at the cost of throughput for each.
#
# Setting this value to 0.0 causes the stream width to be fixed at the
# value of stream_width_default. The default scale is 1.0 to match the
# capabilities detected for the system.
#
#stream_width_scale = 1.0

# Sets the initial amplification factor. This controls batch sizes of
# requests made by each pool worker, multiplying the throughput of each
# stream. This value is somewhat abstract from specific hardware
# characteristics and can be significantly larger than any thread count or
# queue size. This is because each database query may require several
# index lookups, thus many database queries in a batch may make progress
# independently while also sharing index and data blocks which may or may
# not be cached. It is worthwhile to submit huge batches to reduce
# complexity. The maximum value is 32768, though sufficient hardware is
# still advised for that.
#
#stream_amplification = 1024

# Number of sender task workers; determines sender parallelism. Default is
# '0' which means the value is determined internally, likely matching the
# number of tokio worker-threads or number of cores, etc. Override by
# setting a non-zero value.
#
#sender_workers = 0

# Enables listener sockets; can be set to false to disable listening. This
# option is intended for developer/diagnostic purposes only.
#
#listening = true

# Enables configuration reload when the server receives SIGUSR1 on
# supporting platforms.
#
# reloadable: yes
#
#config_reload_signal = true

# Sets the `Access-Control-Allow-Origin` header included by this server in
# all responses. A list of multiple values can be specified. The default
# is an empty list. The actual header defaults to `*` upon an empty list.
#
# There is no reason to configure this without specific intent. Incorrect
# values may degrade or disrupt clients.
#
#access_control_allow_origin = []

# Backport state-reset security fixes to all room versions.
#
# This option applies the State Resolution 2.1 mitigation developed during
# project Hydra for room version 12 to all prior State Resolution 2.0 room
# versions (all room versions supported by this server). These mitigations
# increase resilience to state-resets without any new definition of
# correctness; therefor it is safe to set this to true for existing rooms.
#
# Furthermore, state-reset attacks are not consistent as they result in
# rooms without any single consensus, therefor it is unnecessary to set
# this to false to match other servers which set this to false or simply
# lack support; even if replicating the post-reset state suffered by other
# servers is somehow desired.
#
# This option exists for developer and debug use, and as a failsafe in
# lieu of hardcoding it.
# reloadable: yes
#
#hydra_backports = true

# Delete rooms when the last user from this server leaves. This feature is
# experimental and for the purpose of least-surprise is not enabled by
# default but can be enabled for deployments interested in conserving
# space. It may eventually default to true in a future release.
#
# Note that not all pathways which can remove the last local user
# currently invoke this operation, so in some cases you may find the room
# still exists.
#
# reloadable: yes
#
#delete_rooms_after_leave = false

# Limits the number of One Time Keys per device (not per-algorithm). The
# reference implementation maintains 50 OTK's at any given time, therefor
# our default is at least five times that. There is no known reason for an
# administrator to adjust this value; it is provided here rather than
# hardcoding it.
#
# reloadable: yes
#
#one_time_key_limit = 256

# (EXPERIMENTAL) Setting this option to true replaces the list of identity
# providers displayed on a client's login page with a single button "Sign
# in with single sign-on" linking to the URL
# `/_matrix/client/v3/login/sso/redirect`. All configured providers are
# attempted for authorization. All authorizations associate with the same
# Matrix user. NOTE: All authorizations must succeed, as there is no
# reliable way to skip a provider.
#
# This option is disabled by default, allowing the client to list
# configured providers and permitting privacy-conscious users to authorize
# only their choice.
#
# Note that fluffychat always displays a single button anyway. You do not
# need to enable this to use fluffychat; instead we offer a
# default-provider option, see `default` in the provider config section.
# reloadable: yes
#
#single_sso = false

# Setting this option to true replaces the list of identity providers on
# the client's login screen with a single button "Sign in with single
# sign-on" linking to the URL `/_matrix/client/v3/login/sso/redirect`. The
# deployment is expected to intercept this URL with their reverse-proxy to
# provide a custom webpage listing providers; each entry linking or
# redirecting back to one of the configured identity providers at
# /_matrix/client/v3/login/sso/redirect/<client_id>`.
#
# This option defaults to false, allowing the client to generate the list
# of providers or hide all SSO-related options when none configured.
# reloadable: yes
#
#sso_custom_providers_page = false

# From MSC3824:
# > If the client finds oauth_aware_preferred to be true then, assuming it
# > supports that auth type, it should present this as the only
# > login/registration method available to the user.
# reloadable: yes
#
#oidc_aware_preferred = false

# Directory containing appservice yaml registration files.
#
#appservice_dir = ""

# Skip database migration on startup. This option is intended for
# developer debugging and testing only. Never set this option to false
# unless you have been instructed to do so. Setting this option to false
# may cause permanent damage and permanent loss of data.
#
# Any new database migrations will not be applied on startup, and the
# database schema version will not be adjusted. These migrations and
# schema changes may be expected by the current codebase but may not be
# available when this option is set to false.
#
# Setting this option to false will have no effect if no new migrations
# are to be applied. New migrations are applied once during any execution
# where this option is set to true (which is the default).
#
#database_migrations = true

# Force the database to set its version to the current version known to
# the executable.
#
# - When the discovered version is less than the current version any
#   migrations are applied normally.
# - When the discovered version is equal to the current version,
#   unversioned migrations are applied normally.
# - When the discovered database version is greater than the current
#   version, one-time migrations are applied normally and the discoverable
#   version is regressed back to the current version.
#
# This option extremely dangerous and intended for developer debugging and
# testing only. Never set this option unless you have been instructed to
# do so. Setting this option may cause permanent damage and permanent loss
# of data.
#
#force_migration = false

# Set this to true for excluding unencrypted rooms from the common-rooms
# calculation deciding the receivers of device list updates.
#
# Setting this to true can help performance on very large homeservers,
# but it may not be spec compliant and risky for client expectations.
# reloadable: yes
#
#device_key_update_encrypted_rooms_only = false



#[global.tls]

# Path to a valid TLS certificate file.
#
# example: "/path/to/my/certificate.crt"
#
#certs =

# Path to a valid TLS certificate private key.
#
# example: "/path/to/my/certificate.key"
#
#key =

# Whether to listen and allow for HTTP and HTTPS connections (insecure!)
#
#dual_protocol = false



#[global.well_known]

# The server URL that the client well-known file will serve. This should
# not contain a port, and should just be a valid HTTPS URL.
#
# example: "https://matrix.example.com"
#
#client =

# The server base domain of the URL with a specific port that the server
# well-known file will serve. This should contain a port at the end, and
# should not be a URL.
#
# reloadable: yes
# example: "matrix.example.com:443"
#
#server =

# The URL of the support web page. This and the below generate the content
# of `/.well-known/matrix/support`.
#
# reloadable: yes
# example: "https://example.com/support"
#
#support_page =

# The name of the support role.
#
# reloadable: yes
# example: "m.role.admin"
#
#support_role =

# The email address for the above support role.
#
# reloadable: yes
# example: "admin@example.com"
#
#support_email =

# The Matrix User ID for the above support role.
#
# example "@admin:example.com"
# reloadable: yes
#
#support_mxid =

# LiveKit JWT endpoint.
# Required for Element Call / MatrixRTC (MSC4143).
#
# Note: You must also set `client` above to your homeserver URL.
#
# reloadable: yes
#
#livekit_url = ""

# Custom MatrixRTC transports.
#
# If you're looking to setup Element Call / MatrixRTC with Livekit,
# you should not use this option and instead set `livekit_url`.
# This is only required if you want to configure a non-livekit MatrixRTC
# transport. There are no known client implementations that support any
# other transport types.
#
# This option was previously the only way to configure a Livekit
# transport. It has been superseded by `livekit_url`.
#
# Example:
# ```toml
# [global.well_known]
# client = "https://matrix.yourdomain.com"
#
# [[global.well_known.rtc_transports]]
# type = "livekit"
# livekit_service_url = "https://livekit.yourdomain.com"
# ```
#
# reloadable: yes
#
#rtc_transports = []



#[global.blurhashing]

# blurhashing x component, 4 is recommended by https://blurha.sh/
#
# reloadable: yes
#
#components_x = 4

# blurhashing y component, 3 is recommended by https://blurha.sh/
#
# reloadable: yes
#
#components_y = 3

# Max raw size that the server will blurhash, this is the size of the
# image after converting it to raw data, it should be higher than the
# upload limit but not too high. The higher it is the higher the
# potential load will be for clients requesting blurhashes. Accepts an
# integer byte count or a string with SI/IEC suffix such as "32 MiB".
# Setting it to 0 disables blurhashing.
#
# reloadable: yes
#
#blurhash_max_raw_size = 33554432



#[global.ldap]

# Whether to enable LDAP login.
#
# reloadable: yes
# example: "true"
#
#enable = false

# URI of the LDAP server.
#
# reloadable: yes
# example: "ldap://ldap.example.com:389"
#
#uri =

# Root of the searches.
#
# reloadable: yes
# example: "ou=users,dc=example,dc=org"
#
#base_dn =

# Bind DN if anonymous search is not enabled.
#
# You can use the variable `{username}` that will be replaced by the
# entered username. In such case, the password used to bind will be the
# one provided for the login and not the one given by
# `bind_password_file`. Beware: automatically granting admin rights will
# not work if you use this direct bind instead of a LDAP search.
#
# reloadable: yes
# example: "cn=ldap-reader,dc=example,dc=org" or
# "cn={username},ou=users,dc=example,dc=org"
#
#bind_dn = ""

# Path to a file on the system that contains the password for the
# `bind_dn`.
#
# The server must be able to access the file, and it must not be empty.
#
# reloadable: yes
#
#bind_password_file = ""

# Search filter to limit user searches.
#
# You can use the variable `{username}` that will be replaced by the
# entered username for more complex filters.
#
# reloadable: yes
# example: "(&(objectClass=person)(memberOf=matrix))"
#
#filter = "(objectClass=*)"

# Attribute to use to uniquely identify the user.
#
# reloadable: yes
# example: "uid" or "cn"
#
#uid_attribute = "uid"

# Attribute containing the distinguished name of the user.
#
# reloadable: yes
# example: "givenName" or "sn"
#
#name_attribute = "givenName"

# Root of the searches for admin users.
#
# Defaults to `base_dn` if empty.
#
# reloadable: yes
# example: "ou=admins,dc=example,dc=org"
#
#admin_base_dn =

# The LDAP search filter to find administrative users for tuwunel.
#
# If left blank, administrative state must be configured manually for each
# user.
#
# You can use the variable `{username}` that will be replaced by the
# entered username for more complex filters.
#
# reloadable: yes
# example: "(objectClass=tuwunelAdmin)" or "(uid={username})"
#
#admin_filter =



#[global.jwt]

# Enable JWT logins
#
# reloadable: yes
#
#enable = false

# Validation key, also called 'secret' in Synapse config. The type of key
# can be configured in 'format', but defaults to the common HMAC which
# is a plaintext shared-secret, so you should keep this value private.
#
# reloadable: yes
#
#key =

# Format of the 'key'. Only HMAC, ECDSA, and B64HMAC are supported
# Binary keys cannot be pasted into this config, so B64HMAC is an
# alternative to HMAC for properly random secret strings.
# - HMAC is a plaintext shared-secret private-key.
# - B64HMAC is a base64-encoded version of HMAC.
# - ECDSA is a PEM-encoded public-key.
# - EDDSA is a PEM-encoded Ed25519 public-key.
#
# reloadable: yes
#
#format = "HMAC"

# Automatically create new user from a valid claim, otherwise access is
# denied for an unknown even with an authentic token.
#
# reloadable: yes
#
#register_user = true

# JWT algorithm
#
# reloadable: yes
#
#algorithm = "HS256"

# Optional audience claim list. The token must claim one or more values
# from this list when set.
#
# reloadable: yes
#
#audience = []

# Optional issuer claim list. The token must claim one or more values
# from this list when set.
#
# reloadable: yes
#
#issuer = []

# Require expiration claim in the token. This defaults to false for
# synapse migration compatibility.
#
# reloadable: yes
#
#require_exp = false

# Require not-before claim in the token. This defaults to false for
# synapse migration compatibility.
#
# reloadable: yes
#
#require_nbf = false

# Validate expiration time of the token when present. Whether or not it is
# required depends on require_exp, but when present this ensures the token
# is not used after a time.
#
# reloadable: yes
#
#validate_exp = true

# Validate not-before time of the token when present. Whether or not it is
# required depends on require_nbf, but when present this ensures the token
# is not used before a time.
#
# reloadable: yes
#
#validate_nbf = true

# Bypass validation for diagnostic/debug use only.
#
# reloadable: yes
#
#validate_signature = true



#[[global.identity_provider]]

# The brand-name of the service (e.g. Apple, Facebook, GitHub, GitLab,
# Google) or the software (e.g. keycloak, MAS) providing the identity.
# When a brand is recognized we apply certain defaults to this config
# for your convenience. For certain brands we apply essential internal
# workarounds specific to that provider; it is important to configure this
# field properly when a provider needs to be recognized (like GitHub for
# example).
#
# Several configured providers can share the same brand name. It is not
# case-sensitive. As a convenience for common simple deployments we can
# identify this provider by brand in addition to the unique `client_id` if
# and only if there is a single provider for the brand; see notes for
# `client_id`.
#
#brand =

# The ID of your OAuth application which the provider generates upon
# registration. This ID then uniquely identifies this configuration
# instance itself, becoming the identity provider's ID and must be unique
# and remain unchanged.
#
# As a convenience we also identify this config by `brand` if and only if
# there is a single provider configured for a `brand`. Note carefully that
# multiple providers configured with the same `brand` is not an error and
# this provider will simply not be found when querying by `brand`.
#
#client_id =

# Secret key the provider generated for you along with the `client_id`
# above. Unlike the `client_id`, the `client_secret` can be changed here
# whenever the provider regenerates one for you.
#
#client_secret =

# Secret key to use that's read from the file path specified.
#
# This takes priority over "client_secret" first, and falls back to
# "client_secret" if invalid or failed to open.
#
# example: "/etc/tuwunel/.client_secret"
#
#client_secret_file =

# Issuer URL the provider publishes for you. We have pre-supplied default
# values for some of the canonical public providers, making this field
# optional based on the `brand` set above. Otherwise it is required to
# find self-hosted providers. It must be identical to what is configured
# and expected by the provider and must never change because we associate
# identities to it. If the `/.well-known/openid-configuration` is not
# found behind this URL see `base_path` below as a workaround.
#
#issuer_url =

# The callback URL configured when registering the OAuth application with
# the provider. Tuwunel's callback URL must be strictly formatted exactly
# as instructed. The URL host must point directly at the matrix server and
# use the following path:
# `/_matrix/client/unstable/login/sso/callback/<client_id>` where
# `<client_id>` is the same one configured for this provider above.
#
#callback_url =

# When more than one identity_provider has been configured and
# `single_sso` is false and `sso_custom_providers_page` is false this will
# determine the behavior of the `/_matrix/client/v3/login/sso/redirect`
# endpoint (note the url lacks a trailing `client_id`).
#
# When only one identity_provider is configured it will be interpreted
# as the default and this does not need to be set. Otherwise a default
# *must* be selected for some clients (e.g. fluffychat) to work properly
# when the above conditions require it. To operate out-of-the-box we
# default to one configured provider if none are explicitly default; a
# warning will be logged on startup for this condition.
#
# (EXPERIMENTAL) Multiple providers can be set to default. All providers
# configured with this option set to `true` will associate with the same
# Matrix account when a client flows through
# `/_matrix/client/v3/login/sso/redirect`.
#
# When a user authorizes any provider configured default, the flow will
# include all other providers configured default as well for association.
# NOTE: authorization must succeed for ALL default providers.
#
#default = false

# Optional display-name for this provider instance seen on the login page
# by users. It defaults to `brand`. When configuring multiple providers
# using the same `brand` this can be set to distinguish them.
#
#name =

# Optional icon for the provider. The canonical providers have a default
# icon based on the `brand` supplied above when this is not supplied. Note
# that it uses an MXC url which is curious in the auth-media era and may
# not be reliable.
#
#icon =

# Optional list of scopes to authorize. An empty array does not impose any
# restrictions from here, effectively defaulting to all scopes you
# configured for the OAuth application at the provider. This setting
# allows for restricting to a subset of those scopes for this instance.
# Note the user can further restrict scopes during their authorization.
#
#scope = []

# Optional list of userinfo claims which shape and restrict the way we
# compute a Matrix UserId for new registrations. Reviewing Tuwunel's
# documentation will be necessary for a complete description in detail. An
# empty array imposes no restriction here, avoiding generated fallbacks as
# much as possible.
#
# For simplicity we reserve a claim called "unique" which can be listed
# alone to ensure *only* generated ID's are used for registrations.
#
# Note that listing the claim "sub" has special significance and will take
# precedence over all other claims, listed or unlisted. "sub" is not
# normally used to determine a UserId unless explicitly listed here.
#
# As of now arbitrary claims cannot be listed here, we only recognize
# specific hard-coded claims.
#
#userid_claims = []

# Trusted providers can cause username conflicts (i.e. account hijacking)
# but this is precisely how an existing matrix account can be associated
# with a provider. When this option is set to true, the way we compute a
# Matrix UserId from userinfo claims is inverted: we find the first
# matching user and grant access to it. Whereas by default, when set to
# false, we skip matching users and register the first available username;
# falling-back to random characters to avoid conflicts.
#
# Only set this option to true for providers you self-host and control.
# Never set this option to true for the public providers such as GitHub,
# GitLab, etc.
#
# Note that associating an existing user with an untrusted provider is
# still possible but only with the command '!admin query oauth associate'.
#
#trusted = false

# Setting this option to false will inhibit unique ID's from being
# generated as a last-resort when determining a UserId from a provider's
# claims. In the case of untrusted providers, when all provided claims
# conflict with existing user accounts, a unique fallback ID needs
# to be generated for registration to not be denied with an error.
#
# Set this option to false if you operate a private server or a trusted
# identity provider where random UserId's are undesirable; the result of a
# misconfiguration or other issue where an error is warranted.
#
# This option should be set to true for public servers or some users may
# never be able to register.
#
#unique_id_fallbacks = true

# Controls whether new user registration is possible from this provider.
# When this option is set to false, authorizations from this provider
# only affect existing users and will never result in a new registration
# when the claims fail to match any existing user (in the case of trusted
# providers) or an available username is found (in the case of untrusted
# providers).
#
# Setting this option to false is generally not useful unless there is
# an explicit reason to do so.
#
#registration = true

# Optional extra path components after the issuer_url leading to the
# location of the `.well-known` directory used for discovery. If the path
# starts with a slash it will be treated as absolute, meaning overwriting
# any path in the issuer_url. The path needs to end with a slash. This
# will be empty for specification-compliant providers. We have supplied
# any known values based on `brand` (e.g. `login/oauth/` for GitHub).
#
#base_path =

# Overrides the `.well-known` location where the provider's openid
# configuration is found. It is very unlikely you will need to set this;
# available for developers or special purposes only.
#
#discovery_url =

# Overrides the authorize URL requested during the grant phase. This is
# generally discovered or derived automatically, but may be required as a
# workaround for any non-standard or undiscoverable provider.
#
#authorization_url =

# Overrides the access token URL; the same caveats apply as with the other
# URL overrides.
#
#token_url =

# Overrides the revocation URL; the same caveats apply as with the other
# URL overrides.
#
#revocation_url =

# Overrides the introspection URL; the same caveats apply as with the
# other URL overrides.
#
#introspection_url =

# Overrides the userinfo URL; the same caveats apply as with the other URL
# overrides.
#
#userinfo_url =

# Whether to perform discovery and adjust this provider's configuration
# accordingly. This defaults to true. When true, it is an error when
# discovery fails and authorizations will not be attempted to the
# provider.
#
#discovery = true

# The duration in seconds before a grant authorization session expires.
#
#grant_session_duration = 300

# Whether to check the redirect cookie during the callback. This is a
# security feature and should remain enabled. This is available for
# developers or deployments which cannot tolerate cookies and are willing
# to tolerate the risks.
#
#check_cookie = true

# Extra query parameters appended to every authorization request sent to
# the identity provider.
#
# E.g. to force re-authentication even if IdP cookies are present:
# ```toml
# [[global.identity_provider]]
# extra_authorization_parameters = { prompt = "login" }
# ```
#
#extra_authorization_parameters = {}



#[global.storage_provider.<ID>.local]

# Absolute path to this local filesystem storage provider. Technically the
# provider exists at the filesystem root, and the base_path is prefixed to
# all objects.
#
#base_path =

# Creates the directory on the local filesystem if missing. This is not
# recommended to prevent misconfigured environments and missing mounts
# from silently succeeding.
#
#create_if_missing = false

# Toggles the preservation of a directory after its last file contents are
# removed.
#
#delete_empty_directories = true

# Enables checks performed at startup determining the usability of the
# local directory. Failures will abort the server's startup.
#
#startup_check = true



#[global.storage_provider.<ID>.s3]

# Supply an s3 URL e.g. "s3://bucket/path". These URLs may contain one
# or all of `bucket`, `region`, and `path` . When not supplied, such
# additional items can be supplied below individually.
#
#url =

# The name of the S3 bucket. e.g. "bucketname-123456789-us-west-2-an".
#
#bucket =

# The region of the S3 bucket. e.g. "us-west-2".
#
#region = "us-east-1"

# Your amazon IAM Key ID with access granted to this bucket.
# e.g. "ABCDEFG1X1ZZYYXXWWVV"
#
#key =

# The secret key component which is approx 40 characters of base64.
#
#secret =

# Optional path prefix within the bucket where all our operations will
# take place.
#
#base_path =

# (expert use) Override the location of s3 applied after components of the
# parsed `url` (or when none set).
#
#endpoint =

# (expert use) Override this property useful for some self-hosted
# environments. By default it is derived when parsing the primary `url`.
#
#use_vhost_request = false

# (expert use) Alternative session-token authentication method.
#
#token =

# (expert use) Associated SSE-KMS key material.
#
#kms =

# (expert use) When configured for the bucket it should be reflected here.
#
#use_bucket_key =

# (expert use) Threshold size for switching to Multi-part uploads. This is
# a quirk of the S3 protocol which requires us to use a different approach
# for "large" uploads. This value determines what a "large" upload is. The
# default value should be sufficient for most providers. The value is a
# parsed string allowing SI or IEC units for convenience.
#
#multipart_threshold = 100 MiB

# (expert use) Size of each individual part within a Multi-part upload.
# Once an upload exceeds `multipart_threshold` the payload is split into
# parts of this size, each sent as a separate HTTP PUT. Smaller values
# keep individual requests under per-request timeouts on slow uplinks at
# the cost of more round-trips. S3 requires every part except the last
# to be at least 5 MiB. The value is a parsed string allowing SI or IEC
# units for convenience.
#
#multipart_part_size = 10 MiB

# (developer use) Allows relaxing default requirement forcing HTTPS.
#
#use_https = true

# (developer_use) Allows skipping request header signatures (will be
# reejected by AWS).
#
#use_signatures = true

# (developer_use) Allows disabling request payload signatures.
#
#use_payload_signatures = true

# (developer use) Enables checks performed at startup such as pinging the
# provider. Failures are considered critical startup errors which abort
# startup. When set to false, faulty providers are only discovered with
# first use and will not be fatal errors.
#
# Only set this to false if you expect a provider to be down at startup or
# for development/testing purposes; checks are disabled when the server
# is started in '--maintenance' mode.
#
#startup_check = true



#[global.appservice.<ID>]

# The URL for the application service.
#
# Optionally set to `null` if no traffic is required.
#
#url =

# A unique token for application services to use to authenticate requests
# to Homeservers.
#
#as_token =

# A unique token for Homeservers to use to authenticate requests to
# application services.
#
#hs_token =

# The localpart of the user associated with the application service.
#
#sender_localpart =

# Whether requests from masqueraded users are rate-limited.
#
# The sender is excluded.
#
#rate_limited = false

# The external protocols which the application service provides (e.g.
# IRC).
#
#protocols = []

# Whether the application service wants to receive ephemeral data.
#
#receive_ephemeral = false

# Whether the application service wants to do device management, as part
# of MSC4190.
#
#device_management = false



#[[global.appservice.<ID>.<users|rooms|aliases>]]

# Whether this application service has exclusive access to events within
# this namespace.
#
#exclusive = false

# A regular expression defining which values this namespace includes.
#
#regex =

Debian systemd unit file

[Unit]
Description=Tuwunel Matrix homeserver
Wants=network-online.target
After=network-online.target
Documentation=https://tuwunel.chat/

[Service]
User=tuwunel
Group=tuwunel
Type=notify
WatchdogSec=30

Environment="TUWUNEL_CONFIG=/etc/tuwunel/tuwunel.toml"

ExecStart=/usr/sbin/tuwunel

ReadWritePaths=/var/lib/tuwunel /etc/tuwunel

AmbientCapabilities=
CapabilityBoundingSet=

ManagedOOMPreference=avoid

DevicePolicy=closed
LockPersonality=yes
MemoryDenyWriteExecute=yes
NoNewPrivileges=yes
#ProcSubset=pid
ProtectClock=yes
ProtectControlGroups=yes
ProtectHome=yes
ProtectHostname=yes
ProtectKernelLogs=yes
ProtectKernelModules=yes
ProtectKernelTunables=yes
ProtectProc=invisible
ProtectSystem=strict
PrivateDevices=yes
PrivateMounts=yes
PrivateTmp=yes
PrivateUsers=yes
PrivateIPC=yes
RemoveIPC=yes
RestrictAddressFamilies=AF_INET AF_INET6 AF_UNIX
RestrictNamespaces=yes
RestrictRealtime=yes
RestrictSUIDSGID=yes
SystemCallArchitectures=native
SystemCallFilter=@system-service @resources
SystemCallFilter=~@clock @debug @module @mount @reboot @swap @cpu-emulation @obsolete @timer @chown @setuid @privileged @keyring @ipc
SystemCallErrorNumber=EPERM
#StateDirectory=tuwunel

RuntimeDirectory=tuwunel
RuntimeDirectoryMode=0750

Restart=on-failure
RestartSec=5

TimeoutStopSec=2m
TimeoutStartSec=2m

StartLimitInterval=1m
StartLimitBurst=5

[Install]
WantedBy=multi-user.target
Alias=matrix-tuwunel.service

Arch Linux systemd unit file

[Unit]
Description=Tuwunel Matrix homeserver
Wants=network-online.target
After=network-online.target
Documentation=https://tuwunel.chat/
RequiresMountsFor=/var/lib/private/tuwunel

[Service]
DynamicUser=yes
Type=notify-reload
ReloadSignal=SIGUSR1
WatchdogSec=30

TTYPath=/dev/tty25
DeviceAllow=char-tty
StandardInput=tty-force
StandardOutput=tty
StandardError=journal+console
TTYReset=yes
# uncomment to allow buffer to be cleared every restart
TTYVTDisallocate=no

TTYColumns=120
TTYRows=40

AmbientCapabilities=
CapabilityBoundingSet=

ManagedOOMPreference=avoid

DevicePolicy=closed
LockPersonality=yes
MemoryDenyWriteExecute=yes
NoNewPrivileges=yes
#ProcSubset=pid
ProtectClock=yes
ProtectControlGroups=yes
ProtectHome=yes
ProtectHostname=yes
ProtectKernelLogs=yes
ProtectKernelModules=yes
ProtectKernelTunables=yes
ProtectProc=invisible
ProtectSystem=strict
PrivateDevices=yes
PrivateMounts=yes
PrivateTmp=yes
PrivateUsers=yes
PrivateIPC=yes
RemoveIPC=yes
RestrictAddressFamilies=AF_INET AF_INET6 AF_UNIX
RestrictNamespaces=yes
RestrictRealtime=yes
RestrictSUIDSGID=yes
SystemCallArchitectures=native
SystemCallFilter=@system-service @resources
SystemCallFilter=~@clock @debug @module @mount @reboot @swap @cpu-emulation @obsolete @timer @chown @setuid @privileged @keyring @ipc
SystemCallErrorNumber=EPERM
StateDirectory=tuwunel

RuntimeDirectory=tuwunel
RuntimeDirectoryMode=0750

Environment="TUWUNEL_CONFIG=/etc/tuwunel/tuwunel.toml"
BindPaths=/var/lib/private/tuwunel:/var/lib/conduwuit
BindPaths=/var/lib/private/tuwunel:/var/lib/private/conduwuit
BindPaths=/var/lib/private/tuwunel:/var/lib/matrix-conduit
BindPaths=/var/lib/private/tuwunel:/var/lib/private/matrix-conduit

ExecStart=/usr/bin/tuwunel
Restart=on-failure
RestartSec=5

TimeoutStopSec=4m
TimeoutStartSec=4m

StartLimitInterval=1m
StartLimitBurst=5

[Install]
WantedBy=multi-user.target
Alias=matrix-tuwunel.service

Generic deployment documentation

Tip

Getting help: If you run into any problems while setting up Tuwunel open an issue on GitHub.

Installing Tuwunel

Static prebuilt binary

You may simply download the binary that fits your machine architecture (x86_64 or aarch64). Run uname -m to see what you need.

Prebuilt fully static binaries can be downloaded from the latest tagged release here or main CI branch workflow artifact output. These also include .deb packages for Debian or Ubuntu and .rpm packages for Red Hat or Fedora.

For the best performance; if using an x86_64 CPU made in the last ~10 years, we recommend using the -v3- optimised packages. See below for a command to check what your system supports. If the server refuses to start or exits with an “Illegal Instruction” error you will need -v2- or -v1- packages instead. The database backend, RocksDB, benefits from -v2- or greater as it features performance critical hardware accelerated CRC32 hashing/checksumming.

Linux users can run this script to display which optimization levels they may choose:

cat /proc/cpuinfo | grep -Po '(avx|sse)[235]' | sort -u | sed 's/avx5/v4/;s/avx2/v3/;s/sse3/v2/;s/sse2/v1/' | sort

Compiling

Alternatively, you may compile the binary yourself. We recommend using Nix to build tuwunel as this has the most guaranteed reproducibiltiy and easiest to get a build environment and output going. This also allows easy cross-compilation.

You can run the nix build -L .#static-x86_64-linux-musl-all-features or nix build -L .#static-aarch64-linux-musl-all-features commands based on architecture to cross-compile the necessary static binary located at result/bin/tuwunel. This is reproducible with the static binaries produced in our CI.

If wanting to build using standard Rust toolchains, make sure you install:

• liburing-dev on the compiling machine, and liburing on the target host
• LLVM and libclang for RocksDB

You can build Tuwunel using cargo build --release --all-features

Adding a Tuwunel user

While Tuwunel can run as any user it is better to use dedicated users for different services. This also allows you to make sure that the file permissions are correctly set up.

In Debian, you can use this command to create a Tuwunel user:

sudo adduser --system tuwunel --group --disabled-login --no-create-home

For distros without adduser (or where it’s a symlink to useradd):

sudo useradd -r --shell /usr/bin/nologin --no-create-home tuwunel

Forwarding ports in the firewall or the router

Matrix’s default federation port is port 8448, and clients must be using port 443. If you would like to use only port 443, or a different port, you will need to setup delegation. Tuwunel has config options for doing delegation, or you can configure your reverse proxy to manually serve the necessary JSON files to do delegation (see the [global.well_known] config section and the delegation example).

If Tuwunel runs behind a router or in a container and has a different public IP address than the host system these public ports need to be forwarded directly or indirectly to the port mentioned in the config.

Note for NAT users; if you have trouble connecting to your server from the inside of your network, you need to research your router and see if it supports “NAT hairpinning” or “NAT loopback”.

If your router does not support this feature, you need to research doing local DNS overrides and force your Matrix DNS records to use your local IP internally. This can be done at the host level using /etc/hosts. If you need this to be on the network level, consider something like NextDNS or Pi-Hole.

Setting up a systemd service

Two example systemd units for Tuwunel can be found on the configuration page. You may need to change the ExecStart= path to where you placed the Tuwunel binary if it is not /usr/bin/tuwunel.

On systems where rsyslog is used alongside journald (i.e. Red Hat-based distros and OpenSUSE), put $EscapeControlCharactersOnReceive off inside /etc/rsyslog.conf to allow color in logs.

If you are using a different database_path other than the systemd unit configured default /var/lib/tuwunel, you need to add your path to the systemd unit’s ReadWritePaths=. This can be done by either directly editing tuwunel.service and reloading systemd, or running systemctl edit tuwunel.service and entering the following:

[Service]
ReadWritePaths=/path/to/custom/database/path

Creating the Tuwunel configuration file

Now we need to create the Tuwunel’s config file in /etc/tuwunel/tuwunel.toml. The example config can be found at tuwunel-example.toml.

Please take a moment to read the config. You need to change at least the server name.

RocksDB is the only supported database backend.

Setting the correct file permissions

If you are using a dedicated user for Tuwunel, you will need to allow it to read the config. To do that you can run this:

sudo chown -R root:root /etc/tuwunel
sudo chmod -R 755 /etc/tuwunel

If you use the default database path you also need to run this:

sudo mkdir -p /var/lib/tuwunel/
sudo chown -R tuwunel:tuwunel /var/lib/tuwunel/
sudo chmod 700 /var/lib/tuwunel/

Setting up the Reverse Proxy

We recommend Caddy as a reverse proxy, as it is trivial to use, handling TLS certificates, reverse proxy headers, etc. transparently with proper defaults. However, Nginx is also well-supported and widely used.

Choose your reverse proxy:

• Caddy Setup Guide - Recommended for ease of use and automatic TLS
• Nginx Setup Guide - Popular choice with extensive documentation
• Traefik Setup Guide - Please help us document this choice

Quick Overview

Regardless of which reverse proxy you choose, you will need to:

1. Reverse proxy the following routes:

   • /_matrix/ - core Matrix C-S and S-S APIs
   • /_tuwunel/ - ad-hoc Tuwunel routes such as /local_user_count and /server_version

2. Optionally reverse proxy (recommended):

   • /.well-known/matrix/client and /.well-known/matrix/server if using Tuwunel to perform delegation (see the [global.well_known] config section and the delegation example)
   • /.well-known/matrix/support if using Tuwunel to send the homeserver admin contact and support page (formerly known as MSC1929)
   • / if you would like to see hewwo from tuwunel woof! at the root

3. Handle ports:

   • Port 443 (HTTPS) for client-server API
   • Port 8448 for federation (if federating with other homeservers)

Client IP source

Set ip_source when you want Tuwunel to use a spoofing-resistant client IP source for rate limiting, logging, and security tooling. Leave it unset to keep the legacy fallback behavior.

Use ip_source = "connect_info" only when Tuwunel accepts direct TCP connections and should use the TCP peer address. Do not use connect_info for Unix-socket deployments; leave ip_source unset there.

If Tuwunel is behind a trusted reverse proxy, set ip_source to match the header that proxy controls. Caddy, Nginx, and Traefik usually use ip_source = "rightmost_x_forwarded_for". Cloudflare and cloudflared deployments can use ip_source = "cf_connecting_ip" when Cloudflare supplies that header.

Only use header-based values when clients cannot connect to Tuwunel directly. If clients can reach Tuwunel without going through the trusted proxy, they can send forged forwarding headers and choose the IP address Tuwunel sees.

See the following spec pages for more details on well-known files:

• /.well-known/matrix/server
• /.well-known/matrix/client
• /.well-known/matrix/support

Examples of delegation:

• https://matrix.org/.well-known/matrix/server
• https://matrix.org/.well-known/matrix/client

Other Reverse Proxies

Specific contributions for other proxies are welcome!

Not Recommended:

• Apache: While possible, Apache requires special configuration (nocanon in ProxyPass) to prevent corruption of the X-Matrix header.
• Lighttpd: Its proxy module alters the X-Matrix authorization header, breaking federation functionality.

You are done

Now you can start Tuwunel with:

sudo systemctl start tuwunel

Set it to start automatically when your system boots with:

sudo systemctl enable tuwunel

How do I know it works?

You can open a Matrix client, enter your homeserver and try to register.

You can also use these commands as a quick health check (replace your.server.name).

curl https://your.server.name/_tuwunel/server_version

# If using port 8448
curl https://your.server.name:8448/_tuwunel/server_version

# If federation is enabled
curl https://your.server.name:8448/_matrix/federation/v1/version

• To check if your server can talk with other homeservers, you can use the Matrix Federation Tester. If you can register but cannot join federated rooms check your config again and also check if the port 8448 is open and forwarded correctly.

What’s next?

Audio/Video calls

For Audio/Video call functionality see the TURN Guide.

Appservices

If you want to set up an appservice, take a look at the Appservice Guide.

Reverse Proxy Setup - Caddy

<= Back to Generic Deployment Guide

We recommend Caddy as a reverse proxy, as it is trivial to use, handling TLS certificates, reverse proxy headers, etc. transparently with proper defaults.

Installation

Install Caddy via your preferred method. Refer to the official Caddy installation guide for your distribution.

Configuration

After installing Caddy, create /etc/caddy/conf.d/tuwunel_caddyfile and enter this (substitute your.server.name with your actual server name):

your.server.name, your.server.name:8448 {
    # TCP reverse_proxy
    reverse_proxy localhost:8008
    # UNIX socket (alternative - comment out the line above and uncomment this)
    #reverse_proxy unix//run/tuwunel/tuwunel.sock
}

What this does

• Handles both port 443 (HTTPS) and port 8448 (Matrix federation) automatically
• Automatically provisions and renews TLS certificates via Let’s Encrypt
• Sets all necessary reverse proxy headers correctly
• Routes all traffic to Tuwunel listening on localhost:8008

Client IP source

By default, Tuwunel treats Caddy as the connecting peer, so registration logs, rate limiting, and security tooling all attribute requests to Caddy’s address rather than the real client. If Caddy is the only way clients can reach Tuwunel, set ip_source = "rightmost_x_forwarded_for" in tuwunel.toml (or TUWUNEL_IP_SOURCE=rightmost_x_forwarded_for in Docker). This makes Tuwunel trust the X-Forwarded-For header that Caddy’s reverse_proxy directive already sets. If you use the Unix-socket reverse_proxy target, leave ip_source unset instead.

The setting only takes effect at startup, so restart Tuwunel after changing it.

That’s it! Just start and enable the service and you’re set.

sudo systemctl enable --now caddy

Verification

After starting Caddy, verify it’s working by checking:

curl https://your.server.name/_tuwunel/server_version
curl https://your.server.name:8448/_tuwunel/server_version

Caddy and .well-known

Caddy can serve .well-known/matrix/client and .well-known/matrix/server instead of tuwunel. This is useful when delegating a root domain such as example.com to a subdomain like matrix.example.com, where Caddy on the root domain has no Tuwunel upstream of its own.

In this configuration Caddy bypasses Tuwunel’s CORS layer, so the CORS headers recommended by the Matrix specification must be added explicitly.

Note

Caddyfile uses backticks as an alternative string quote so the inline JSON body (which contains double quotes) does not need escaping. Field names and values inside a header block are space-separated; do not place a colon after the field name.

example.com {
	@matrix path /.well-known/matrix/*
	header @matrix {
		Access-Control-Allow-Origin "*"
		Access-Control-Allow-Methods "GET, POST, PUT, DELETE, OPTIONS"
		Access-Control-Allow-Headers "X-Requested-With, Content-Type, Authorization"
		Content-Type "application/json"
	}
	respond /.well-known/matrix/client `{"m.homeserver":{"base_url":"https://matrix.example.com"}}`
	respond /.well-known/matrix/server `{"m.server":"matrix.example.com:443"}`
}

To advertise a MatrixRTC focus (MSC4143) for Element Call, extend the client response with an org.matrix.msc4143.rtc_foci array pointing at your LiveKit JWT service:

respond /.well-known/matrix/client `{"m.homeserver":{"base_url":"https://matrix.example.com"},"org.matrix.msc4143.rtc_foci":[{"type":"livekit","livekit_service_url":"https://rtc.example.com"}]}`

=> Continue with “You’re Done”

Reverse Proxy Setup - Nginx

<= Back to Generic Deployment Guide

This guide shows you how to configure Nginx as a reverse proxy for Tuwunel with TLS support.

Installation

Install Nginx via your preferred method. Most distributions include Nginx in their package repositories:

# Debian/Ubuntu
sudo apt install nginx

# Red Hat/Fedora
sudo dnf install nginx

# Arch Linux
sudo pacman -S nginx

Configuration

Create a new configuration file at /etc/nginx/sites-available/tuwunel (or /etc/nginx/conf.d/tuwunel.conf on some distributions):

upstream tuwunel {
  server 127.0.0.1:8008; # IP and port where tuwunel is listening
}

# Client-Server API over HTTPS (port 443)
server {
  listen 443 ssl;
  listen [::]:443 ssl;
  http2 on;
  server_name matrix.example.com;

  # Nginx standard body size is 1MB, which is quite small for media uploads
  # Increase this to match the max_request_size in your tuwunel.toml
  client_max_body_size 100M;

  # Forward requests to Tuwunel
  location / {
    proxy_pass http://tuwunel;

    # Preserve host and scheme - critical for proper Matrix operation
    proxy_set_header Host $host;
    proxy_set_header X-Forwarded-For $remote_addr;
    proxy_set_header X-Forwarded-Proto https;
  }

  # TLS configuration (Let's Encrypt example using certbot)
  ssl_certificate /etc/letsencrypt/live/matrix.example.com/fullchain.pem;
  ssl_certificate_key /etc/letsencrypt/live/matrix.example.com/privkey.pem;
}

# Matrix Federation over HTTPS (port 8448)
# Only needed if you want to federate with other homeservers
# Don't forget to open port 8448 in your firewall!
server {
  listen 8448 ssl;
  listen [::]:8448 ssl;
  http2 on;
  server_name matrix.example.com;

  # Same body size increase for larger files
  client_max_body_size 100M;

  # Forward to the same local port as client-server API
  location / {
    proxy_pass http://tuwunel;
    proxy_set_header Host $host;
    proxy_set_header X-Forwarded-For $remote_addr;
    proxy_set_header X-Forwarded-Proto https;
  }

  # TLS configuration (same certificates as above)
  ssl_certificate /etc/letsencrypt/live/matrix.example.com/fullchain.pem;
  ssl_certificate_key /etc/letsencrypt/live/matrix.example.com/privkey.pem;
}

Important Notes

• Replace matrix.example.com with your actual server name
• client_max_body_size: Must match or exceed max_request_size in your tuwunel.toml
• ip_source: If Nginx is the only way clients can reach Tuwunel, set ip_source = "rightmost_x_forwarded_for" so Tuwunel uses the trusted X-Forwarded-For value
• Do NOT use $request_uri in proxy_pass - while some guides suggest this, it’s not necessary for Tuwunel and can cause issues
• IPv6: The listen [::]:443 and listen [::]:8448 lines enable IPv6 support. Remove them if you don’t need IPv6

TLS Certificates

The example above uses Let’s Encrypt certificates via certbot. To obtain certificates:

sudo certbot certonly --nginx -d matrix.example.com

Certbot will automatically handle renewal. Make sure to reload Nginx after certificate renewal:

sudo systemctl reload nginx

Optional: Timeout Configuration

The default Nginx timeouts are usually sufficient for Matrix operations. Element’s long-polling /sync requests typically run for 30 seconds, which is within Nginx’s default timeouts.

However, if you experience federation retries or dropped long-poll connections, you can extend the timeouts by adding these lines inside your location / blocks:

location / {
  proxy_pass http://tuwunel;
  proxy_set_header Host $host;
  proxy_set_header X-Forwarded-For $remote_addr;
  proxy_set_header X-Forwarded-Proto https;

  # Optional: Extend timeouts if experiencing issues
  proxy_read_timeout 300s;
  proxy_send_timeout 300s;
}

Enable the Configuration

If using sites-available/sites-enabled structure:

sudo ln -s /etc/nginx/sites-available/tuwunel /etc/nginx/sites-enabled/

Test the configuration:

sudo nginx -t

If the test passes, reload Nginx:

sudo systemctl reload nginx

Enable Nginx to start on boot:

sudo systemctl enable nginx

Verification

After configuring Nginx, verify it’s working by checking:

curl https://matrix.example.com/_tuwunel/server_version
curl https://matrix.example.com:8448/_tuwunel/server_version

Troubleshooting

Apache Compatibility Note

If you’re considering Apache instead of Nginx: Apache is not well-suited as a reverse proxy for Matrix homeservers. If you must use Apache, you need to use nocanon in your ProxyPass directive to prevent httpd from corrupting the X-Matrix authorization header, which will break federation.

Lighttpd is Not Supported

Lighttpd has known issues with the X-Matrix authorization header, making federation non-functional. We do not recommend using Lighttpd with Tuwunel.

=> Continue with “You’re Done”

Reverse Proxy Setup - Traefik

<= Back to Generic Deployment Guide

Installation

Install Traefik via your preferred method. You can read the official docker quickstart guide or the in-depth walkthrough

Configuration

TLS certificates

You can setup auto renewing certificates with different kinds of acme challenges.

Router configurations

Add tuwunel to your traefik’s network.

services:
    tuwunel:
    # ...
    networks:
        - proxy # your traefik network name
networks:
    proxy: # your traefik network name
        external: true

Be sure to change the your.server.name to your actual tuwunel domain. and the yourcertresolver should be changed to whatever you named it in your traefik config.

You only have to do any one of these methods below.

Labels

To use labels with traefik you need to configure a docker provider.

Then add the labels in your tuwunel’s docker compose file.

services:
    tuwunel:
        # ...
        labels:
            - "traefik.enable=true"
            - "traefik.http.routers.tuwunel.entrypoints=web"
            - "traefik.http.routers.tuwunel.rule=Host(`your.server.name`)"
            - "traefik.http.routers.tuwunel.middlewares=https-redirect@file"
            - "traefik.http.routers.tuwunel-secure.entrypoints=websecure"
            - "traefik.http.routers.tuwunel-secure.rule=Host(`your.server.name`)"
            - "traefik.http.routers.tuwunel-secure.tls=true"
            - "traefik.http.routers.tuwunel-secure.service=tuwunel"
            - "traefik.http.services.tuwunel.loadbalancer.server.port=6167"
            - "traefik.http.routers.tuwunel-secure.tls.certresolver=yourcertresolver"
            - "traefik.docker.network=proxy"

Config File

To use the config file you need to configure a file provider.

Then add this into your config file.

http:
    routers:
        tuwunel:
            entryPoints:
                - "web"
                - "websecure"
            rule: "Host(`your.server.name`)"
            middlewares:
                - https-redirect
            tls:
                certResolver: "yourcertresolver"
            service: tuwunel
    services:
        tuwunel:
            loadBalancer:
                servers:
            # this url should point to your tuwunel installation.
            # this should work if your tuwunel container is named tuwunel and is in the same network as traefik.
                    - url: "http://tuwunel:6167"
                passHostHeader: true

Client IP source

If Traefik is the only way clients can reach Tuwunel, set ip_source = "rightmost_x_forwarded_for" in tuwunel.toml so Tuwunel uses the trusted X-Forwarded-For value.

Federation

If you will use a .well-known file you can use traefik to redirect .well-known/matrix to tuwunel built-in .well-known file.

replace the rule in either of the methods from

Host(`your.server.name`)

to

Host(`your.tuwunel.domain`) || Host(`your.server.name`) && PathPrefix(`/.well-known/matrix`)

If you are not using a .well-known file you will need to add and expose port 8448 to a traefik entrypoint.

You can then add these to your preferred traefik config method. you should replace matrixfederationentry with what you named your entrypoint.

Labels:

            - "traefik.http.routers.matrix-federation.entrypoints=matrixfederationentry"
            - "traefik.http.routers.matrix-federation.rule=Host(`your.server.name`)"
            - "traefik.http.routers.matrix-federation.tls=true"
            - "traefik.http.routers.matrix-federation.service=matrix-federation"
            - "traefik.http.services.matrix-federation.loadbalancer.server.port=6167"
            - "traefik.http.routers.matrix-federation.tls.certresolver=yourcertresolver"

Config file:

        entryPoints:
            - "web"
            - "websecure"
            - "matrixfederationentry"

Important

Encoded Character Filtering options must be set to true. This only applies to traefik version 3.6.4 to 3.6.6 and 2.11.32 to 2.11.34

Verification

After starting Traefik, verify it’s working by checking:

curl https://your.server.name/_tuwunel/server_version
curl https://your.server.name:8448/_tuwunel/server_version

=> Continue with “You’re Done”

Example: using the root domain as the homeserver name

<= Back to Generic Deployment Guide

It is possible to host tuwunel on a subdomain such as matrix.example.com but delegate from example.com as the server name. This means that usernames will be @user:example.com rather than @user:matrix.example.com.

Federating servers and clients accessing tuwunel at example.com will attempt to discover the subdomain by accessing the example.com/.well-known/matrix/client and example.com/.well-known/matrix/server endpoints. These need to be set up to point back to matrix.example.com.

Note

In all of the following examples, replace matrix.example.com with the subdomain where tuwunel is hosted, <PORT> with the external port for federation, and example.com with the domain you want to use as the public-facing homeserver.

Configuration

Make sure the following are set in your configuration file or via environment variables:

1. Server name: set TUWUNEL_SERVER_NAME=example.com or in the configuration file:

   [global]

   # The server_name is the pretty name of this server. It is used as a
   # suffix for user and room IDs/aliases.
   #
   # See the docs for reverse proxying and delegation:
   # https://tuwunel.chat/deploying/generic.html#setting-up-the-reverse-proxy
   #
   # Also see the `[global.well_known]` config section at the very bottom.
   #
   # Examples of delegation:
   # - https://matrix.org/.well-known/matrix/server
   # - https://matrix.org/.well-known/matrix/client
   #
   # YOU NEED TO EDIT THIS. THIS CANNOT BE CHANGED AFTER WITHOUT A DATABASE
   # WIPE.
   #
   # example: "girlboss.ceo"
   #
   server_name = example.com


2. Client-server URL: set TUWUNEL_WELL_KNOWN__CLIENT=https://matrix.example.com or in the configuration file:

   [global.well_known]

   # The server URL that the client well-known file will serve. This should
   # not contain a port, and should just be a valid HTTPS URL.
   #
   # example: "https://matrix.example.com"
   #
   client = https://matrix.example.com


3. Server-server federation domain and port: where <PORT> is the external port for federation (default 8448, but often 443 when reverse proxying), set TUWUNEL_WELL_KNOWN__SERVER=matrix.example.com:<PORT> or in the configuration file:

   [global.well_known]

   # The server URL that the client well-known file will serve. This should
   # not contain a port, and should just be a valid HTTPS URL.
   #
   # example: "https://matrix.example.com"
   #
   client = https://matrix.example.com

   # The server base domain of the URL with a specific port that the server
   # well-known file will serve. This should contain a port at the end, and
   # should not be a URL.
   #
   # example: "matrix.example.com:443"
   #
   server = matrix.example.com:<PORT> # e.g. matrix.example.com:443


Serving .well-known endpoints

With the above configuration, tuwunel will generate and serve the appropriate /.well-known/matrix entries for delegation, so these can be served by reverse proxying /.well-known/matrix on example.com to tuwunel. Alternatively, if example.com is not behind a reverse proxy, static JSON files can be served directly.

Option 1: Static JSON files

At a minimum, the following JSON files should be created:

1. At example.com/.well-known/matrix/client:

   {
       "m.homeserver": {
           "base_url": "https://matrix.example.com/"
       }
   }


2. At example.com/.well-known/matrix/server (substituting <PORT> as above):

   {
       "m.server": "matrix.example.com:<PORT>" // e.g. "matrix.example.com:443"
   }


Option 2: Reverse proxy

These are example configurations if example.com is reverse-proxied behind Nginx or Caddy.

Note

Replace tuwunel with the URL where tuwunel is listening; this may look like 127.0.0.1:8008, matrix.example.com, or tuwunel if you declared an upstream tuwunel block.

Important

These configurations need to be applied to the reverse proxy for example.com, not matrix.example.com.

Caddy

example.com {
	reverse_proxy /.well-known/matrix/* https://matrix.example.com {
		header_up Host {upstream_hostport}
	}
}

Nginx

server {
  listen 443 ssl http2;
  listen [::]:443 ssl http2;
  server_name example.com;

  set $backend "tuwunel";

  location /.well-known/matrix/ {
    proxy_pass http://$backend:6167$request_uri;
    proxy_set_header X-Forwarded-For $remote_addr;
    proxy_ssl_server_name on;
  }

  # The remainder of your nginx configuration for example.com including SSL termination, other locations, etc.
}

Testing

Navigate to example.com/.well-known/matrix/client and example.com/.well-known/matrix/server. These should display results similar to the JSON snippets above.

Entering example.com in the Matrix federation tester should also work.

Additional resources

For a more complete guide, see the Matrix setup with Ansible and Docker documentation on setting up .well-known.

Tuwunel for Arch Linux

Currently Tuwunel is only on the Arch User Repository (AUR).

The Tuwunel AUR packages are community maintained and are not maintained by Tuwunel development team, but the AUR package maintainers are in the Matrix room. Please attempt to verify your AUR package’s PKGBUILD file looks fine before asking for support.

• tuwunel - latest tagged tuwunel
• tuwunel-bin - latest tagged tuwunel static binary

Tuwunel for Debian

Information about downloading and deploying the Debian package. This may also be referenced for other apt-based distros such as Ubuntu.

Installation

It is recommended to see the generic deployment guide for further information if needed as usage of the Debian package is generally related.

No apt repository is currently offered yet, it is in the works/development.

Configuration

When installed, the example config is placed at /etc/tuwunel/tuwunel.toml as the default config. The config mentions things required to be changed before starting.

You can tweak more detailed settings by uncommenting and setting the config options in /etc/tuwunel/tuwunel.toml.

Running

The package uses the tuwunel.service systemd unit file to start and stop Tuwunel. The binary is installed at /usr/sbin/tuwunel.

This package assumes by default that Tuwunel will be placed behind a reverse proxy. The default config options apply (listening on localhost and TCP port 6167). Matrix federation requires a valid domain name and TLS, so you will need to set up TLS certificates and renewal for it to work properly if you intend to federate.

Consult various online documentation and guides on setting up a reverse proxy and TLS. Caddy is documented at the generic deployment guide as it’s the easiest and most user friendly.

Tuwunel for FreeBSD

Tuwunel at the moment does not provide FreeBSD builds or have FreeBSD packaging, however Tuwunel does build and work on FreeBSD using the system-provided RocksDB.

Contributions for getting Tuwunel into ports are welcome.

Tuwunel for NixOS

Tuwunel can be acquired by Nix from various places:

• The flake.nix at the root of the repo
• The default.nix at the root of the repo
• From Tuwunel’s binary cache

A community maintained NixOS package is available at tuwunel

NixOS module

A NixOS module ships with Nixpkgs as services.matrix-tuwunel, available in 25.11 and unstable. It generates tuwunel.toml from a settings attrset and runs the server under a hardened systemd unit (DynamicUser, ProtectSystem=strict, strict SystemCallFilter).

Minimal configuration:

{
  services.matrix-tuwunel = {
    enable = true;
    settings.global = {
      server_name = "example.com";
      address = [ "127.0.0.1" "::1" ];
      port = [ 6167 ];
      allow_federation = true;
    };
  };
}

Notable defaults:

• User and group tuwunel (override via services.matrix-tuwunel.user / .group).
• Database under /var/lib/tuwunel/ (override via services.matrix-tuwunel.stateDirectory).
• Listens on 127.0.0.1 and ::1 port 6167.

Anything placed under settings.global is written verbatim into the [global] table of tuwunel.toml, so the configuration reference applies directly.

UNIX sockets

The module exposes unix_socket_path and unix_socket_perms directly:

services.matrix-tuwunel.settings.global = {
  unix_socket_path = "/run/tuwunel/tuwunel.sock";
  unix_socket_perms = 660;
};

Leave address unset (or null) when using a socket. The systemd unit already permits AF_UNIX, so no further overrides are needed.

Migrating from services.matrix-conduit

services.matrix-tuwunel replaces the legacy services.matrix-conduit module that older guides reference. Most settings carry over because both render the same TOML schema. When migrating:

• Disable services.matrix-conduit and enable services.matrix-tuwunel.
• Confirm the database is RocksDB. Tuwunel dropped SQLite in favor of RocksDB; if you ran a SQLite Conduit, migrate first with conduit_toolbox.
• Either set services.matrix-tuwunel.stateDirectory to match your existing database_path, or move the database under /var/lib/tuwunel/.

Tuwunel for Red Hat

Information about downloading and deploying the Red Hat package. This may also be referenced for other rpm-based distros such as CentOS.

Installation

It is recommended to see the generic deployment guide for further information if needed as usage of the RPM package is generally related.

No rpm repository is currently offered yet, it is in the works/development.

Configuration

When installed, the example config is placed at /etc/tuwunel/tuwunel.toml as the default config. The config mentions things required to be changed before starting.

You can tweak more detailed settings by uncommenting and setting the config options in /etc/tuwunel/tuwunel.toml.

Running

The package uses the tuwunel.service systemd unit file to start and stop Tuwunel. The binary is installed at /usr/sbin/tuwunel.

This package assumes by default that Tuwunel will be placed behind a reverse proxy. The default config options apply (listening on localhost and TCP port 8008). Matrix federation requires a valid domain name and TLS, so you will need to set up TLS certificates and renewal for it to work properly if you intend to federate.

Consult various online documentation and guides on setting up a reverse proxy and TLS. Caddy is documented at the generic deployment guide as it’s the easiest and most user friendly.

Podman / Quadlets

Podman and Quadlets are well supported on Redhat-based distributions. See Podman and systemd for examples.

Containers

Tuwunel ships as a small, statically linked OCI image that runs unprivileged on any container runtime. Pick a deployment style based on how you already manage services on the host.

• Docker. Pull prebuilt images from GHCR or Docker Hub, then run standalone or via one of the provided docker-compose stacks (with Caddy, Traefik, or a bring-your-own reverse proxy).

• Kubernetes. Community-maintained Helm chart for cluster deployments. Tuwunel itself does not scale horizontally, so the chart runs a single replica with persistent storage.

• Podman with Quadlets. Rootless deployment managed by systemd user units, suited to single-host setups where containers should behave like native services.

Image registries

Three rolling tags trade update frequency for confidence.

For automated updates we strongly advise tracking :latest.

Tuwunel for Docker

Docker

To run tuwunel with Docker you can either build the image yourself or pull it from a registry.

Use a registry

OCI images for tuwunel are available in the registries listed below.

Registry	Image	Size	Notes
GitHub Registry	ghcr.io/matrix-construct/tuwunel:latest		Most recent tagged release. Recommended for automated updates (~monthly).
Docker Hub	docker.io/jevolk/tuwunel:latest		Most recent tagged release. Recommended for automated updates (~monthly).
GitHub Registry	ghcr.io/matrix-construct/tuwunel:preview		Selected higher-confidence updates between releases (~weekly).
Docker Hub	docker.io/jevolk/tuwunel:preview		Selected higher-confidence updates between releases (~weekly).
GitHub Registry	ghcr.io/matrix-construct/tuwunel:main		Every reviewed merge to the main branch (~daily).
Docker Hub	docker.io/jevolk/tuwunel:main		Every reviewed merge to the main branch (~daily).

Run

When you have the image you can simply run it with

docker run -d -p 8448:8008 \
    -v db:/var/lib/tuwunel/ \
    -e TUWUNEL_SERVER_NAME="your.server.name" \
    -e TUWUNEL_ALLOW_REGISTRATION=false \
    --name tuwunel $LINK

or you can use docker compose.

The -d flag lets the container run in detached mode. You may supply an optional tuwunel.toml config file, the example config can be found here. You can pass in different env vars to change config values on the fly. You can even configure tuwunel completely by using env vars. For an overview of possible values, please take a look at the docker-compose.yml file.

If you just want to test tuwunel for a short time, you can use the --rm flag, which will clean up everything related to your container after you stop it.

Docker-compose

If the docker run command is not for you or your setup, you can also use one of the provided docker-compose files.

Depending on your proxy setup, you can use one of the following files:

• If you already have a traefik instance set up, use docker-compose.for-traefik.yml
• If you don’t have a traefik instance set up and would like to use it, use docker-compose.with-traefik.yml
• If you want a setup that works out of the box with caddy-docker-proxy, use docker-compose.with-caddy.yml and replace all example.com placeholders with your own domain
• For any other reverse proxy, use docker-compose.yml

When picking the traefik-related compose file, rename it so it matches docker-compose.yml, and rename the override file to docker-compose.override.yml. Edit the latter with the values you want for your server.

When picking the caddy-docker-proxy compose file, it’s important to first create the caddy network before spinning up the containers:

docker network create caddy

After that, you can rename it so it matches docker-compose.yml and spin up the containers!

Additional info about deploying tuwunel can be found here.

Run

If you already have built the image or want to use one from the registries, you can just start the container and everything else in the compose file in detached mode with:

docker compose up -d

Note: Don’t forget to modify and adjust the compose file to your needs.

Nix build

Tuwunel’s Nix images are built using buildLayeredImage. This ensures all OCI images are repeatable and reproducible by anyone, keeps the images lightweight, and can be built offline.

This also ensures portability of our images because buildLayeredImage builds OCI images, not Docker images, and works with other container software.

The OCI images are OS-less with only a very minimal environment of the tini init system, CA certificates, and the tuwunel binary. This does mean there is not a shell, but in theory you can get a shell by adding the necessary layers to the layered image. However it’s very unlikely you will need a shell for any real troubleshooting.

The flake file for the OCI image definition is at nix/pkgs/oci-image/default.nix.

To build an OCI image using Nix, the following outputs can be built:

• nix build -L .#oci-image (default features, x86_64 glibc)
• nix build -L .#oci-image-x86_64-linux-musl (default features, x86_64 musl)
• nix build -L .#oci-image-aarch64-linux-musl (default features, aarch64 musl)
• nix build -L .#oci-image-x86_64-linux-musl-all-features (all features, x86_64 musl)
• nix build -L .#oci-image-aarch64-linux-musl-all-features (all features, aarch64 musl)

Use Traefik as Proxy

As a container user, you probably know about Traefik. It is a easy to use reverse proxy for making containerized app and services available through the web. With the two provided files, docker-compose.for-traefik.yml (or docker-compose.with-traefik.yml) and docker-compose.override.yml, it is equally easy to deploy and use tuwunel, with a little caveat. If you already took a look at the files, then you should have seen the well-known service, and that is the little caveat. Traefik is simply a proxy and loadbalancer and is not able to serve any kind of content, but for tuwunel to federate, we need to either expose ports 443 and 8448 or serve two endpoints .well-known/matrix/client and .well-known/matrix/server.

With the service well-known we use a single nginx container that will serve those two files.

Voice communication

See the TURN page.

Podman, Quadlets, and systemd

For a rootless setup, we can use quadlets and systemd to manage the container lifecycle.

Important

If this is the first container managed with quadlets for your user, ensure that linger is enabled so your containers are not killed after logging out.

sudo loginctl enable-linger <username>

Step One

Copy quadlet files to ~/.config/containers/systemd/tuwunel

tuwunel.container

# tuwenel.container

[Unit]
Description=Tuwunel Matrix Homeserver

[Container]
ContainerName=tuwunel-homeserver
Image=ghcr.io/matrix-construct/tuwunel:latest
PublishPort=8008:8008
Volume=tuwunel-db:/var/lib/tuwunel/

#Example location in ~/tuwunel/config/
Volume=%h/tuwunel/config/tuwunel.toml:/etc/tuwunel.toml
EnvironmentFile=tuwunel.env

[Service]
# Uncomment when your system is properly configured, restart=always can mask start up errors.
#Restart=always

[Install]
WantedBy=default.target

tuwunel-db.volume

[Volume]
VolumeName=tuwunel-db

tuwunel.env

TUWUNEL_SERVER_NAME="your.server.tld"
TUWUNEL_PORT=8008
TUWUNEL_MAX_REQUEST_SIZE=20000000
TUWUNEL_ALLOW_REGISTRATION=true
TUWUNEL_REGISTRATION_TOKEN=<replace with a passphrase or random string>
TUWUNEL_ALLOW_FEDERATION=true
TUWUNEL_TRUSTED_SERVERS=["matrix.org"]
TUWUNEL_LOG=info

#Listen on this host for IPv4 and v6
TUWUNEL_ADDRESS=["0.0.0.0", "::"]

#Tell Tuwunel to use the user config file
TUWUNEL_CONFIG=/etc/tuwunel.toml

mkdir -p ~/.config/containers/systemd/tuwunel

Step Two

Modify tuwunel.env and tuwunel.toml to desired values. This can be saved in your user home directory if desired.

Step Three

• Reload daemon to generate our systemd unit files:

systemctl --user daemon-reload

Step Four

• Start tuwunel:

systemctl --user start tuwunel

Logging

To check the logs, run:

systemctl --user status tuwunel

or

podman logs tuwunel-homeserver

Troubleshooting systemd unit file generation

Look for errors in the output: /usr/lib/systemd/system-generators/podman-system-generator --user --dryrun

Tuwunel for Kubernetes

Tuwunel doesn’t support horizontal scalability or distributed loading natively, however a community maintained Helm Chart is available here to run Tuwunel on Kubernetes: https://github.com/AreYouLoco/tuwunel-helm and the legacy conduwuit version: https://gitlab.cronce.io/charts/conduwuit.

Should changes need to be made, please reach out to the maintainer in our Matrix room as this is not maintained/controlled by the Tuwunel maintainers.

Authentication systems

Tuwunel gives you fine-grained control over who can register and how users authenticate. This chapter covers everything from basic password login and token-based invitations to full OpenID Connect federation.

• Legacy Authentication — Control who can register, token-based invitations, guest access, and basic login options.

• Identity Providers — Single-sign-on login via GitHub, Google, Keycloak, and other OAuth/OIDC providers.

• OIDC Services — Tuwunel’s built-in OIDC authorization server for next-generation Matrix applications.

• LDAP Delegation — Delegate user management and password authentication to an LDAP directory.

• Enterprise JWT — Operator-controlled signing key can mint a token that authenticates as any user.

Legacy Authentication

By default, registration is disabled. You must explicitly enable it and choose what conditions, if any, a prospective user must meet before an account is created.

Enabling registration

Set allow_registration = true to enable registration. On its own this is not enough — you must also configure at least one of the following:

• A registration token (recommended)
• The open-registration confirmation flag (not recommended)
• One or more identity providers

Token-based registration

A registration token acts as a shared secret that prospective users must supply when creating an account. This is the recommended approach for private or invite-only servers.

Static token — set a single token directly in the config:

allow_registration = true
registration_token = "o&^uCtes4HPf0Vu@F20jQeeWE7"

File-based tokens — read tokens from a file, one per line or separated by whitespace. Useful for rotating tokens without restarting the server:

allow_registration = true
registration_token_file = "/etc/tuwunel/.reg_tokens"

Both options can be set at the same time; the file takes priority.

Admin-issued tokens — generate short-lived or single-use tokens from the admin room without touching the config file:

Open registration

To allow anyone to register without a token, you must set an additional confirmation flag that acknowledges the abuse risk:

allow_registration = true
yes_i_am_very_very_sure_i_want_an_open_registration_server_prone_to_abuse = true

This is not recommended for public-facing servers. Consider token-based registration or SSO providers instead.

Guest registration

Guest accounts are anonymous sessions that some clients (e.g. Element) create automatically before a user logs in. Guest registration is separate from normal registration and is disabled by default.

Login options

These options control which login methods are accepted regardless of how accounts were created.

Token and session lifetimes

Emergency password

The emergency password lets you log in to the server bot account (@conduit:<server_name>) when normal access is unavailable — for example, if you have lost access to your admin room.

emergency_password = "F670$2CP@Hw8mG7RY1$%!#Ic7YA"

Remove this option and restart the server once you have regained access — all sessions for the bot account are logged out when it is unset. See the troubleshooting guide for other recovery methods.

OIDC Server (Next-Gen Auth)

Tuwunel includes a built-in OIDC authorization server that implements next-generation Matrix authentication. Matrix clients that support next-gen auth interact with this server directly instead of using the legacy m.login.password or m.login.sso flows.

This implements the following MSCs:

• MSC2964 — OAuth 2.0 authorization code grant for Matrix
• MSC2965 — OIDC provider discovery and account management
• MSC2966 — Dynamic client registration (RFC 7591)
• MSC2967 — OAuth 2.0 API scopes for Matrix
• MSC3824 — OIDC-aware client hint (oidc_aware_preferred)
• MSC4312 — Cross-signing reset requiring SSO re-authentication for OIDC devices

Prerequisites

The OIDC server activates automatically when both of the following are configured:

1. At least one [[global.identity_provider]] block (see Identity Providers)
2. well_known.client in [global.well_known]:

[global.well_known]
client = "https://matrix.example.com"

The well_known.client URL becomes the OIDC issuer URL. If only one of the two prerequisites is met, Tuwunel logs a warning at startup and the OIDC server does not start.

Endpoints

Discovery

Authorization server

Account management UI

Dynamic Client Registration

Matrix clients that support next-gen auth register themselves with Tuwunel before initiating the authorization flow, using RFC 7591 dynamic client registration:

POST /_tuwunel/oidc/registration

No pre-configuration of clients is required — any Matrix client that supports dynamic registration can authenticate against Tuwunel’s OIDC server.

Account Management UI

Tuwunel serves a built-in account management page at /_tuwunel/oidc/account for users authenticated via OIDC. From this page users can:

• View all active OIDC sessions
• See which client and identity provider each session belongs to
• End individual sessions
• Edit their profile

The URL for this page is advertised in the authorization server metadata under account_management_uri (MSC4191).

Cross-Signing Protection (MSC4312)

Devices that authenticated via the OIDC server are tracked as “OIDC devices.” When such a device attempts to reset cross-signing keys, Tuwunel requires re-authentication via the original identity provider through the SSO UIAA flow. This prevents a compromised client from resetting cross-signing without the user actively re-authorizing through their identity provider.

Administrators can inspect which devices are OIDC devices using the admin query commands for OAuth sessions.

Signing Keys

Tuwunel generates and persists an ECDSA signing key on first startup, stored in the oidc_signingkey database table. The corresponding public key is served at /_tuwunel/oidc/jwks. This key signs ID tokens (JWTs) issued by the token endpoint.

Startup Warnings

If an [[global.identity_provider]] is configured but well_known.client is missing, Tuwunel logs:

OIDC server (Next-gen auth) requires `well_known.client` to be configured to serve your `identity_provider`.

The OIDC server will not start. Traditional SSO (legacy m.login.sso flow) continues to work without the OIDC server.

LDAP Authentication

Tuwunel can authenticate password logins against an LDAP directory. When a user logs in with m.login.password, Tuwunel locates them in the directory, verifies the password by binding as that user, and creates a Matrix account on first successful login if one does not yet exist.

LDAP support is a compile-time feature. It is not part of the default build — you must compile with --features ldap (or use a release artifact that already includes it) before any of the configuration below has effect.

Enabling LDAP

LDAP is configured under a single [global.ldap] section. The minimum to enable it is the enable flag and a uri:

[global.ldap]
enable = true
uri = "ldaps://ldap.example.org:636"
base_dn = "ou=users,dc=example,dc=org"

The URI scheme decides the transport: ldap:// is plaintext, ldaps:// upgrades to TLS using the system’s installed CAs.

When enable = true, every m.login.password request is routed through LDAP first. Local password authentication still happens as a fallback when the LDAP search returns zero matches — useful for the bootstrap admin account or for service users that should not exist in the directory. If the LDAP search returns two or more matches the login is rejected.

Bind modes

Tuwunel supports three bind strategies, selected by what you put in bind_dn and bind_password_file.

Search-then-bind (recommended)

A service account binds to the directory, searches for the user, then Tuwunel re-binds as the user with the supplied password to verify it. This mode is required if you want admin synchronization (see below).

[global.ldap]
enable = true
uri = "ldaps://ldap.example.org:636"
base_dn = "ou=users,dc=example,dc=org"
bind_dn = "cn=ldap-reader,dc=example,dc=org"
bind_password_file = "/etc/tuwunel/.ldap_bind_password"
filter = "(&(objectClass=person)(memberOf=cn=matrix,ou=groups,dc=example,dc=org))"

The bind password is read from bind_password_file rather than placed inline in the config. The file must be readable by the Tuwunel process and must not be empty.

Anonymous search-then-bind

If your directory permits anonymous searches, omit both bind_dn and bind_password_file. Tuwunel skips the initial bind and queries the directory unauthenticated, then re-binds as the user to verify the password.

Direct bind

If bind_dn contains the literal substring {username}, Tuwunel skips the search entirely and binds directly with that DN, substituting the user’s localpart for {username} and using the supplied login password as the bind password:

[global.ldap]
enable = true
uri = "ldaps://ldap.example.org:636"
bind_dn = "cn={username},ou=users,dc=example,dc=org"

This is the simplest mode but has two limitations: it cannot apply a search filter (so anyone in the bind DN’s subtree can log in), and admin synchronization does not work because Tuwunel never gets a chance to query the directory under a service account.

Configuration reference

The localpart match is case-insensitive — Tuwunel sends a lowercased version of the localpart through {username} substitution and accepts an entry if either the original or lowercased form appears in uid_attribute or name_attribute.

Admin synchronization

Setting admin_filter to a non-empty value turns the LDAP directory into the source of truth for who is a Tuwunel admin. On every successful LDAP login, Tuwunel runs a second search rooted at admin_base_dn (or base_dn if empty) using admin_filter. Membership in the result set is compared against the user’s current admin status in Tuwunel:

• In LDAP admin set, not a Tuwunel admin → granted admin.
• Not in LDAP admin set, currently a Tuwunel admin → admin revoked.
• Otherwise → no change.

Two examples:

# Admins are users with a custom objectClass.
admin_filter = "(objectClass=tuwunelAdmin)"

# Admins are members of an LDAP group, looked up under a different subtree.
admin_base_dn = "ou=admins,dc=example,dc=org"
admin_filter = "(uid={username})"

Admin synchronization only runs in the search-then-bind modes. In direct-bind mode the admin search is silently skipped — manage admins manually with !admin users make-admin and !admin users revoke-admin if you need that combination.

Account lifecycle

The first time a user successfully authenticates against LDAP, Tuwunel auto-creates a local Matrix account for them (the same way Synapse, Nextcloud, and Jellyfin behave). The account is registered with origin "ldap" and a placeholder password value — the local password field is never consulted for an LDAP user, so they can only log in by re-authenticating against the directory.

Subsequent logins reuse the existing account and only update admin status if admin_filter is configured.

Deactivating a user in LDAP prevents future logins but does not automatically deactivate or delete the corresponding Matrix account. Use !admin users deactivate if you also want to remove access to existing sessions and devices.

Admin commands for testing

Two admin commands invoke the LDAP code paths directly without going through the login API. They are useful for verifying that filter, uid_attribute, bind_dn, and TLS configuration produce the expected results.

Both commands are gated by the ldap build feature.

Disabling password login for non-LDAP users

Tuwunel’s LDAP integration always falls back to local password verification when the LDAP search returns no matches. To enforce LDAP-only login for everyone (apart from accounts that authenticate via SSO), pair LDAP with a restrictive filter that matches every legitimate user, and remove or invalidate local passwords for accounts that should no longer be able to log in directly. Alternatively, set login_with_password = false and rely on identity providers for non-LDAP users.

JSON web token for enterprise

Tuwunel can accept signed JSON Web Tokens as proof of identity, both as a login flow (POST /_matrix/client/v3/login with type = org.matrix.login.jwt) and as a User-Interactive Authentication step for sensitive operations.

This is an enterprise feature intended for managed deployments where identity is owned by an external system. Two typical uses:

• Externalized user management. A hosting provider or corporate identity service mints short-lived JWTs for its users; Tuwunel becomes a stateless consumer of those tokens and creates Matrix accounts on first login.

• Account override. An operator-controlled signing key can mint a token that authenticates as any user for password resets, key recovery, or legal compliance without modifying the user’s credentials.

Enabling JWT

The minimum configuration to accept JWTs is enable = true and a key:

[global.jwt]
enable = true
key = "yJKn0!E2g$5Hs!rUv9NQwL@ZmpQ3xVT"

With these defaults, Tuwunel will accept any HS256-signed token whose sub claim is the localpart of an MXID on this server.

POST /_matrix/client/v3/login then accepts:

{
  "type": "org.matrix.login.jwt",
  "token": "<jwt>"
}

GET /_matrix/client/v3/login advertises the flow as long as enable = true.

The sub (subject) claim is the localpart of the user’s MXID. Tuwunel combines it with this server’s server_name to form the full MXID. The subject is lowercased before lookup.

For a server with server_name = "matrix.example.org", a token with "sub": "alice" authenticates as @alice:matrix.example.org. The token issuer must agree with the server on this naming.

Configuration reference

key is also accepted under the alias secret to match Synapse config files.

Migrating from Synapse

Synapse’s JWT support uses a configuration of similar shape. To migrate a Synapse experimental_features.jwt_config block:

Synapse defaults to optional exp/nbf and accepts the localpart in the sub claim. Tuwunel matches both behaviors out of the box, so a straight key+algorithm port should authenticate the same set of tokens.

Account lifecycle

The first time a token authenticates as a user that does not yet exist:

• If register_user = true, Tuwunel creates the account with origin "jwt" and a placeholder password marker. The local password field is never read for a JWT-authenticated user — they can only re-authenticate by presenting another valid JWT.
• If register_user = false, the request fails with M_NOT_FOUND and the account is not created.

Subsequent logins reuse the existing account.

JWT does not synchronize admin status, group membership, or display names — the token grants login only. If you need ongoing identity attribute synchronization, use LDAP or an OIDC identity provider instead.

UIAA — JWT for account override

When enable = true, the m.login.jwt UIAA stage becomes available alongside m.login.password and m.login.sso for sensitive operations that require interactive re-authentication (deactivate account, change password, add 3PID, etc.).

A JWT presented at the UIAA stage validates the user but does not auto-register: the token’s subject must already exist as a Matrix account. This restriction prevents an account-override flow from accidentally creating new accounts when an operator intends only to substitute identity for an existing one.

A typical operator workflow for a forced password reset:

1. Sign a JWT with sub set to the target user’s localpart.

2. Submit it as the auth field of POST /_matrix/client/v3/account/password:

   {
     "auth": {
       "type": "org.matrix.login.jwt",
       "token": "<jwt>"
     },
     "new_password": "<new password>"
   }


3. Tuwunel validates the signature, confirms the user exists, and completes the password change without ever consulting the user’s existing credentials.

Limit access to the signing key accordingly. Anyone with the HMAC secret, or the matching ECDSA/EdDSA private key, can authenticate as any user on the server.

Key formats and algorithms

format selects how key is interpreted. algorithm selects the JWT signing algorithm. The two must agree.

For asymmetric formats (ECDSA, EDDSA) the key is the public key — Tuwunel only verifies, it never signs. The corresponding private key stays with the issuer.

# HMAC shared secret (Synapse-compatible default)
format = "HMAC"
algorithm = "HS256"
key = "..."

# ECDSA public-key
format = "ECDSA"
algorithm = "ES256"
key = """-----BEGIN PUBLIC KEY-----
MFkwEwYHKoZIzj0CAQYIKoZIzj0DAQcDQgAE...
-----END PUBLIC KEY-----"""

Time-bounded tokens

exp (expiration) and nbf (not-before) follow the spec semantics: seconds since the Unix epoch. Configure based on the issuer’s behavior:

• Issuer always sets exp — set require_exp = true to reject any token without an expiration. validate_exp is true by default.
• Issuer never sets exp — leave both require_exp and validate_exp at their defaults; tokens without exp are accepted as non-expiring (use cautiously).
• Mixed — leave require_exp = false and validate_exp = true (the defaults). This is Synapse-compatible: exp is optional but enforced when present.

nbf is symmetric with exp and most deployments leave it unset on both issuer and consumer.

Audience and issuer validation

By default no aud or iss validation is performed. To restrict acceptance to tokens issued by, or destined for, specific systems, set the respective config field:

audience = ["https://matrix.example.org"]
issuer   = ["https://idp.example.org"]

When set, the corresponding claim becomes required in addition to being checked against the allowed list. Multiple values are treated as “any of these is acceptable.”

Identity Providers

Tuwunel can delegate login to external OAuth/OIDC identity providers. Each configured provider appears as an option on the client’s login page. Users are redirected to the provider to authenticate, then returned to Tuwunel which maps their identity to a Matrix account.

Provider guides

• Authelia
• Authentik
• Keycloak
• Please contribute documentation for yours here!

Configuring Tuwunel

Each provider is a [[global.identity_provider]] table in your configuration file. Multiple providers can be configured by repeating the table header. Container users please refer to the section on environment variables instead.

Required fields

Authentication

Discovery

Callback

Login behavior

User ID mapping

URL overrides

These override endpoints that are normally discovered automatically. Only use them for non-standard or undiscoverable providers.

Session

Configuring via environment variables

For container deployments (Docker Compose, Podman, Kubernetes) where mounting a configuration file is inconvenient, every provider field can be set via environment variables instead.

The variable name is built from three parts joined by __ (double underscore):

TUWUNEL_IDENTITY_PROVIDER__<index>__<FIELD>

• TUWUNEL_IDENTITY_PROVIDER — fixed prefix that maps to the [[global.identity_provider]] table array.
• <index> — an arbitrary string (typically 0, 1, 2, …) that groups variables belonging to the same provider. All variables sharing the same index are treated as a single [[global.identity_provider]] entry. Indexes are sorted lexicographically, so numeric indexes give a predictable order.
• <FIELD> — the field name from the tables below, uppercased.

Multiple providers are expressed by using different indexes:

# First provider — GitHub
TUWUNEL_IDENTITY_PROVIDER__0__BRAND="github"
TUWUNEL_IDENTITY_PROVIDER__0__CLIENT_ID="Ov23liYourGitHubClientId"
TUWUNEL_IDENTITY_PROVIDER__0__CLIENT_SECRET="your_github_secret"
TUWUNEL_IDENTITY_PROVIDER__0__CALLBACK_URL="https://matrix.example.com/_matrix/client/unstable/login/sso/callback/Ov23liYourGitHubClientId"

# Second provider — Google (marked as default)
TUWUNEL_IDENTITY_PROVIDER__1__BRAND="google"
TUWUNEL_IDENTITY_PROVIDER__1__CLIENT_ID="123456789-abc.apps.googleusercontent.com"
TUWUNEL_IDENTITY_PROVIDER__1__CLIENT_SECRET="GOCSPX-your_secret"
TUWUNEL_IDENTITY_PROVIDER__1__CALLBACK_URL="https://matrix.example.com/_matrix/client/unstable/login/sso/callback/123456789-abc.apps.googleusercontent.com"
TUWUNEL_IDENTITY_PROVIDER__1__DEFAULT="true"

Every field listed in the tables below has a matching environment variable. For example, trusted = true in TOML becomes TUWUNEL_IDENTITY_PROVIDER__0__TRUSTED="true".

Example configurartions

GitHub

[[global.identity_provider]]
brand = "GitHub"
client_id = "Ov23liYourGitHubClientId"
client_secret = "your_github_client_secret"
callback_url = "https://matrix.example.com/_matrix/client/unstable/login/sso/callback/Ov23liYourGitHubClientId"

GitHub’s issuer_url and base_path are pre-configured. client_id doubles as the provider ID in the callback URL.

Google

[[global.identity_provider]]
brand = "Google"
client_id = "123456789-abc.apps.googleusercontent.com"
client_secret = "GOCSPX-your_secret"
callback_url = "https://matrix.example.com/_matrix/client/unstable/login/sso/callback/123456789-abc.apps.googleusercontent.com"

Self-hosted Keycloak

[[global.identity_provider]]
brand = "Keycloak"
client_id = "tuwunel"
client_secret = "your_keycloak_secret"
issuer_url = "https://sso.example.com/realms/myrealm"
callback_url = "https://matrix.example.com/_matrix/client/unstable/login/sso/callback/tuwunel"
trusted = true

With trusted = true, users whose Keycloak username matches an existing Matrix localpart are granted access to that account. Only use trusted when you control the identity provider.

Matrix Authentication Service (MAS)

[[global.identity_provider]]
brand = "MAS"
client_id = "your_mas_client_id"
client_secret = "your_mas_secret"
issuer_url = "https://auth.example.com"
callback_url = "https://matrix.example.com/_matrix/client/unstable/login/sso/callback/your_mas_client_id"

Common setup patterns

Linking existing users to an identity provider

When SSO is added to a server that already has password-based accounts, the central question is: how does Tuwunel know which provider identity belongs to which existing Matrix account?

The most direct approach is to set trusted = true and list "sub" in userid_claims. The sub claim is the stable, globally unique user identifier that every OIDC provider is required to maintain. Listing it in userid_claims tells Tuwunel to use it as the authoritative match key. Marking the provider as trusted then inverts Tuwunel’s normal logic: instead of registering a new account when it finds no existing match, it looks for an existing Matrix account whose localpart equals the sub value and grants access to it. The result is that logging in through the provider seamlessly picks up the user’s existing account:

[[global.identity_provider]]
brand = "Keycloak"
client_id = "tuwunel"
# ...
trusted = true
userid_claims = ["sub"]

For this to work, the sub value the provider returns for each user must match that user’s Matrix localpart exactly. If your provider allows you to set sub to an arbitrary value, aligning it with the Matrix localpart is the cleanest path. If it does not — for example, if sub is an opaque UUID — you can use a different claim (such as preferred_username) as the match key, or pre-register the link with the admin command described below.

Only ever set trusted = true for identity providers you self-host and fully control. In trusted mode, anyone who can present a matching provider identity gains access to the corresponding Matrix account. Public providers such as GitHub and Google must never be trusted.

Admin-approved association for untrusted providers

When the provider is not trusted — a public service such as GitHub or Google where trusted = true would be unsafe — you can still link an existing Matrix account to a specific provider identity by having an admin pre-approve the connection before the user’s next login.

The admin command registers a set of claims to watch for from that provider. When the user next authenticates, Tuwunel checks the claims returned by the provider against any pending approvals. If every claim in the approval matches what the provider returns, the accounts are linked and the approval is consumed.

!admin query oauth associate <provider_id> @alice:example.com \
  --claim sub=550e8400-e29b-41d4-a716-446655440000

Specify whichever claims uniquely identify the user on that provider. sub is the most reliable because every OIDC provider guarantees it is stable and unique per user.

Pending approvals are held in memory, not the database. The affected user must complete their login before the server is restarted, or the command must be run again.

How Tuwunel derives Matrix user IDs from claims

When a user authenticates through a provider for the first time and no existing account is linked, Tuwunel must compute a Matrix localpart from the claims in the provider’s userinfo response. It tries each of the following in order, using the first claim that is present and yields a valid, available username:

1. preferred_username
2. username
3. nickname
4. login
5. email — only the portion before the @ is used

The sub claim is deliberately excluded from this default sequence because it is typically an opaque identifier rather than a human-readable name. It is only consulted when explicitly listed in userid_claims, where it always takes precedence over every other claim regardless of list order.

If none of these five claims appear in the userinfo response, or if every derived candidate is already taken by another account, Tuwunel falls back to a randomly generated localpart. This fallback is controlled by unique_id_fallbacks, which defaults to true. On private servers where silent random assignment is unacceptable, set it to false — Tuwunel will return an error instead.

Make sure user profiles on your identity provider contain at least one of the five claims above. If a profile has none of them, Tuwunel has nothing to work with and will resort to the random fallback. The safest choice is to ensure preferred_username is populated on every account, as it is the first claim Tuwunel checks and tends to hold a recognisable, human-readable name that also makes a reasonable Matrix localpart.

The userid_claims field lets you restrict which claims Tuwunel considers and in what order. For example, to use only preferred_username and fall back to the local part of the email address, and never silently generate a random ID:

userid_claims = ["preferred_username", "email"]
unique_id_fallbacks = false

Listing "sub" anywhere in userid_claims elevates it to the highest priority, overriding all other entries. The special value "unique" used alone instructs Tuwunel to always generate a unique random localpart and never attempt to derive one from claims at all.

Multiple providers

When multiple providers are configured, each appears separately on the client’s login page (unless single_sso = true). The default field controls which provider /_matrix/client/v3/login/sso/redirect (without a provider ID) redirects to:

[[global.identity_provider]]
brand = "GitHub"
client_id = "github_client_id"
# ...
default = true   # this provider handles the bare SSO redirect

[[global.identity_provider]]
brand = "Google"
client_id = "google_client_id"
# ...

If no provider is explicitly default and exactly one is configured, it becomes the implicit default.

Global SSO options

These top-level options control how SSO providers are presented to clients.

Admin commands

These admin room commands help manage OAuth state:

Protocol flow reference

1. The client fetches /_matrix/client/v3/login and finds an m.login.sso entry listing configured providers.
2. The user selects a provider; the client redirects to /_matrix/client/v3/login/sso/redirect/<client_id>.
3. Tuwunel redirects the user to the provider’s authorization endpoint.
4. The provider authenticates the user and redirects back to /_matrix/client/unstable/login/sso/callback/<client_id>.
5. Tuwunel exchanges the code for tokens, fetches user claims, maps them to a Matrix user ID, and issues a login token back to the client.

Authelia

Authelia configuration

Add the client in Authelia’s config. The client secret in Authelia must be stored as a hash; use the Authelia CLI generator to produce it (the hash always starts with $pbkdf2).

identity_providers:
  oidc:
    claims_policies:
      tuwunel:
        id_token: ["email", "name", "groups", "preferred_username"]
    clients:
      - client_id: '<client_id>'
        client_name: 'tuwunel'
        client_secret: '<client_secret_hash>'
        claims_policy: "tuwunel"
        public: false
        redirect_uris:
          - "https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>"
        scopes:
          - 'openid'
          - 'groups'
          - 'email'
          - 'profile'
        grant_types:
          - 'refresh_token'
          - 'authorization_code'
        response_types:
          - 'code'
        response_modes:
          - 'form_post'
        token_endpoint_auth_method: 'client_secret_post'

Tuwunel configuration

Note

The client_secret value here is the plain-text password, not the hash stored in Authelia. Authelia stores the hash; Tuwunel supplies the password.

[[global.identity_provider]]
brand = "Authelia"
name = "Authelia"
client_id = "<client_id>"
client_secret = "<client_secret_password>"
issuer_url = "https://<your.authelia.example.com>"
callback_url = "https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>"

See the Authelia OIDC documentation for full details on the provider side.

Authentik

Authentik is a self-hostable identity provider that speaks OpenID Connect.

Note

This guide was written against Authentik 2025.10; the flow is the same on all later versions through at least 2026.2.

Authentik configuration

From the admin interface, navigate to Applications > Applications and select Create with Provider. Review the items below and click Submit.

Application

• Application name: the user-facing name shown to your users on the Authentik side.
• Slug: appears in the issuer URL on the tuwunel side. Pick something short and stable, such as tuwunel.

Provider

Select OAuth2/OpenID Provider.

• Authorization flow: any built-in flow is fine if you have not created custom ones.
• Client ID and Client Secret: Authentik generates these. Save both values — tuwunel needs them.
• Redirect URIs/Origins: set this to https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>, substituting your Matrix server’s public hostname and the Client ID from the previous step.
• All other fields can stay at their defaults.

Bindings

Optional. Add policies here to restrict tuwunel access to a subset of your Authentik users.

Tuwunel configuration

Add an [[global.identity_provider]] entry to your tuwunel.toml:

[[global.identity_provider]]
brand = "Authentik"
client_id = "<client_id>"
client_secret = "<client_secret>"
issuer_url = "https://<your.authentik.example.com>/application/o/<slug>/"
callback_url = "https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>"

issuer_url is the application’s slug-based path with a trailing slash. This is the value Authentik returns as the iss claim in issued tokens, and tuwunel discovers all other endpoints from <issuer_url>.well-known/openid-configuration automatically.

If your Authentik instance reports a different iss — for example when running behind a path prefix, or with a non-default Issuer Mode on the provider — override discovery directly:

discovery_url = "https://<your.authentik.example.com>/application/o/<slug>/.well-known/openid-configuration"

Tip

For the full set of identity provider options see the providers reference. For the Authentik side, see the OAuth2/OpenID Connect provider documentation.

Customising the Matrix localpart

By default tuwunel derives a new user’s Matrix localpart from the preferred_username claim Authentik returns — see How tuwunel derives Matrix user IDs from claims. The default Authentik mapping populates preferred_username with the user’s Authentik username, so user foo becomes @foo:example.com.

To decouple the two — for example to give Authentik user foo the localpart @bar:example.com — replace Authentik’s default profile scope with a custom property mapping that returns the localpart you want.

Create a custom property mapping

In the admin interface, navigate to Customization > Property Mappings and select Create. Choose Scope Mapping, then set the Scope name to profile.

In Expression, return a dictionary that exposes the desired localpart as preferred_username. The example below uses a per-user matrix_localpart attribute when set, falling back to the Authentik username:

if "matrix_localpart" in request.user.attributes:
    return {
        "name": request.user.name,
        "given_name": request.user.name,
        "preferred_username": request.user.attributes["matrix_localpart"],
        "nickname": request.user.attributes["matrix_localpart"],
        "groups": [group.name for group in request.user.ak_groups.all()],
    }
return {
    "name": request.user.name,
    "given_name": request.user.name,
    "preferred_username": request.user.username,
    "nickname": request.user.username,
    "groups": [group.name for group in request.user.ak_groups.all()],
}

Note the Name you give the mapping, then click Finish.

Replace the default profile mapping

In Applications > Providers, edit your tuwunel provider, expand Advanced protocol settings, and find the Scopes field.

Move your new mapping from Available Scopes into Selected Scopes with the right arrow (>), then move authentik default OAuth Mapping: OpenID 'profile' out with the left arrow (<). Click Update.

Set the attribute on a user

In Directory > Users, edit the user and add to Attributes:

matrix_localpart: bar

Click Update.

Tip

Users can be allowed to set the attribute themselves through a custom prompt in a Stage Configuration flow. See Authentik’s documentation for details.

Verify

In Applications > Providers, open your provider and click Preview. Select the user under Preview for user; the JWT payload should contain the customised localpart:

{
    "preferred_username": "bar",
    "nickname": "bar"
}

Keycloak

Keycloak is a self-hostable OpenID Connect provider.

Keycloak configuration

1. Create a client on your Keycloak server:

   • Enable Client Authentication.
   • Set Root URL to https://<your.matrix.example.com>.
   • Add a Valid Redirect URI: https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>
   • Set Web Origins to https://<your.matrix.example.com>.

2. Navigate to the Credentials tab and note the Client Secret.

3. Note the realm you created the client in.

Tuwunel configuration

Important

Ensure your Matrix .well-known values are being served correctly before starting. You can verify them with matrixtest.

Add the following to your tuwunel.toml. Replace the placeholders with the values from your Keycloak client.

[[global.identity_provider]]
brand = "Keycloak"
client_id = "<client_id_in_keycloak>"
client_secret = "<client_secret_from_credentials_tab>"
issuer_url = "https://<your.keycloak.example.com>/realms/<realm_name>"
callback_url = "https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id_in_keycloak>"
trusted = true

Setting trusted = true allows users whose Keycloak username matches an existing Matrix localpart to log in to that account via SSO. Only use this for identity providers you self-host and fully control — see Linking existing users.

Environment variables

If you prefer environment variables (e.g. in docker-compose.yaml or a tuwunel.env file):

TUWUNEL_IDENTITY_PROVIDER__0__BRAND="keycloak"
TUWUNEL_IDENTITY_PROVIDER__0__CLIENT_ID="<client_id>"
TUWUNEL_IDENTITY_PROVIDER__0__CLIENT_SECRET="<client_secret>"
TUWUNEL_IDENTITY_PROVIDER__0__ISSUER_URL="https://<your.keycloak.example.com>/realms/<realm_name>"
TUWUNEL_IDENTITY_PROVIDER__0__CALLBACK_URL="https://<your.matrix.example.com>/_matrix/client/unstable/login/sso/callback/<client_id>"
TUWUNEL_IDENTITY_PROVIDER__0__TRUSTED="true"

Multimedia and storage provision

Tuwunel handles media uploads, remote media fetching, thumbnail generation, URL previews, and blurhash generation. This chapter covers configuration for all of these features, as well as the storage backends that back them.

• Storage providers — Local filesystem and S3-compatible object storage backends.

• Media management — Commands for inspecting, deleting, and bulk-removing media, including spam response.

Upload limits

Legacy media endpoints

Matrix spec version 1.11 introduced authenticated media endpoints. The older unauthenticated endpoints are deprecated but some clients and servers still use them.

Blocking remote media

prevent_media_downloads_from is a list of regex patterns matched against server names. Tuwunel refuses to download media originating from any matching server.

prevent_media_downloads_from = [
  "badserver\\.tld$",
  "spammy-phrase",
]

This is useful as a reactive measure after a spam incident. See the Management page for bulk-deletion commands to pair with it.

URL previews

URL previews are disabled unless at least one allowlist is configured. All allowlist checks are evaluated before the denylist check.

Note

Setting any allowlist to ["*"] opens significant attack surface — a malicious client could cause the server to make requests to arbitrary URLs on the local network. Use explicit allowlists wherever possible.

Blurhash

Tuwunel can generate blurhashes for uploaded images, which clients use to show a blurred placeholder before the full image loads. This requires the blurhashing compile-time feature.

Blurhash settings live in a dedicated config section:

[global.blurhashing]
components_x = 4
components_y = 3
blurhash_max_raw_size = 33554432

Storage providers

Tuwunel stores media through a configurable provider layer that abstracts over local filesystem and S3-compatible object storage. Multiple providers can be active simultaneously, which enables zero-downtime migrations.

Default storage

Without any explicit configuration, Tuwunel stores media in a subdirectory called media/ inside your database_path. This is represented internally as the implicit provider named "media".

# These are the effective defaults — no configuration required
media_storage_providers = ["media"]
store_media_on_providers = []

When store_media_on_providers is empty, all providers in media_storage_providers receive new uploads. With only the implicit "media" provider active, this is simply the local filesystem.

Configuring providers

Providers are declared as TOML sections named [global.storage_provider.<NAME>.<brand>], where <NAME> is the identifier you reference in media_storage_providers, and <brand> is either local or s3. For container deployments (Docker Compose, Podman, Kubernetes) where mounting a configuration file is inconvenient, please refer to the section on environment variables instead.

Local filesystem

[global.storage_provider.media.local]
base_path = "/var/lib/tuwunel/media"
create_if_missing = false
delete_empty_directories = true
startup_check = true

S3 and S3-compatible storage

[global.storage_provider.media_on_s3.s3]
bucket = "my-matrix-media"
region = "us-east-1"
key    = "AKIAIOSFODNN7EXAMPLE"
secret = "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY"

Alternatively, supply a full S3 URL that encodes bucket, region, and path:

[global.storage_provider.media_on_s3.s3]
url    = "s3://my-matrix-media/prefix"
key    = "AKIAIOSFODNN7EXAMPLE"
secret = "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY"

S3 configuration reference

Self-hosted S3-compatible services

For MinIO, DigitalOcean Spaces, Cloudflare R2, and similar services, set the endpoint field and disable virtual-hosted-style requests if required:

[global.storage_provider.media_on_s3.s3]
endpoint         = "https://minio.example.com:9000"
bucket           = "matrix-media"
region           = "us-east-1"
key              = "minioadmin"
secret           = "minioadmin"
use_vhost_request = false

Environment variables

The variable name is built from four parts joined by __ (double underscore):

TUWUNEL_STORAGE_PROVIDER__<NAME>__<brand>__<FIELD>

• TUWUNEL_STORAGE_PROVIDER — fixed prefix that maps to [global.storage_provider].
• <NAME> — the provider name you reference in media_storage_providers (e.g., MEDIA, MEDIA_ON_S3).
• <brand> — the provider type: LOCAL or S3.
• <FIELD> — the field name from the tables below, uppercased.

Local filesystem example

TUWUNEL_STORAGE_PROVIDER__MEDIA__LOCAL__BASE_PATH="/var/lib/tuwunel/media"
TUWUNEL_STORAGE_PROVIDER__MEDIA__LOCAL__CREATE_IF_MISSING="false"

S3 example

TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__BUCKET="my-matrix-media"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__REGION="us-east-1"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__KEY="AKIAIOSFODNN7EXAMPLE"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__SECRET="wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY"

Self-hosted S3-compatible example

TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__ENDPOINT="https://minio.example.com:9000"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__BUCKET="matrix-media"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__REGION="us-east-1"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__KEY="minioadmin"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__SECRET="minioadmin"
TUWUNEL_STORAGE_PROVIDER__MEDIA_ON_S3__S3__USE_VHOST_REQUEST="false"

The media_storage_providers and store_media_on_providers lists are top-level settings and follow the standard env var pattern using TOML array syntax:

TUWUNEL_MEDIA_STORAGE_PROVIDERS='["media", "media_on_s3"]'
TUWUNEL_STORE_MEDIA_ON_PROVIDERS='["media_on_s3"]'

Migrating to a new storage provider

To migrate from local storage to S3 (or between any two providers) without downtime:

Step 1 — Add the new provider and list both in media_storage_providers, but direct new writes only to the new one via store_media_on_providers:

media_storage_providers  = ["media", "media_on_s3"]
store_media_on_providers = ["media_on_s3"]

[global.storage_provider.media_on_s3.s3]
bucket = "my-matrix-media"
region = "us-east-1"
key    = "AKIAIOSFODNN7EXAMPLE"
secret = "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY"

Tuwunel now writes new media to S3 and reads from whichever provider holds the file, falling back to local if not found on S3.

Step 2 — Copy existing files to the new provider using the storage sync admin command:

!admin query storage sync media media_on_s3

This copies all objects present in media but absent from media_on_s3.

Step 3 — Once the sync is complete and verified, remove "media" from both lists and restart:

media_storage_providers  = ["media_on_s3"]
store_media_on_providers = []

Storage admin commands

These commands are available via !admin query storage and operate directly on provider objects. They are useful for diagnostics, manual migrations, and verifying provider state.

Startup checks

These options control what Tuwunel verifies about stored media at startup.

Media management

Tuwunel provides a set of admin room commands for inspecting and deleting media. All commands are invoked in the admin room and prefixed with !admin media.

Inspecting media

get-file-info

!admin media get-file-info <mxc_uri>

Returns the stored metadata for a media file: content type, file size, creation time, and which user uploaded it. Useful for investigating a reported file before deciding whether to delete it.

get-remote-file

!admin media get-remote-file <mxc_uri> [-s <server>] [-t <timeout_ms>]

Fetches a remote media file from the originating server and returns its metadata. The actual content is discarded after fetching so the admin room is not flooded. Default timeout is 10 000 ms.

get-remote-thumbnail

!admin media get-remote-thumbnail <mxc_uri> \
  [-s <server>] [-t <timeout_ms>] [--width <px>] [--height <px>]

Like get-remote-file but requests a thumbnail at the given dimensions (default 800×800). Useful for confirming what a thumbnail looks like without sending it to a client.

Deleting media

Delete a single file

!admin media delete --mxc mxc://example.com/AbCdEfGhIjKl

Removes one media file from the database and from storage. Use get-file-info first to confirm you have the right MXC URI.

Delete media referenced by an event

!admin media delete-by-event --event-id $abc123:example.com

Extracts all MXC URIs from the event (including the primary media URL, thumbnail URL, and encrypted file URL) and deletes each one. Returns the number of files deleted. Useful when a user reports a specific message containing unwanted media.

Delete a list of MXC URIs

Paste a code block of MXC URIs into the admin room, one per line:

!admin media delete-list
```
mxc://example.com/AbCdEfGhIjKl
mxc://example.com/MnOpQrStUvWx
mxc://badserver.tld/YzAbCdEfGhIj
```

Errors on individual URIs are ignored. The command returns the total number deleted and the number that failed to parse.

Delete by time range

!admin media delete-range <duration> --older-than
!admin media delete-range <duration> --newer-than

Deletes remote media whose filesystem modification time falls outside the given duration from now. Exactly one of --older-than or --newer-than must be specified.

Duration format: 30s, 5m, 2h, 7d, etc.

By default only remote media is deleted. To also delete locally-uploaded media, append the confirmation flag:

!admin media delete-range 90d --older-than --yes-i-want-to-delete-local-media

Examples:

# Delete all remote media older than 30 days
!admin media delete-range 30d --older-than

# Delete remote media uploaded in the last hour (e.g. after a spam burst)
!admin media delete-range 1h --newer-than

Delete all media from a local user

!admin media delete-all-from-user <username>

Deletes every media file uploaded by the named local user. The username is the localpart only, without the @ or server name. Errors on individual files are ignored.

Delete all media from a remote server

!admin media delete-all-from-server <server_name>

Deletes every cached copy of remote media originating from the given server. This only affects remotely-fetched media by default. To also remove local uploads that somehow reference the server, add the confirmation flag:

!admin media delete-all-from-server <server_name> \
  --yes-i-want-to-delete-local-media

Responding to a spam incident

The full incident playbook (cached-media delete, federation blocks, invite gating, and the per-room policy-server option) lives in Policy and Moderation > Responding to a spam incident. That chapter is the source of truth; refer to it when an incident is in progress.

Voice and videotelephony systems

There are two ways of setting up voice and video calling for use with Matrix:

• MatrixRTC/Element Call (using a Livekit backend).
• Legacy Calling (using a TURN backend).

Which of these is right for your homeserver largely depends on your preferred client. Different clients support different calling methods, but the majority of maintained clients that support calling are moving towards using MatrixRTC. It is also possible to use legacy calls and the newer MatrixRTC concurrently.

To set up MatrixRTC/Element Call, see the MatrixRTC documentation.

To set up legacy calling, see the TURN documentation. Note: if you are also setting up MatrixRTC, additionally review the External TURN Integration section of the MatrixRTC documentation.

MatrixRTC/Element Call Setup

MatrixRTC is the modern Matrix calling framework used by Element Call and other recent clients. The media itself is carried by a Selective Forwarding Unit (SFU); Tuwunel does not embed an SFU, so an external one is required. Livekit is the SFU implementation supported here, paired with the lk-jwt-service which issues the access tokens clients use to join Livekit rooms.

This guide shows you how to deploy MatrixRTC/Element Call using Docker and Docker Compose, as Livekit only provides prebuilt Docker images. It is possible to run Livekit using their installation script, however this method is not supported or recommended.

Note

In the following documentation, yourdomain.com is whatever you have set as server_name in your tuwunel.toml. This needs to be replaced with the actual domain. It is assumed that you will be hosting MatrixRTC at matrix-rtc.yourdomain.com. If you wish to host this service at a different subdomain, this needs to be replaced as well.

Note

This guide provides example configuration for Caddy, Nginx, and Traefik reverse proxies. Others can be used, but the configuration will need to be adapted.

1. Set Up DNS

Create a DNS record for matrix-rtc.yourdomain.com pointing to your server.

2. Initial Setup

1. Create a directory for your MatrixRTC setup, e.g. mkdir /opt/matrix-rtc.
2. Change into that directory, e.g. cd /opt/matrix-rtc.
3. The following steps will require a key and a secret, referred to as MRTCKEY and MRTCSECRET hereafter. It is suggested that MRTCKEY is 20 characters and MRTCSECRET is 64 characters. If you have pwgen installed, you can generate these with pwgen -s -1 20 for MRTCKEY and pwgen -s -1 64 for MRTCSECRET. Make a note of these values for use in later steps.

2.1 Create Docker Compose Containers

Note: If you are using plain Docker rather than Docker Compose, skip to step 2.2.

1. Create and open a compose.yaml file in your MatrixRTC directory, e.g. nano compose.yaml.
2. Add the following. MRTCKEY and MRTCSECRET should be replaced with the values generated above.

services:
  matrix-rtc-jwt:
    image: ghcr.io/element-hq/lk-jwt-service:latest
    container_name: matrix-rtc-jwt
    environment:
      - LIVEKIT_JWT_BIND=:8081
      - LIVEKIT_URL=wss://matrix-rtc.yourdomain.com
      - LIVEKIT_KEY=MRTCKEY # Random 20 character string
      - LIVEKIT_SECRET=MRTCSECRET # Random 64 character string
      - LIVEKIT_FULL_ACCESS_HOMESERVERS=yourdomain.com # Your server_name from tuwunel.toml
    restart: unless-stopped
    ports:
      - "8081:8081"

  matrix-rtc-livekit:
    image: livekit/livekit-server:latest
    container_name: matrix-rtc-livekit
    command: --config /etc/livekit.yaml
    restart: unless-stopped
    volumes:
      - ./livekit.yaml:/etc/livekit.yaml:ro
    network_mode: "host"
    # Uncomment the lines below and comment `network_mode: "host"` above to specify port mappings.
#    ports:
#      - "7880:7880/tcp"
#      - "7881:7881/tcp"
#      - "50100-50200:50100-50200/udp"

2.2 Create Livekit Configuration

1. Create and open a livekit.yaml file in your MatrixRTC directory, e.g. nano livekit.yaml.
2. Add the following. MRTCKEY and MRTCSECRET should be replaced with the values generated above.

port: 7880
bind_addresses:
  - ""
rtc:
  tcp_port: 7881
  port_range_start: 50100
  port_range_end: 50200
  use_external_ip: true
  enable_loopback_candidate: false
keys:
  MRTCKEY: MRTCSECRET

Note

The enable_loopback_candidate option above causes Livekit to include 127.0.0.1 and ::1 as ICE host candidates. It is intended for deployments where the public IP is mapped to the loopback interface on the host. Set it to true if you have that specific topology. If calls fail only for clients on the same LAN as the server, see the Troubleshooting section.

3. Configure .well-known

3.1. .well-known served by Tuwunel

Follow this step if your .well-known configuration is served by Tuwunel. Otherwise follow Step 3.2.

1. Open your tuwunel.toml file, e.g. nano /etc/tuwunel/tuwunel.toml.
2. Find the line reading #livekit_url = "" and replace it with:

livekit_url = "https://matrix-rtc.yourdomain.com"

3. Ensure that you have [global.well_known] uncommented above this line. .well-known will not be served correctly otherwise.

3.2. .well-known served independently

Follow this step if you serve your .well-known/matrix files directly. Otherwise follow Step 3.1.

1. Open your .well-known/matrix/client file, e.g. nano /var/www/.well-known/matrix/client.
2. Add the following to the end of this file:

  "org.matrix.msc4143.rtc_foci": [
    {
      "type": "livekit",
      "livekit_service_url": "https://matrix-rtc.yourdomain.com"
    }
  ]

The final file should look something like this:

{
  "m.homeserver": {
    "base_url":"https://matrix.yourdomain.com"
  },
  "org.matrix.msc4143.rtc_foci": [
    {
      "type": "livekit",
      "livekit_service_url": "https://matrix-rtc.yourdomain.com"
    }
  ]
}

4. Configure Firewall

You will need to allow ports 7881/tcp and 50100:50200/udp through your firewall. If you use UFW: ufw allow 7881/tcp and ufw allow 50100:50200/udp.

If you are behind NAT, you will also need to forward 7880/tcp, 7881/tcp, and 50100:50200/udp to livekit.

5. Configure Reverse Proxy

As reverse proxies can be installed in different ways, step-by-step instructions are not given for this section. If you use Caddy, follow step 5.1; Nginx, follow step 5.2; Traefik, follow step 5.3.

5.1. Caddy

1. Add the following to your Caddyfile. If you are running Caddy in Docker, replace localhost with matrix-rtc-jwt in the first instance, and matrix-rtc-livekit in the second.

matrix-rtc.yourdomain.com {
    # This is matrix-rtc-jwt
    @jwt_service {
        path /sfu/get* /healthz* /get_token*
    }
    handle @jwt_service {
        reverse_proxy localhost:8081
    }
    # This is livekit
    handle {
        reverse_proxy localhost:7880 {
            header_up Connection "upgrade"
            header_up Upgrade {http.request.header.Upgrade}
        }
    }
}

2. Restart Caddy.

5.2. Nginx

1. Add the following to your Nginx configuration. If you are running Nginx in Docker, replace localhost with matrix-rtc-jwt in the first instance, and matrix-rtc-livekit in the second.

server {
    listen 443 ssl;
    listen [::]:443 ssl;
    http2 on;
    server_name matrix-rtc.yourdomain.com;

    # Logging
    access_log /var/log/nginx/matrix-rtc.yourdomain.com.log;
    error_log /var/log/nginx/matrix-rtc.yourdomain.com.error;

    # TLS example for certificate obtained from Let's Encrypt.
    ssl_certificate /etc/letsencrypt/live/matrix-rtc.yourdomain.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/matrix-rtc.yourdomain.com/privkey.pem;

    # lk-jwt-service
    location ~ ^/(sfu/get|healthz|get_token) {
        proxy_pass http://localhost:8081;

        proxy_set_header Host $host;
        proxy_set_header X-Forwarded-Server $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
    # livekit
    location / {
       proxy_pass http://localhost:7880;
       proxy_http_version 1.1;

       proxy_set_header Connection "upgrade";
       proxy_set_header Upgrade $http_upgrade;

       proxy_set_header Host $host;
       proxy_set_header X-Forwarded-Server $host;
       proxy_set_header X-Real-IP $remote_addr;
       proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
       proxy_set_header X-Forwarded-Proto $scheme;

        # Optional timeouts per LiveKit
        proxy_read_timeout 300s;
        proxy_send_timeout 300s;
    }
}

2. Restart Nginx.

5.3. Traefik

1. Add matrix-rtc-jwt and matrix-rtc-livekit to your Traefik network:

services:
  matrix-rtc-jwt:
    # ...
    networks:
        - proxy # your traefik network name

  matrix-rtc-livekit:
    # ...
    networks:
        - proxy # your traefik network name

networks:
    proxy: # your traefik network name
        external: true

2. Configure routing with either of the methods below.

2.1 Labels

services:
  matrix-rtc-jwt:
    # ...
    labels:
        - "traefik.enable=true"
        - "traefik.http.routers.matrixrtcjwt.entrypoints=websecure"
        - "traefik.http.routers.matrixrtcjwt.rule=Host(`matrix-rtc.yourdomain.com`) && (PathPrefix(`/sfu/get`) || PathPrefix(`/healthz`) || PathPrefix(`/get_token`))"
        - "traefik.http.routers.matrixrtcjwt.tls=true"
        - "traefik.http.routers.matrixrtcjwt.service=matrixrtcjwt"
        - "traefik.http.services.matrixrtcjwt.loadbalancer.server.port=8081"
        - "traefik.http.routers.matrixrtcjwt.tls.certresolver=yourcertresolver" # change to your cert resolver's name
        - "traefik.docker.network=proxy" # your traefik network name

  matrix-rtc-livekit:
    # ...
    labels:
        - "traefik.enable=true"
        - "traefik.http.routers.livekit.entrypoints=websecure"
        - "traefik.http.routers.livekit.rule=Host(`matrix-rtc.yourdomain.com`)"
        - "traefik.http.routers.livekit.tls=true"
        - "traefik.http.routers.livekit.service=livekit"
        - "traefik.http.services.livekit.loadbalancer.server.port=7880"
        - "traefik.http.routers.livekit.tls.certresolver=yourcertresolver" # change to your cert resolver's name
        - "traefik.docker.network=proxy" # your traefik network name

2.2 Config file

http:
    routers:
        matrixrtcjwt:
            entryPoints:
                - "websecure"
            rule: "Host(`matrix-rtc.yourdomain.com`) && (PathPrefix(`/sfu/get`) || PathPrefix(`/healthz`) || PathPrefix(`/get_token`))"
            tls:
                certResolver: "yourcertresolver" # change to your cert resolver's name
            service: matrixrtcjwt
        livekit:
            entryPoints:
                - "websecure"
            rule: "Host(`matrix-rtc.yourdomain.com`)"
            tls:
                certResolver: "yourcertresolver" # change to your cert resolver's name
            service: livekit
    services:
        matrixrtcjwt:
            loadBalancer:
                servers:
                    - url: "http://matrix-rtc-jwt:8081"
                passHostHeader: true
        livekit:
            loadBalancer:
                servers:
                    - url: "http://matrix-rtc-livekit:7880"
                passHostHeader: true

6. Start Docker Containers

Note: If you are using Docker Compose, follow 6.1. If you are using plain Docker, follow 6.2.

6.1 Using Docker Compose

1. Ensure you are in your matrix-rtc directory, e.g. cd /opt/matrix-rtc.
2. Start containers: docker compose up -d.

6.2 Using Docker Run

1. Start matrix-rtc-jwt. MRTCKEY and MRTCSECRET should be replaced with the values generated in Step 2. matrix-rtc.yourdomain.com should be replaced with your MatrixRTC subdomain. yourdomain.com should be replaced with what you have set as server_name in tuwunel.toml.

docker run -d \
  --restart unless-stopped \
  --name matrix-rtc-jwt \
  -p 8081:8081 \
  -e LIVEKIT_JWT_BIND=":8081" \
  -e LIVEKIT_URL="wss://matrix-rtc.yourdomain.com" \
  -e LIVEKIT_KEY="MRTCKEY" \
  -e LIVEKIT_SECRET="MRTCSECRET" \
  -e LIVEKIT_FULL_ACCESS_HOMESERVERS="yourdomain.com" \
  ghcr.io/element-hq/lk-jwt-service:latest

2. Start matrix-rtc-livekit:

docker run -d \
  --restart unless-stopped \
  --name matrix-rtc-livekit \
  --network host \
  -v /opt/matrix-rtc/livekit.yaml:/etc/livekit.yaml:ro \
  livekit/livekit-server:latest \
  --config /etc/livekit.yaml

Element Call should now be working.

Additional Configuration

External TURN Integration

If you follow this guide and also set up Coturn as per the TURN documentation, there will be a port clash between the two services. To avoid this, the following must be added to your coturn.conf:

min-port=50201
max-port=65535

If you have Coturn configured, you can use it as a TURN server for Livekit to improve call reliability. As Coturn allows multiple instances of static-auth-secret, it is suggested that the secret used for Livekit is different to that used for Tuwunel.

1. Create a secret for Coturn — a random 64-character alphanumeric string is suggested.
2. Add the following line to the end of your coturn.conf, where AUTH_SECRET is the secret created in Step 1:

static-auth-secret=AUTH_SECRET

3. Add the following to the end of the rtc block in your livekit.yaml. AUTH_SECRET is the same as above. turn.yourdomain.com should be replaced with your actual TURN domain.

  turn_servers:
    - host: turn.yourdomain.com
      port: 5349
      protocol: tls
      secret: "AUTH_SECRET"

Using the Livekit Built-In TURN Server

Livekit includes a built-in TURN server which can be used in place of an external option. This TURN server will only work with Livekit and is not compatible with traditional Matrix calling. For that, see the TURN documentation.

Basic Setup

The simplest way to enable this is to add the following to your livekit.yaml:

turn:
  enabled: true
  udp_port: 3478
  relay_range_start: 50300
  relay_range_end: 65535
  domain: matrix-rtc.yourdomain.com

It is strongly recommended that you use network_mode: "host"; however if port mappings are necessary, add the following ports to matrix-rtc-livekit in your compose.yaml:

ports:
      - 3478:3478/udp
      - 50300-65535:50300-65535/udp

You will need to allow ports 3478 and 50300:65535/udp through your firewall. If you use UFW: ufw allow 3478 and ufw allow 50300:65535/udp.

Setup With TLS

To enable TLS for the TURN server, the process is slightly more complicated. Some WebRTC software will not accept certificates provided by Let’s Encrypt; it is therefore suggested that you use ZeroSSL as an alternative.

1. Create a DNS record for e.g. matrix-turn.yourdomain.com pointing to your server.
2. Get a certificate for this subdomain.
3. Add the certificates as volumes for matrix-rtc-livekit in your compose.yaml. For example:

volumes:
      - ./certs/privkey.pem:/certs/privkey.pem:ro
      - ./certs/fullchain.pem:/certs/fullchain.pem:ro

4. Add the following to the bottom of your livekit.yaml. The values for cert_file and key_file should match where these files are mounted in the container.

turn:
  enabled: true
  udp_port: 3478
  tls_port: 5349
  relay_range_start: 50300
  relay_range_end: 65535
  external_tls: false
  domain: matrix-turn.yourdomain.com
  cert_file: /certs/fullchain.pem
  key_file: /certs/privkey.pem

5. It is strongly recommended that you use network_mode: "host"; however if port mappings are necessary, add the following ports to matrix-rtc-livekit in your compose.yaml:

ports:
      - 3478:3478/udp
      - 5349:5349/tcp
      - 50300-65535:50300-65535/udp

6. You will need to allow ports 3478, 5349, and 50300:65535/udp through your firewall. If you use UFW: ufw allow 3478, ufw allow 5349, and ufw allow 50300:65535/udp.
7. Restart the containers.

Troubleshooting

The easiest way to test your configuration is using the testmatrix utility provided by spaetz. This can be installed using pip install testmatrix if you have Python and pip installed.

To use this utility to test your call setup, you will need an access token for your account. This can be most easily found at the bottom of the “Help & About” section of the Element Web settings, or in the “Developer Tools” section of the Cinny settings.

Once you have testmatrix installed, run the following (YOUR_TOKEN must be replaced with the access token from your client described above):

testmatrix -u @your-user:yourdomain.com -t YOUR_TOKEN yourdomain.com

The output of this command will give you information on whether calls are properly set up.

If all tests are successful, you will get credentials that can be used with the Livekit Connection Tester. This can be used to test the ability of your Livekit service to route calls.

If any of these tests fail, further information can be found in the container logs. Run docker compose logs --follow in the directory where your compose.yaml is located.

Calls connect for some clients but not others

A common failure mode is that calls work for clients outside your local network but fail for clients on the same LAN as the Livekit server, and the failure is browser-dependent (Firefox often breaks while Chromium succeeds, or vice versa).

This is usually a NAT routing issue rather than a Livekit configuration issue. Livekit advertises the server’s public IP as an ICE candidate via STUN. Clients on the same LAN that try to reach that public IP must traverse the router back into the LAN, a feature called “NAT loopback” or “hairpin NAT”. Some routers do not support it, and in that case local clients cannot establish a media path to any candidate that names the public IP. Browsers differ in how aggressively they retry alternative candidates and in how they handle host candidates under mDNS obfuscation, so the same network can break one browser while another works.

The reliable fix is to make local clients resolve the MatrixRTC subdomain to the LAN address, so they bypass the router for that traffic. Most routers expose this as a “local DNS override”, “DNS rewrite”, or “host override” setting. Alternatively, run a small local DNS resolver (dnsmasq, AdGuard Home, Pi-hole) on the network and point LAN clients at it. External clients continue to resolve the subdomain to the public IP via public DNS.

Setting up TURN/STUN

In order to make or receive legacy calls in Matrix, a TURN server is required. Tuwunel suggests using Coturn for this purpose, which is also available as a Docker image.

Note

If you are setting up MatrixRTC and only need a TURN server to improve Livekit call reliability (not legacy calling), Livekit ships its own built-in TURN server. See Using the Livekit Built-In TURN Server in the MatrixRTC documentation. The instructions on this page are for a standalone Coturn deployment used by legacy Matrix calls; if you run both, review External TURN Integration for the port allocation considerations.

Configuration

Create a configuration file called coturn.conf containing:

use-auth-secret
static-auth-secret=<a secret key>
realm=<your server domain>

A common way to generate a suitable alphanumeric secret key is by using pwgen -s 64 1.

These same values need to be set in Tuwunel. See the example config in the TURN section for configuring these and restart Tuwunel after.

turn_secret or a path to turn_secret_file must have a value of your coturn static-auth-secret, or use turn_username and turn_password if using legacy username:password TURN authentication (not preferred).

turn_uris must be the list of TURN URIs you would like to send to the client. Typically you will just replace the example domain example.turn.uri with the realm you set from the example config.

If you are using TURN over TLS, you can replace turn: with turns: in the turn_uris config option to instruct clients to attempt to connect to TURN over TLS. This is highly recommended.

If you need unauthenticated access to the TURN URIs, or some clients may be having trouble, you can enable turn_guest_access in Tuwunel which disables authentication for the TURN URI endpoint /_matrix/client/v3/voip/turnServer.

Run

Run the Coturn image using

docker run -d --network=host \
  -v $(pwd)/coturn.conf:/etc/coturn/turnserver.conf \
  coturn/coturn

or docker-compose. For the latter, paste the following section into a file called docker-compose.yml and run docker compose up -d in the same directory.

services:
    turn:
      container_name: coturn-server
      image: docker.io/coturn/coturn
      restart: unless-stopped
      network_mode: "host"
      volumes:
        - ./coturn.conf:/etc/coturn/turnserver.conf

To understand why the host networking mode is used and explore alternative configuration options, please visit Coturn’s Docker documentation.

For security recommendations see Synapse’s Coturn documentation.

The TURN server requires the appropriate ports to be forwarded where your installation is behind NAT. These are currently 3478/tcp, 3478/udp, 5349/tcp, and 5349/udp.

Application Services

Application services are out-of-process programs that extend the homeserver; most bridges (IRC, XMPP, Discord, Telegram, Slack) are implemented this way. They authenticate with a pair of shared secret tokens and declare namespaces of users and room aliases that they manage.

The upstream reference is the Matrix Application Service API specification.

Registration

Tuwunel supports three registration methods. They coexist and are all loaded on startup.

Admin room

The most convenient method for live deployments. Send !admin appservices register to the admin room with the registration YAML in a code block below:

!admin appservices register
\`\`\`
id: my-bridge
url: http://localhost:29328
as_token: secret-token-a
hs_token: secret-token-b
sender_localpart: my-bridge-bot
namespaces:
  users:
    - exclusive: true
      regex: '@my-bridge_.*:example\.com'
\`\`\`

The registration is persisted in the database and survives restarts. Registering with an existing ID replaces the old entry. No restart is required.

Server configuration

Application services can be declared inline in tuwunel.toml. The TOML section key becomes the registration ID unless id is explicitly set:

[global.appservice.my-bridge]
url = "http://localhost:29328"
as_token = "secret-token-a"
hs_token = "secret-token-b"
sender_localpart = "my-bridge-bot"

[[global.appservice.my-bridge.users]]
exclusive = true
regex = '@my-bridge_.*:example\.com'

Config-file registrations are reloaded on each restart. They cannot be removed with !admin appservices unregister.

Registration file directory

Point appservice_dir at a directory containing YAML registration files. Every readable file is loaded at startup:

[global]
appservice_dir = "/etc/tuwunel/appservices"

Files use the same YAML format that bridges produce for Synapse. New or removed files are not picked up without a restart.

Namespaces

Each registration declares which users, room aliases, and room IDs the appservice claims. Entries under users, aliases, and rooms are lists; each entry has a regex and an optional exclusive flag.

Regex matching is unanchored – add ^ and $ if you need to match the full string.

When exclusive: true, the homeserver rejects any attempt by a normal user to register a conflicting user ID or room alias. Multiple appservices can share a non-exclusive namespace; exclusive ranges must not overlap.

Configuration reference

Fields under [global.appservice.<ID>]:

Namespace entries under [[global.appservice.<ID>.users]], aliases, and rooms:

Admin commands

All commands run from the admin room (!admin appservices <subcommand>):

Connection settings

These options go in the top-level [global] section:

Getting help

For setup questions, join #tuwunel:matrix.org or open an issue.

Policy and Moderation

This chapter covers the federation-level, room-level, and user-level controls Tuwunel exposes to operators for keeping their server, its users, and the rooms they participate in within a desired policy posture. Most controls fall into one of three layers: configuration (statically applied at startup or reload), admin-room commands (live operator actions), and per-room policy delegation (MSC4284).

Configuration values shown here are documented in the example configuration with their defaults and full per-knob explanation. This page summarises each knob’s role in the moderation toolkit rather than restating the example file.

Federation server blocklists

The largest hammer. Three knobs in tuwunel-example.toml:

• forbidden_remote_server_names: regex patterns matched against room IDs, room aliases, sender server names, sender users’ server names, inbound X-Matrix origins, and outbound federation handlers. Effectively a global ACL. Matching servers can neither send to nor receive from this homeserver, and local clients cannot join their rooms.
• allowed_remote_server_names_experimental: an allow-list counterpart. When non-empty, anything not matching is denied. forbidden_remote_server_names is still applied after, so a wide allow (.*\\.example\\.com) plus a narrow deny (bad\\.example\\.com) is a valid composition.
• forbidden_remote_room_directory_server_names: limits the broader knob to outbound room-directory queries, useful when the goal is to keep users from discovering rooms on a server without cutting all federation with it.

These checks are inexpensive and apply on every relevant code path. Use a regex denylist when a server has crossed a hard line; use the directory-only variant for cases that warrant friction without isolation.

Admin commands for moderation

The admin room (joined automatically on first registration unless create_admin_room = false) accepts the following moderation-relevant commands. Run any command with --help for argument detail.

Rooms

• !admin rooms moderation ban-room <room>: bans a room, evicts every local user including admins, removes local aliases, unpublishes from the directory, and disables federation with the room.
• !admin rooms moderation ban-list-of-rooms: bulk variant; takes a code block of room IDs or aliases.
• !admin rooms moderation unban-room <room>: reverses a ban and re-enables federation.
• !admin rooms moderation list-banned-rooms: lists every banned room.
• !admin rooms delete <room>: harder than ban; removes the room from the database after evicting users.

Federation

• !admin federation disable-room <room>: blocks new inbound PDUs for one room without banning it. Useful for stalling a runaway room while investigating.
• !admin federation enable-room <room>: re-enables inbound handling.
• !admin federation incoming-federation: lists rooms with active inbound PDU handlers.
• !admin federation fetch-support-well-known <server>: fetches a remote server’s .well-known/matrix/support record (administrator and security contacts), letting you raise abuse reports out-of-band before resorting to blocks.

Users

• !admin users deactivate <user>: deactivates a local account; by default also leaves all rooms.
• !admin users deactivate-all: bulk variant accepting a code block of usernames.
• !admin users reject-invites <user>: rejects all pending invites, with an optional reason. Useful when an account has been targeted by an invite flood.
• !admin users redact-event <event_id>: forcibly redacts an event from a local sender even when the user is offline or unwilling.
• !admin users force-demote <user> <room>: drops a user’s power level to the room default when permissions allow.
• !admin users delete-room-tag / put-room-tag: room-tag housekeeping; the m.server_notice tag pinned to the admin room is the typical use.

Media

See Multimedia and Storage > Management for the full admin command reference. Tools relevant to moderation:

• !admin media delete --mxc <mxc_uri>: single-file removal.
• !admin media delete-by-event --event-id <event_id>: removes every MXC URI referenced by an event.
• !admin media delete-list: bulk removal from a code block of MXC URIs.
• !admin media delete-range <duration> --older-than|--newer-than: time-range delete; remote-only by default, local with the --yes-i-want-to-delete-local-media confirmation.
• !admin media delete-all-from-user <username>: removes every upload by a local user.
• !admin media delete-all-from-server <server>: drops every cached copy of remote media from the named server.

Media policy

• prevent_media_downloads_from: regex denylist for remote media downloads. Narrower than forbidden_remote_server_names; the server can still federate, just no media flows in.
• media_storage_provider (under [media.storage]): when files live in an external provider, deletion semantics still apply through the same admin commands.

Identifier blocklists

Applied at registration, alias creation, and at startup as warnings against existing entries.

• forbidden_alias_names: regex patterns matched against newly created room aliases and custom room IDs. Existing aliases that match are warned about on startup but not removed.
• forbidden_usernames: same shape, applied to local username availability checks and registration.

Invite gating

• block_non_admin_invites: when true, only server admins can send room invites (local or remote) and only admins can receive remote invites. The cheapest mitigation for an invite-spam wave on a small or invite-only server.

Auto-deactivation triggers

• auto_deactivate_banned_room_attempts: when true, any local user who attempts to join a banned room, an alias matching forbidden_alias_names, or an alias / room ID containing a forbidden_remote_server_names match, is fully deactivated and made to leave every room. Off by default because rooms are sometimes banned for non-moderation reasons.

Per-room policy delegation (MSC4284)

MSC4284 lets a room’s moderators delegate event signing to a third-party policy server whose ed25519 signature must be present on every non-policy event in the room. The signature folds into event.signatures and federates transitively. Tuwunel implements outbound /sign on local sends, inbound verification on federated receives, fetch-on-missing for inbound events without a signature, and refusal/backoff caching to avoid hammering a server that is rate-limiting or has refused.

Two configuration knobs:

• enable_policy_servers: master switch (default false). When false, Tuwunel ignores policy state entirely. When true, the gate engages only in rooms that carry a valid m.room.policy state event.
• policy_server_request_timeout: seconds (default 5) for both outbound /sign and inbound signature-fetch requests.

Operator-relevant implications when enabling:

• Per-room opt-in. The global flag only allows the gate to engage; the room’s own m.room.policy state event is what activates it. Rooms without the state event are unaffected.
• Latency cost. Every outbound send in a policy-room round-trips to the policy server before federating. The default 5-second cap prevents a single misbehaving policy server from stalling sends indefinitely.
• Fail-open on transport failure. Network errors and timeouts are logged and the event is sent or accepted unsigned, on the assumption that the next homeserver in the room will pick up the gap.
• Fail-closed on explicit refusal. A policy server returning M_FORBIDDEN (or, on the unstable variant, 200 OK with no signature for the configured via) causes outbound sends to fail with M_FORBIDDEN, and inbound events to soft-fail.
• Privacy in encrypted rooms. The PDU is forwarded to the policy server for signing. Ciphertext is opaque, but metadata (sender, timestamp, room, event type) is not. Encrypted-room policy delegation is the room’s call; Tuwunel does not block it.
• Refusal and rate-limit caching. Per-event refusals and per-policy-server M_LIMIT_EXCEEDED backoffs are persisted, so repeated arrivals of the same event do not re-hit a refusing or throttled server.

For room version compatibility, MSC4416 (the room-version-13 successor that makes a missing or invalid policy signature an auth-rule rejection rather than a soft fail) is not yet active in Tuwunel and depends on upstream typing work. Until v13 ships, “leave it off” is safe; once v13 rooms become common, leaving it off in such a room means accepting events that the rest of the federation will reject.

URL previews and outbound network policy

URL preview generation is a frequent attack surface (SSRF, exfiltration via forced fetches). Tuwunel exposes both a domain policy layer and an IP egress layer.

Domain policy:

• url_preview_domain_contains_allowlist, url_preview_url_contains_allowlist: permissive contains-match allowlists. The contains-match is intentionally loose; treat as “anything mentioning this string passes”.
• url_preview_domain_explicit_allowlist: strict equality match on the host.
• url_preview_domain_explicit_denylist: strict equality match, evaluated before the allowlist.
• url_preview_check_root_domain: when true, applies the contains and explicit allowlists against the root domain, so an allow on wikipedia.org also lets en.m.wikipedia.org through.
• url_preview_max_spider_size (bytes; SI/IEC suffix accepted): caps the spider response body.
• url_preview_bound_interface: pins outbound preview requests to a specific interface or source IP. Linux/Android/Fuchsia accept interface names (eth0); other platforms accept addresses.

IP egress:

• ip_range_denylist: list of IPv4/IPv6 CIDR ranges Tuwunel will not send outbound requests to. Defaults to RFC1918, loopback, multicast, link-local, and the documentation/testnet ranges. This is application-layer enforcement and not a substitute for a host firewall, but it closes the obvious SSRF vectors out of the box. Set to [] only if a firewall is enforcing the same constraints upstream.

Redaction retention and forensics

Moderation actions often hinge on what an event said before redaction.

• save_unredacted_events (default true): keeps the pre-redaction PDU in storage so admins can recover content for incident review.
• redaction_retention_seconds (default 60 days): how long unredacted copies live before being dropped. Lower this for tighter privacy posture; raise it when investigations span longer horizons.
• allow_room_admins_to_request_unredacted_events (default true): lets a user with redact power level retrieve unredacted copies via MSC2815. Server admins can request regardless.
• disable_local_redactions: blocks local users from sending redactions (server admins exempt). Useful only in archival or read-only deployments; most operators leave this off.

The !admin debug get-retained-pdu command surfaces a retained event from the admin room.

Responding to a spam incident

When a server sends spam media to your users, the typical response is:

1. Identify the source server. Check the MXC URIs in the reported messages. The server name is the authority component: mxc://<server_name>/<media_id>. The sender server on the offending event is the canonical source even when media is hosted elsewhere.

2. Delete cached copies of the spam media.

!admin media delete-all-from-server badserver.tld

3. Block future media downloads from that server. Add the server to prevent_media_downloads_from in your config and reload or restart Tuwunel:

prevent_media_downloads_from = ["badserver\\.tld$"]

4. If the spam arrived within a known time window, use delete-range to catch anything missed:

!admin media delete-range 2h --newer-than

5. If you have a list of specific MXC URIs (e.g. from a moderation tool or a shared blocklist), use delete-list to remove them in bulk.

6. Consider server-level federation blocks via forbidden_remote_server_names if the server is persistently abusive. This blocks all federation traffic, not just media, and so is the right tool only once the source has demonstrated it will not stop.

7. If the spam came as invite floods, set block_non_admin_invites = true to halt all non-admin invite traffic during the incident, then run !admin users reject-invites <user> for affected accounts. Re-enable invites once the source server is blocked.

8. If a single room is the vector (for example, a public room being used to flood a user’s timeline), !admin rooms moderation ban-room <room> evicts your local users and severs federation with the room without affecting other rooms on the same server.

9. For ongoing moderation against a class of senders, consider whether a per-room MSC4284 policy server is appropriate. This delegates per-event signing to a moderation service, with the trade-offs described in Per-room policy delegation above. This is a heavier setup than a one-time response and is worth it only when the room expects sustained policy enforcement.

Maintaining your Tuwunel setup

Moderation

Tuwunel has moderation through admin room commands. “binary commands” (medium priority) and an admin API (low priority) is planned. Some moderation-related config options are available in the example config such as “global ACLs” and blocking media requests to certain servers. See the example config for the moderation config options under the “Moderation / Privacy / Security” section.

Tuwunel has moderation admin commands for:

• managing room aliases (!admin rooms alias)
• managing room directory (!admin rooms directory)
• managing room banning/blocking and user removal (!admin rooms moderation)
• managing user accounts (!admin users)
• fetching /.well-known/matrix/support from servers (!admin federation)
• blocking incoming federation for certain rooms (not the same as room banning) (!admin federation)
• deleting media (see the media section)

Any commands with -list in them will require a codeblock in the message with each object being newline delimited. An example of doing this is:

!admin rooms moderation ban-list-of-rooms
```
!roomid1:server.name
#badroomalias1:server.name
!roomid2:server.name
!roomid3:server.name
#badroomalias2:server.name
```

Database (RocksDB)

Generally there is very little you need to do. Compaction is ran automatically based on various defined thresholds tuned for Tuwunel to be high performance with the least I/O amplifcation or overhead. Manually running compaction is not recommended, or compaction via a timer, due to creating unnecessary I/O amplification. RocksDB is built with io_uring support via liburing for improved read performance.

RocksDB troubleshooting can be found in the RocksDB section of troubleshooting.

Compression

Some RocksDB settings can be adjusted such as the compression method chosen. See the RocksDB section in the example config.

btrfs users have reported that database compression does not need to be disabled on Tuwunel as the filesystem already does not attempt to compress. This can be validated by using filefrag -v on a .SST file in your database, and ensure the physical_offset matches (no filesystem compression). It is very important to ensure no additional filesystem compression takes place as this can render unbuffered Direct IO inoperable, significantly slowing down read and write performance. See https://btrfs.readthedocs.io/en/latest/Compression.html#compatibility

Important

Compression is done using the COW mechanism so it’s incompatible with nodatacow. Direct IO read works on compressed files but will fall back to buffered writes and leads to no compression even if force compression is set. Currently nodatasum and compression don’t work together.

ZFS

ZFS has several quirks that interact badly with RocksDB defaults. Apply both the Tuwunel config changes and the dataset properties below.

In tuwunel.toml:

• rocksdb_direct_io = false. OpenZFS prior to 2.3 silently ignored O_DIRECT and fell back to buffered. OpenZFS 2.3+ honors O_DIRECT only when requests are page-aligned and a multiple of the recordsize, which RocksDB cannot guarantee.
• rocksdb_allow_fallocate = false. OpenZFS does not implement fallocate(2) preallocation; only FALLOC_FL_PUNCH_HOLE and FALLOC_FL_ZERO_RANGE are supported.
• Leave rocksdb_optimize_for_spinning_disks = false on NVMe or SSD pools, even when running on ZFS.

On the dataset hosting database_path:

recordsize takes effect only on files written after the property is changed. After adjusting it, dump the database (offline copy out, wipe the dataset, copy back) so existing SSTs adopt the new recordsize. Without a dump-and-reload, compaction will gradually rewrite into the new recordsize over weeks; pre-existing files keep the old size in the meantime.

For sync write latency, in order of preference: a separate SLOG vdev, then logbias=throughput, then sync=disabled (only if you accept that a host crash may discard the WAL tail; Tuwunel recovers cleanly from this via rocksdb_recovery_mode=1, the default).

Files in database

Do not touch any of the files in the database directory. This must be said due to users being mislead by the .log files in the RocksDB directory, thinking they’re server logs or database logs, however they are critical RocksDB files related to WAL tracking.

The only safe files that can be deleted are the LOG files (all caps). These are the real RocksDB telemetry/log files, however Tuwunel has already configured to only store up to 3 RocksDB LOG files due to generally being useless for average users unless troubleshooting something low-level. If you would like to store nearly none at all, see the rocksdb_max_log_files config option.

Online backups

Currently only RocksDB supports online backups. If you’d like to backup your database online without any downtime, see the !admin server command for the backup commands and the database_backup_path config options in the example config.

Please note that the format of the database backup is not the exact same. This is unfortunately a bad design choice by Facebook as we are using the database backup engine API from RocksDB, however the data is still there and can still be joined together.

Restoring online backup

To restore a backup from an online RocksDB backup:

• shutdown Tuwunel
• create a new directory for merging together the data
• in the online backup created, copy all .sst files in $DATABASE_BACKUP_PATH/shared_checksum to your new directory
• trim all the strings so instead of ######_sxxxxxxxxx.sst, it reads ######.sst. A way of doing this with sed and bash is for file in *.sst; do mv "$file" "$(echo "$file" | sed 's/_s.*/.sst/')"; done
• copy all the files in $DATABASE_BACKUP_PATH/1 (or the latest backup number if you have multiple) to your new directory
• set your database_path config option to your new directory, or replace your old one with the new one you crafted
• start up Tuwunel again and it should open as normal

Offline backups

If you’d like to do an offline backup, shutdown Tuwunel and copy your database_path directory elsewhere. This can be restored with no modifications needed.

Backing up media is also just copying the media/ directory from your database directory.

Media

Media still needs various work, however Tuwunel implements media deletion via:

• MXC URI or Event ID (unencrypted and attempts to find the MXC URI in the event)
• Delete list of MXC URIs
• Delete remote media in the past N seconds/minutes via filesystem metadata on the file created time (btime) or file modified time (mtime)

See the !admin media command for further information. All media in Tuwunel is stored at $DATABASE_DIR/media. This will be configurable soon.

If you are finding yourself needing extensive granular control over media, we recommend looking into Matrix Media Repo. Tuwunel intends to implement various utilities for media, but MMR is dedicated to extensive media management.

Built-in S3 support is also planned, but for now using a “S3 filesystem” on media/ works. Tuwunel also sends a Cache-Control header of 1 year and immutable for all media requests (download and thumbnail) to reduce unnecessary media requests from browsers, reduce bandwidth usage, and reduce load.

Troubleshooting Tuwunel

Important

If you intend on asking for support and you are using Docker, PLEASE triple validate your issues are NOT because you have a misconfiguration in your Docker setup. We must remain focused on supporting Tuwunel issues and cannot budget our time for generic Docker support. Compose file issues or Dockerhub image issues are okay if they are something we can fix.

Tuwunel and Matrix issues

Lost access to admin room

You can reinvite yourself to the admin room through the following methods:

• Use the --execute "users make_user_admin <username>" Tuwunel binary argument once to invite yourself to the admin room on startup
• Use the Tuwunel console/CLI to run the users make_user_admin command
• Or specify the emergency_password config option to allow you to temporarily log into the server account (@conduit) from a web client

General potential issues

Potential DNS issues when using Docker

Docker has issues with its default DNS setup that may cause DNS to not be properly functional when running Tuwunel, resulting in federation issues. The symptoms of this have shown in excessively long room joins (30+ minutes) from very long DNS timeouts, log entries of “mismatching responding nameservers”, and/or partial or non-functional inbound/outbound federation.

This is not a Tuwunel issue, and is purely a Docker issue. It is not sustainable for heavy DNS activity which is normal for Matrix federation. The workarounds for this are:

• Use DNS over TCP via the config option query_over_tcp_only = true
• Don’t use Docker’s default DNS setup and instead allow the container to use and communicate with your host’s DNS servers (host’s /etc/resolv.conf)

DNS No connections available error message

If you receive spurious amounts of error logs saying “DNS No connections available”, this is due to your DNS server (servers from /etc/resolv.conf) being overloaded and unable to handle typical Matrix federation volume. Some users have reported that the upstream servers are rate-limiting them as well when they get this error (e.g. popular upstreams like Google DNS).

Matrix federation is extremely heavy and sends wild amounts of DNS requests. Unfortunately this is by design and has only gotten worse with more server/destination resolution steps. Synapse also expects a very perfect DNS setup.

There are some ways you can reduce the amount of DNS queries, but ultimately the best solution/fix is selfhosting a high quality caching DNS server like Unbound without any upstream resolvers, and without DNSSEC validation enabled.

DNSSEC validation is highly recommended to be disabled due to DNSSEC being very computationally expensive, and is extremely susceptible to denial of service, especially on Matrix. Many servers also strangely have broken DNSSEC setups and will result in non-functional federation.

Tuwunel cannot provide a “works-for-everyone” Unbound DNS setup guide, but the official Unbound tuning guide and the Unbound Arch Linux wiki page may be of interest. Disabling DNSSEC on Unbound is commenting out trust-anchors config options and removing the validator module.

Avoid using systemd-resolved as it does not perform very well under high load, and we have identified its DNS caching to not be very effective.

dnsmasq can possibly work, but it does not support TCP fallback which can be problematic when receiving large DNS responses such as from large SRV records. If you still want to use dnsmasq, make sure you disable dns_tcp_fallback in Tuwunel config.

Raising dns_cache_entries in Tuwunel config from the default can also assist in DNS caching, but a full-fledged external caching resolver is better and more reliable.

If you don’t have IPv6 connectivity, changing ip_lookup_strategy to match your setup can help reduce unnecessary AAAA queries (1 - Ipv4Only (Only query for A records, no AAAA/IPv6)).

If your DNS server supports it, some users have reported enabling query_over_tcp_only to force only TCP querying by default has improved DNS reliability at a slight performance cost due to TCP overhead.

RocksDB / database issues

Database corruption

There are many causes and varieties of database corruption. There are several methods for mitigation, each with outcomes ranging from a recovered state down to a savage state. This guide has been simplified into a set of universal steps which everyone can follow from the top until they have recovered or reach the end. The details and implications will be explained within each step.

Tip

All command-line -O options can be expressed as environment variables or in the config file based on your deployment’s requirements. Note that --maintenance is equivalent to configuring startup_netburst = false and listening = false.

Important

Always create a backup of the database before running any operation. This is critical for steps 3 and above.

0. Start the server with the following options:

tuwunel --maintenance -O rocksdb_recovery_mode=0

This is actually a “control” and not a method of recovery. If the server starts you either do not have corruption or have deep corruption indicated by very specific errors from rocksdb citing corruption during runtime. If you are certain there is deep corruption skip to step 4, otherwise you are finished without any modifications.

1. Start the server in Tolerate-Corrupted-Tail-Records mode:

tuwunel --maintenance -O rocksdb_recovery_mode=1

The most common corruption scenario is from a loss of power to the hardware (not an application crash, though it is still possible). This is remediated by dropping the most recently written record. It is highly unlikely there will be any impact on the application from this loss. In the best-case the same data is often re-requested over the federation or replaced by a client. In the worst-case clients may need to clear-cache & reload to guarantee correctness. If the server starts you are finished.

2. Start the server in Point-In-Time mode:

tuwunel --maintenance -O rocksdb_recovery_mode=2

Similar to the corruption scenario above but for more severe cases. The most recent records are discarded back to the point where there is no corruption. It is highly unlikely there will be any impact on the application from this loss, but it is more likely than above that clients may need to clear-cache & reload to correctly resynchronize with the server.

3. Start the server in Skip-Any-Corrupted-Record mode:

Warning

Salvage mode potentially impacting the application’s ability to function. We cannot provide support for users who have entered this mode.

tuwunel --maintenance -O rocksdb_recovery_mode=3

Similar to the prior corruption scenarios but for the most severe cases. The database will be inconsistent. It is theoretically possible for the server to continue functioning without notable issue in the best case, but it is completely uncertain what the effect of this operation will be. If the server starts you should immediately export your messages, encryption keys, etc, in a salvage effort and prepare to reinstall.

4. Start the server in repair mode.

Warning

Salvage mode potentially impacting the application’s ability to function. We cannot provide support for users who have entered this mode.

Caution

Always create a backup of the database before entering this mode. The repair is not configurable and not interactive. It may automatically remove more data than anticipated, preventing further salvage efforts.

tuwunel --maintenance -O rocksdb_repair=true

For corruption affecting the bulk database tables not covered by any journal. This will leave the database in an inconsistent and unpredictable state. It is theoretically possible to continue operating the server depending on which records were dropped, such as some historical records which are no longer essential. Nevertheless the impact of this operation is impossible to assess and a successful recovery should be used to salvage data prior to reinstall.

Once finished, restart the server without rocksdb_repair. If no errors persist, restart the server again without maintenance mode.

5. Utilize an external repair tool.

Warning

Salvage mode potentially impacting the application’s ability to function. We cannot provide support for users who have entered this mode.

git clone https://github.com/facebook/rocksdb
cd rocksdb
make -j$(nproc) ldb
./ldb repair --db=/var/lib/tuwunel/ 2>./repair-log.txt

For situations when the repair mode in step 4 failed or produced unexpected results.

Debugging

Note that users should not really be debugging things. If you find yourself debugging and find the issue, please let us know and/or how we can fix it. Various debug commands can be found in !admin debug.

Debug/Trace log level

Tuwunel builds without debug or trace log levels at compile time by default for substantial performance gains in CPU usage and improved compile times. If you need to access debug/trace log levels, you will need to build without the release_max_log_level feature or use our provided release-logging binaries and images.

Changing log level dynamically

Tuwunel supports changing the tracing log environment filter on-the-fly using the admin command !admin debug change-log-level <log env filter>. This accepts a string without quotes the same format as the log config option.

Example: !admin debug change-log-level debug

This can also accept complex filters such as: !admin debug change-log-level info,conduit_service[{dest="example.com"}]=trace,ruma_state_res=trace !admin debug change-log-level info,conduit_service[{dest="example.com"}]=trace,conduit_service[send{dest="example.org"}]=trace

And to reset the log level to the one that was set at startup / last config load, simply pass the --reset flag.

!admin debug change-log-level --reset

Pinging servers

Tuwunel can ping other servers using !admin debug ping <server>. This takes a server name and goes through the server discovery process and queries /_matrix/federation/v1/version. Errors are outputted.

While it does measure the latency of the request, it is not indicative of server performance on either side as that endpoint is completely unauthenticated and simply fetches a string on a static JSON endpoint. It is very low cost both bandwidth and computationally.

Allocator memory stats

When using jemalloc with jemallocator’s stats feature (--enable-stats), you can see Tuwunel’s high-level allocator stats by using !admin server memory-usage at the bottom.

If you are a developer, you can also view the raw jemalloc statistics with !admin debug memory-stats. Please note that this output is extremely large which may only be visible in the Tuwunel console CLI due to PDU size limits, and is not easy for non-developers to understand.

Matrix RTC test tool

testmatrix is a command line tool for testing various aspects of a matrix server and guiding debugging. Details for troubleshooting Matrix RTC can be found in the Matrix RTC chapter on troubleshooting.

Development

Information about developing the project. If you plan on contributing, see the contributor’s guide. If you are only interested in using it, you can safely ignore this page.

Rust Documentation

Tuwunel’s rustdocs are hosted within this book under the /docs directory. Developers may build the same documentation locally using cargo doc.

Tuwunel project layout

Tuwunel uses a collection of sub-crates, packages, or workspace members that indicate what each general area of code is for. All of the workspace members are under src/. The workspace definition is at the top level Cargo.toml. See the Rust documentation on Workspaces for general questions and information on Cargo workspaces.

Tuwunel’s crates form a directed acyclic-graph without circular dependencies. Listed here from the top are the most abstract down to the most dependent at the bottom. Crates only have visibility into other crates listed above them; they cannot see structs or call functions in any crate listed below them.

• tuwunel_macros are Tuwunel Rust macros like general helper macros, logging and error handling macros, and syn and procedural macros.

• tuwunel_core is core Tuwunel functionality like config loading, error definitions, global utilities, logging infrastructure, etc.

• tuwunel_database is RocksDB encapsulation, interface wrappers, configurations, and our opinionated asynchronous database frontend.

• tuwunel_service is stateful runtime functionality at the heart of the application. This crate is divided into “services” each with “workers” and queues and all of the moving parts that attend to the tasks of sending messages and notifications, etc. Each service attempts to encapsulate any database tables it requires for its persistent state. Services call other services and they do not form an acyclic graph, for now.

• tuwunel_api is the stateless runtime functionality which implements the Matrix C-S and S-S API’s in a broad set of http handlers. These handlers call various services to query or update their state as necessary. They do not interface with raw data or database functions except through a service.

• tuwunel_admin is a module that implements the admin room as a broad set of command API handlers. Similar to tuwunel_api these handlers also interface with various services as necessary. Currently the admin crate does not call into tuwunel_api as a dependency, but this is not intentional and subject to change.

• tuwunel_router is the webserver and request handling bits, using axum, tower, tower-http, hyper, etc, and the server state to drive the tuwunel_api handlers.

• main is the binary executable. This is where the main() function lives, tokio worker and async initialisation, Sentry initialisation, clap init, and signal handling. If you are adding new Rust features, they must go here. This crate is also capable of compiling as a library for integration testing and embedding.

Notes

It is highly unlikely you will ever need to add a new workspace member, instead look to create a new Service to implement distinct or unique functionality. If you truly find yourself needing another crate, we recommend reaching out to us in the Matrix room for discussions about it beforehand.

The primary inspiration for this design was apart of hot reloadable development, to support “Tuwunel as a library” where specific parts can simply be swapped out. There is evidence Conduit wanted to go this route too as axum is technically an optional feature in Conduit, and can be compiled without the binary or axum library for handling inbound web requests; but it was never completed or worked.

Adding compile-time features

If you’d like to add a compile-time feature, you must first define it in the main workspace crate located in src/main/Cargo.toml. The feature must enable a feature in the other workspace crate(s) you intend to use it in. Then the said workspace crate(s) must define the feature there in its Cargo.toml.

So, if this is adding a feature to the API such as woof, you define the feature in the api crate’s Cargo.toml as woof = []. The feature definition in main’s Cargo.toml will be woof = ["tuwunel-api/woof"].

The rationale for this is due to Rust / Cargo not supporting “workspace level features”, we must make a choice of; either scattering features all over the workspace crates, making it difficult for anyone to add or remove default features; or define all the features in one central workspace crate that propagate down/up to the other workspace crates. It is a Cargo pitfall, and we’d like to see better developer UX in Rust’s Workspaces.

Additionally, the definition of one single place makes “feature collection” in our Nix flake a million times easier instead of collecting and deduping them all from searching in all the workspace crates’ Cargo.tomls. Though we wouldn’t need to do this if Rust supported workspace-level features to begin with.

List of forked dependencies

During Tuwunel development, we have had to fork some dependencies to support our use-cases in some areas. This ranges from things said upstream project won’t accept for any reason, faster-paced development (unresponsive or slow upstream), Tuwunel-specific usecases, or lack of time to upstream some things.

• ruma/ruma: https://github.com/matrix-construct/ruma - various performance improvements, more features, faster-paced development, better client/server interop hacks upstream won’t accept, etc
• facebook/rocksdb: https://github.com/matrix-construct/rocksdb - liburing build fixes and GCC debug build fix
• tikv/jemallocator: https://github.com/matrix-construct/jemallocator - musl builds seem to be broken on upstream, fixes some broken/suspicious code in places, additional safety measures, and support redzones for Valgrind
• zyansheep/rustyline-async: https://github.com/matrix-construct/rustyline-async - tab completion callback and CTRL+\ signal quit event for Tuwunel console CLI
• rust-rocksdb/rust-rocksdb: https://github.com/matrix-construct/rust-rocksdb-zaidoon1 - @zaidoon1’s fork has quicker updates, more up to date dependencies, etc. Our fork fixes musl build issues, removes unnecessary gtest include, and uses our RocksDB and jemallocator forks.
• tokio-rs/tracing: https://github.com/matrix-construct/tracing - Implements Clone for EnvFilter to support dynamically changing tracing envfilter’s alongside other logging/metrics things

Debugging with tokio-console

tokio-console can be a useful tool for debugging and profiling. To make a tokio-console-enabled build of Tuwunel, enable the tokio_console feature, disable the default release_max_log_level feature, and set the --cfg tokio_unstable flag to enable experimental tokio APIs. A build might look like this:

RUSTFLAGS="--cfg tokio_unstable" cargo +nightly build \
    --release \
    --no-default-features \
    --features=systemd,element_hacks,gzip_compression,brotli_compression,zstd_compression,tokio_console

You will also need to enable the tokio_console config option in Tuwunel when starting it. This was due to tokio-console causing gradual memory leak/usage if left enabled.

Contributing guide

If you would like to work on an issue that is not assigned, preferably ask in the Matrix room first at #tuwunel:grin.hu, and comment on it.

Inclusivity and Diversity

All MUST code and write with inclusivity and diversity in mind. See the following page by Google on writing inclusive code and documentation.

This EXPLICITLY forbids usage of terms like “blacklist”/“whitelist” and “master”/“slave”, forbids gender-specific words and phrases, forbids ableist language like “sanity-check”, “cripple”, or “insane”, and forbids culture-specific language (e.g. US-only holidays or cultures).

No exceptions are allowed. Dependencies that may use these terms are allowed but do not replicate the name in your functions or variables.

In addition to language, write and code with the user experience in mind. This is software that intends to be used by everyone, so make it easy and comfortable for everyone to use. 🏳️‍⚧️

Linting and Formatting

It is mandatory all your changes satisfy the lints (clippy, rustc, rustdoc, etc) and your code is formatted via the nightly cargo fmt. A lot of the rustfmt.toml features depend on nightly toolchain. It would be ideal if they weren’t nightly-exclusive features, but they currently still are. CI’s rustfmt uses nightly.

If you need to allow a lint, please make sure it’s either obvious as to why (e.g. clippy saying redundant clone but it’s actually required) or it has a comment saying why. Do not write inefficient code for the sake of satisfying lints. If a lint is wrong and provides a more inefficient solution or suggestion, allow the lint and mention that in a comment.

Variable, comment, function, etc standards

Rust’s default style and standards with regards to function names, variable names, comments, etc applies here.

Software testing

Continuous integration runs Complement protocol compliance tests against Tuwunel. The results are compared against a stored baseline via git diff — both new failures and new passes are flagged. If your changes affect compliance, note it in your pull request and review the result diff uploaded as an artifact.

See Complement Testing for details on how the test harness works and how to run Complement locally against a debug or release build.

Writing documentation

Tuwunel’s website uses mdbook containing rustdoc which are deployed via CI pipeline using GitHub Pages. All documentation is in the docs/ directory at the top level. The compiled mdbook website is also uploaded as an artifact.

• To build the book locally run mdbook build -d <outdir> . in the project root.

• To build the book using local stages of the CI pipeline run docker/bake.sh book; the produced docker image will contain it.

• To build the book using Nix, run: bin/nix-build-and-cache just .#book

Rust API documentation (rustdoc) is generated from the sourcecode contained in src/ and deployed via CI to a directory within GitHub Pages adjacent to the book. In other contexts mdbook and rustdoc are independent.

• To build the API documents locally run cargo doc and browse to target/doc/tuwunel/.

• To build the API documents using local stages of the CI pipeline run docker/bake.sh docs; the produced docker image will contain results in /usr/src/tuwunel/target/x86_64-unknown-linux-gnu/doc (and one can extrapolate for other platforms).

Creating pull requests

Please try to keep contributions to the GitHub. While the mirrors of Tuwunel allow for pull/merge requests, there is no guarantee I will see them in a timely manner. Additionally, please mark WIP or unfinished or incomplete PRs as drafts. This prevents me from having to ping once in a while to double check the status of it, especially when the CI completed successfully and everything so it looks done.

If you open a pull request on one of the mirrors, it is your responsibility to inform me about its existence. In the future I may try to solve this with more repo bots in the Tuwunel Matrix room. There is no mailing list or email-patch support on the sr.ht mirror, but if you’d like to email me a git patch you can do so at jasonzemos@gmail.com.

Direct all PRs/MRs to the main branch.

By sending a pull request or patch, you are agreeing that your changes are allowed to be licenced under the Apache-2.0 licence and all of your conduct is in line with the Contributor’s Covenant, and Tuwunel’s Code of Conduct.

Contribution by users who violate either of these code of conducts will not have their contributions accepted. This includes users who have been banned from Tuwunel Matrix rooms for Code of Conduct violations.

Stale Branch Policy

This section applies to Matrix-Construct members and Tuwunel maintainers

Branches on the matrix-construct/tuwunel repository are centrally maintained. They may be rebased without your consent. Trivial conflicts may be resolved by another maintainer. Please resolve more difficult conflicts as soon as possible. Stale branches may be deleted in some cases; personal repositories are advised for avoiding any such complications.

Protocol Implementation

Specification Compliance

Todo

MSC Implementation Status

The status table lists every memo Tuwunel knows about,

Complement Testing

The Complement results page summarizes runs of the Complement homeserver acceptance suite.

Tuwunel MSC Implementation Status

Columns

• Inv: inventory status (matrix-spec-proposals state). One of merged, open, closed, unknown.
• Status: ✅ yes / 🟨 partial / ❌ no / ⬛ n/a, followed by a confidence glyph (● high / ◐ med / ○ low / · unknown) that reflects confidence in the assessment, not in the implementation.
• Correct/Impl: two absolute percentages of the total proposal, e.g. 70/80. Correct is the share of the proposal’s requirements Tuwunel adheres to correctly; Impl is the share that has any code path attempting adherence. By definition Correct <= Impl. Either may be ?. Proposals are loosely normative, so this is NOT just MUST/SHOULD: every requirement-shaped statement counts (“the server returns X”, “this field is added to Y”, etc.).

Counts

• ✅ yes: 216
• 🟨 partial: 59
• ❌ no: 457
• ⬛ n/a: 292

Status by inventory bucket

Merged

Sorted by MSC number, highest first. Out-of-scope rows are listed in the Out of scope section.

Spec compliance gaps

Merged MSCs (in the live Matrix spec) that Tuwunel does not fully implement. These are the highest-priority items to fix for spec compliance.

Open

Sorted by MSC number, highest first. Out-of-scope rows are listed in the Out of scope section.
